Checking for leaks
WARNING:
Before using this outdoor firepit, make sure you have read, understand and are
following all information provided in the "Safety Information" section beginning on page 2
and 3. Failure to follow those instructions can cause death, serious injury or property
damage.
WARNING:
Failure to inspect this connection or follow these instructions could cause a fire or an
explosion which can cause death, serious bodily injury or damage to property.
Burner connections
1. Make sure the valve connections are securely fastened to the burner and the cylinder.
2. Visually check the connection between the burner/venturi tube and orifice.
3. Make sure the burner/venturi tube fits over the orifice.
4. Please refer to diagram for proper installation (see Figure 6).
5. If the burner/venturi tube does not rest flush to the orifice as shown, please contact us for
assistance.
OPERATING INSTRUCTIONS
7
Figure 6
