- Page 1 IN230100005V01_US 342-071V00 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY INSTRUCTION MANUAL...
- Page 2 Dear customer, Thank you for purchasing this product. So that your appliance serves you well, please read all the instructions in this user's manual. If you have any questions, please contact our customer care center. Our contact details are below: Country Phone Email...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION * Maximum load is 50 kg. * For ages 1-10 years only. Must be under adult supervision. * Only one child can use this product at a time. * When using, only jump in the centre - avoid the sides. * Before using, please take off glasses, necklaces, watches and other valuable accessories. -
Page 4: Parts List
Parts List If any parts are missing, deformed or damaged when you receive your pack- age, please contact customer service with your order number. We will send you the replacement part as soon as possible. 1.frame tubes X6 2.legs X6 3.Jump mat X1 4.elastic jump ropes X30 5.Lower Support Rods X6... -
Page 5: Assembly Method
Assembly method Step 1: Assemble the Trampoline Frame For this step prepare six frame tubes (No. 1) link the six frame tubes to form a hexagonal frame as the picture shows Step 2: Install the legs For this step, please prepare six legs (No. 2), please insert the legs into the frame tube, and then tighten the screws with a screw- driver Fix the leg tube to prevent loosening, as shown in the picture... - Page 6 Step 3: Install the jump cloth For this step, prepare a jumping cloth (#3) and elastic ropes (#4). Please pass the elastic rope through the jump cloth perime- ter and fix it on the trampoline frame. The elastic rope needs to be fixed in a cross shape.
- Page 7 Step 4: Install the Cloth Cover and Support rod Prepare six lower support rods (#5) and six upper support rods (#6) for this step. Please insert the lower sup- port rod into the corresponding pole position of the trampoline frame. Align the screw holes and fix with screws until tightened.
- Page 8 Step 5: Install the Plastic Cap For this step, please prepare six plastic caps (No. 7) and fix them to the corresponding screw holes on the top of the support rod, tighten them with screws, and install the six plastic caps on the support rod in turn.
- Page 9 Step 6: Follow the Safety Mesh Cover Please prepare a safety net cover (No. 10) for this step, and put the safety net cover inside the support pole. Then put the elastic band on the net cover into the cap installed on the support rod in turn, and then pull the Velcro strip in the middle of the net cover and fix it on the support rod.
