4G Router
Quick Start Guide
V1.0.1
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DH-WM4700-O and is the answer not in the manual?

Questions and answers

Summary of Contents for Dahua Technology DH-WM4700-O

  • Page 1 4G Router Quick Start Guide V1.0.1 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

  • Page 2: Foreword

    Foreword General This manual introduces the structure and configuration of the 4G router (hereinafter referred to as "the Device"). Models DH-WM4700-O Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will result in DANGER death or serious injury.
  • Page 3 All the designs and software are subject to change without prior written notice. The product  updates might cause some differences between the actual product and the manual. Please contact the customer service for the latest program and supplementary documentation. There still might be deviation in technical data, functions and operations description, or errors ...

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings The manual helps you to use our product properly. To avoid danger and property damage, read the manual carefully before using the product, and we highly recommend you to keep it well for future reference. Operating Requirements Do not expose the device directly to the sunlight, and keep it away from heat.

  • Page 5: Table Of Contents

    Table of Contents Foreword ................................I Important Safeguards and Warnings ......................III 1 Product Introduction ............................ 1 2 Product Configuration ..........................3 Cybersecurity Recommendations ....................7 Table of Contents IV...

  • Page 6: Product Introduction

    Product Introduction Front panel Table 1-1 Front panel description Indicator Status Description Wi-Fi is enabled. Wi-Fi Wi-Fi is not enabled. On: WAN port is connected. On/flash Flash: Data transmission is in progress. WAN port is disconnected. On: Network port is connected. On/flash Local network Flash: Data transmission is in progress.
  • Page 7 Indicator Description One 100 Mbps WAN port for Internet access. WIFI External Wi-Fi antenna. Product Introduction 2...

  • Page 8: Product Configuration

    Product Configuration Before you configure the Device, make sure that: Connect the LAN port of the Device to the PC with network cable, and then power on the  Device. The network of the PC is set to automatic access mode. ...
  • Page 9 Basic setup (Optional) In WAN Setup section, configure WAN parameters. Only the private network card needs to be configured, and the ordinary mobile card  does not need to be configured to automatically access the Internet. Only certain parameters are described, and the rest parameters can be configured ...
  • Page 10 Network setup Configure wireless network name. In the left navigation menu, click Wireless. The Wireless Basic Settings interface is displayed. See Figure 2-4. Wireless basic settings Enter Wireless Network Name (SSID), and then click Save. Configure wireless network password. In the left navigation menu, select Wireless > Wireless Security. Select Security Mode as WPA Personal.
  • Page 11 System log Click Save to finish configuration. Select Status > WebLog to view logs. Click Backup to back up logs.  Click Refresh to refresh logs.  Product Configuration 6...

  • Page 12: Cybersecurity Recommendations

    Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks.
  • Page 13 between 1024–65535, reducing the risk of outsiders being able to guess which ports you are using. Enable HTTPS We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel. MAC Address Binding We recommend you to bind the IP and MAC address of the gateway to the device, thus reducing the risk of ARP spoofing.
  • Page 14 More information Please visit Dahua official website security emergency response center for security announcements and the latest security recommendations. Cybersecurity Recommendations 9...
