Toshiba Satellite A135-S4527 Specifications

Satellite A135 Series Detailed Product Specification
Model Name
:A135-S4527
C1 2
Operating System
• Genuine Windows Vista™ Home Premium(32-bit version)
Processor and Chipset
• Intel® Pentium® dual-core processor T2080
o 1.73GHz, 1MB L2, 533MHz FSB
• Chipset
o Mobile Intel® 943GML Express Chipset
4
Memory
• Configured with 1024MB PC4200 DDR2 SDRAM (both memory slots
may be occupied). Maximum capacity 2048MB
5
Hard Disk Drive
• 120GB (5400 RPM); Serial ATA hard disk drive; 9.5mm height; user
removable
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
7
Display
• 15.4" diagonal widescreen TruBrite™ TFT LCD display at 1280x800
native resolution (WXGA)
o Native support for 720p content
8
Graphics
• Intel® Graphics Media Accelerator 950 with 8MB-256MB dynamically
allocated shared graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Skip to Previous/Next Track, Play, Stop)
Communications
• Modem
9
• 10/100 Base-TX Ethernet
• Integrated Wi-Fi® compliant wireless:
o Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 4 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.2" x 10.5" x 1.47"
Part Number:
3
6
10
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A135-S4527 BTS Rev.1.10 2007-03-22 MCL T20070214 CB1.02
This product specification is variable and subject to change prior to product launch.
1
PSAD0U-05400P
• Weight: Starting at 6.0 lbs (2.73 kg) depending upon configuration
• LCD Cover Color: Mist Gray
Power
• 65W (19V x 3.42A) 100-240V AC Adapter.
o Dimensions (WxDxH): 4.25" x 1.34" x 1.85"
o Weight: starting at 0.67 lbs
12
Battery
• 4000mAh Lithium Ion battery pack
o Dimensions (WxDxH): 8.15" x 2.13" x 0.91"
o Weight: starting at 0.75 lbs
C1 13
Software
• Toshiba Software and Utilities(Pitts to update)
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree®
o TOSHIBA Assist
o TOSHIBA Security Assist
o TOSHIBA Disc Creator
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Speech System
o TOSHIBA Recovery Disc Creator
• Third-party Software
o TOSHIBA Game Console
o Microsoft Works Version 8.5
o Sun® Java™ 2 Runtime Environment
o Adobe® Acrobat® Reader 8.0
o InterVideo® WinDVD® 8 SD
o Microsoft® Windows Media Player 11
o Google™ Desktop
o Google™ Toolbar
o Yahoo! Music™ Jukebox
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day
trial)
o McAfee® Internet Security Suite (30-day trial)
• Special Offers
o Microsoft Office Live
o Microsoft Money Essentials

Environmental Specifications

14
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
• This product is RoHS
SATELLITE – 1 YEAR STANDARD LIMITED
16
WARRANTY
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
UPC:
032017833005
Operating Non-operating
5° to 35° C -20° to 65° C
(41° to 95° F) (-4° to 149° F)
15° C per hour (max) 20° C per hour (max)
20% to 80% 10% to 95%
-30 to 10,000 feet -30 to 40,000 feet
10G 60G
0.5G 1.0G
15
compatible
11
Page 1 of 5
