Toshiba Satellite A135-S2356 Specifications

Satellite A135 Series Detailed Product Specification
Model Name
: A135-S2356
C1 2
Operating System
• Genuine Windows Vista™ Home Basic (32-bit version)
Processor and Chipset
• Intel® Celeron® M Processor 520
o 1.60GHz, 1MB L2, 533MHz FSB
• ATI Radeon® Xpress 200M Chipset
4
Memory
• Configured with 512MB PC4200 DDR2 SDRAM (both memory slots
may be occupied). Maximum capacity 2048MB
5
Hard Disk Drive
• 80GB (5400RPM); Serial-ATA hard disk drive; 9.5mm height; user
removable
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
7
Display
• 15.4" diagonal widescreen TruBrite™ TFT LCD display at 1280x800
native resolution (WXGA)
o Native support for 720p content
8
Graphics
• ATI Radeon® Xpress 200M 128MB dynamically allocated shared
graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Skip to Previous/Next Track, Play, Stop)
Communications
• Modem 9
• 10/100 Ethernet
• Integrated Wireless-LAN:
o Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o USB v2.0 – 4 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.2" x 10.5" x 1.47"
• Weight: Starting at 6.0 lbs depending upon configuration
• LCD Cover Color: Mist Gray
Part Number:
3
6
10
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A135-S2356 BTS Rev. 1.10 2007-03-22 MCL T20070209 CB1.02
This product specification is variable and subject to change prior to product launch.
1
PSAD6U-01800G
Power
• 65W (19V 3.42A) 100-240V AC Adapter.
o Dimensions (WxDxH): 4.25" x 1.34" x 1.85"
o Weight: starting at 0.67 lbs
Battery
• 4000mAh Lithium Ion battery pack
o Dimensions (WxDxH): 8.15" x 2.13" x 0.91"
o Weight: starting at 0.75 lbs
Software
• Toshiba Software and Utilities(Pitts to update)
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree®
o TOSHIBA Assist
o TOSHIBA Security Assist
o TOSHIBA Disc Creator
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Speech System
• Third-party Software
o TOSHIBA Game Console
o Microsoft Works Version 8.5
o Sun® Java™ 2 Runtime Environment
o Adobe® Acrobat® Reader 8.0
o InterVideo® WinDVD® 8 SD
o Microsoft® Windows Media Player 11
o Google™ Desktop
o Google™ Toolbar
o Yahoo! Music™ Jukebox
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day
trial)
o McAfee® Internet Security Suite (30-day trial)
• Special Offers
o Microsoft Office Live
o Microsoft Money Essentials
Environmental Specifications
14
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
• Energy Star Compliant
• This product is RoHS
SATELLITE – 1 YEAR STANDARD LIMITED
WARRANTY
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
11
UPC:
12
C1 13
Operating
5° to 35° C
(41° to 95° F)
15° C per hour (max)
20% to 80%
-30 to 10,000 meters
10G
0.5G
15
compatible
16
032017842533
Non-operating
-20° to 65° C
(-4° to 149° F)
20° C per hour (max)
10% to 95%
-30 to 40,000 meters
60G
1.0G
Page 1 of 4
