Toshiba Satellite A105-S4342 Specifications

Satellite A105 Series Detailed Product Specification
Model Name Description
A105-S4342 Genuine Windows® XP Professional, Intel® Core™ 2 Duo Processor T5500, 2048MB
DDR2, 200GB 4200rpm SATA, DVD SuperMulti (+/- R double layer), 15.4" TruBrite™
(WXGA), Intel® Graphics Media Accelerator 950, Intel® PRO/Wireless 3945ABG
(802.11a/g), CD control buttons, 1 year limited Warranty
2
Operating System
• Genuine Windows® XP Professional
• Windows Vista™ Premium Ready
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
Processor and Chipset
Intel® Centrino® Mobile Technology featuring:
• Intel® Core™ Duo 2 Processor T5500
o 1.66GHz, 2MB L2, 667MHz FSB
• Chipset
o Mobile Intel® 945GM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
5
Memory
• Configured with 2048MB PC4200 DDR2 SDRAM (both memory
slots may be occupied)
• 2048MB (Min)/4096MB (Max), with 1024MB or 2048MB PC4200 or
PC5300 DDR2 memory modules.
6
Hard Disk Drive
• 200GB (4200 RPM) Serial-ATA (SATA) hard disk drive; 12.5mm
height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, 8x), DVD-R (Double Layer, 2x), DVD-RW (4x),
DVD+R (Single Layer, 8x), DVD+R (Double Layer, 2.4x),
DVD+RW (4x), DVD-RAM (5x:write)
8
Display
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
9
Graphics
• Intel Graphics Media Accelerator 950 with 8MB-128MB dynamically
allocated shared graphics memory
Sound
• Built-in harman/kardon® stereo speakers
• Sound Volume Control Dial
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
• Built-in microphone
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
3
4
7
10
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A105-S4342 Rev. 1.20 2006-09-18 MCL T20060621 CB1.70
1
o Windows Key Function
o Application Key Function
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Dual Mode Pad™ pointing device
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem
• Intel PRO/1000 VE Network Connection - 10/100/1000 Base-TX
Ethernet
• Integrated Intel Pro/Wireless Network Connection 3945ABG
12
(802.11a/b/g)
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• ExpressCard slot supporting ExpressCard/34 and ExpressCard/54
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Headphone output port
o Microphone input port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.72 kg) depending upon
13
configuration
• Indicators: DC-IN, HDD, CD/DVD-ROM, CapsLock, Arrow Mode,
Numeric Mode, Battery, System Sleep, Wireless
• Chassis Description
o Case material: PC-ABS Plastic
o LCD Cover Color: Onyx Blue
• Physical Security
o Slot for cable lock; Yes
o Items protected by a screw: Memory, HDD, LAN
o Fingerprint Reader (includes software for password and
identity management)
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Part Number UPC
PSAA8U-14N02R 032017680173
