LEDVANCE PHASE EV

Installation Guide

Side-by-side Mounting Plate

Item No: 78137

Model: EVCSBSMTGPLATE

Side-by-side mounting plate for use with

EVC48ALVL2C1XX (Level 2 Commercial EVSE) and

EVCPED (pedestal).

Please Read All Instructions Before Attempting Installation

−

TO PREVENT PERSONAL INJURY OR PRODUCT DAMAGE ONLY LICENSED ELECTRICIANS SHOULD

PROVIDE ALL INSTALLATION SERVICES.

−

TO AVOID ELECTRIC SHOCK OR COMPONENT DAMAGE DISCONNECT POWER BEFORE ATTEMPTING

INSTALLATION OR SERVICING.

−

THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE (NEC)

AND ALL APPLICABLE FEDERAL, STATE AND LOCAL ELECTRICAL CODES AND SAFETY STANDARDS.

−

ANY ALTERATION OR MODIFICATION OF THIS PRODUCT IS EXPRESSLY FORBIDDEN AS IT MAY

CAUSE SERIOUS PERSONAL INJURY, DEATH, PROPERTY DAMAGE AND/OR PRODUCT MALFUNCTION.

−

TO PREVENT PRODUCT MALFUNCTION AND / OR ELECTRICAL SHOCK THIS PRODUCT MUST BE

PROPERLY GROUNDED.

Page 1 of 6

WARNING

Table of Contents

Need help?

Do you have a question about the PHASE EV EVCSBSMTGPLATE and is the answer not in the manual?

Questions and answers

Summary of Contents for Ledvance PHASE EV EVCSBSMTGPLATE

Page 1 LEDVANCE PHASE EV Installation Guide Side-by-side Mounting Plate Item No: 78137 Model: EVCSBSMTGPLATE Side-by-side mounting plate for use with EVC48ALVL2C1XX (Level 2 Commercial EVSE) and EVCPED (pedestal). WARNING Please Read All Instructions Before Attempting Installation − TO PREVENT PERSONAL INJURY OR PRODUCT DAMAGE ONLY LICENSED ELECTRICIANS SHOULD PROVIDE ALL INSTALLATION SERVICES.
Page 2 Safety Precautions IMPORTANT: READ CAREFULLY BEFORE INSTALLING THE SIDE-BY-SIDE MOUNTING PLATE. RETAIN FOR FUTURE REFERENCE. GENERAL: Upon receipt of the side-by-side mounting plate, thoroughly inspect for any freight damage which should be brought to the attention of the delivery carrier. What’s Included (1) Side-by-side mounting plate (1) Panel cover...
Page 3 Side-by-side (SBS) Mounting Plate Installation 1. Remove the back 2 cover panels by unscrewing the 12 screws. 2. Next, attach the SBS mounting plate to the pedestal with (10) M5 provided screws. Attach SBS mounting plate with (10) M5 screws Page 3 of 6...
Page 4 3. Install the holsters, cable hangers, and front panel cover. Install front panel cover. Page 4 of 6...
Page 5 4. Install charger mounting plate and charger as shown in the pictures below. Repeat for both sides. Page 5 of 6...
Page 6 5. Feed the wirings through the holes on each side and make the connections. When finished, install the back plates and the back panel cover. Feed wirings through Install back plates and hole on each side. back panel cover. Page 6 of 6...
