- Page 1 I N E O D E M H A R D W A R E R E V I S I O N User Guide Copyright 2008-2016 Issue 1.8 MuLogic B.V. Feb. 2016 Plesmanstraat 58d 3905 KZ Veenendaal, The Netherlands...
-
Page 3: Important Note
• Safety: Directive 2006/95/EC (EN 60950) • The LLM-336 complies with EMC directive 2004/108/EC and is classified for use in Residential areas. Test standard: EN 55022 Class B The LLM-336 also complies with the Immunity standard for ITE equipment EN 55024 with the applicable test levels increased to levels compatible with Industrial standards (ref. -
Page 4: Declaration Of Conformity
Declaration of Conformity We, Mulogic b.v., Olivier van Noortstraat 4, 3124LA, Schiedam, the Netherlands, herewith declare that the products: Type of product Model Hardware Revision Panel/DIN-Rail modem LLM-336D Rev. 2 Standalone modem LLM-336S Rev. 2 Rack mounted modem LLM-336R Rev. 2... - Page 5 The LLM-336 is available in two versions of standalone modem or as rack card. The rack card conforms to the CEPT T/CD 01-14 type I specification, which enables easy integration in various hardware environments.
- Page 6 User Guide – Hardware Details and Installation Leased Line Data Modem LLM-336 Features • Supported modem standards Full Duplex operation (ITU-T) V.34 2400 up to 33600 bit/s V.32bis 7200, 12000 and 14400 bit/s V.32 4800 and 9600 bit/s V.22bis 1200 and 2400 bit/s V.22...
-
Page 7: Hardware Versions
User Guide – Hardware Details and Installation Hardware Details and Installation Hardware versions The LLM-336 is available in the following hardware versions: • LLM-336D: Small plastic housing suited for panel or Din Rail mounting. LLM-336R: Modem card for MuLogic UCF and MCF card frames. -
Page 8: Front Panel Led Indicators
LLM-336S Front panel LED Indicators The LED indicators of the LLM-336, display the real-time status of the modem and the key DTE interface signals. In case a communication problem occurs, these LEDs can help you determine the cause of the problem. -
Page 9: Switches And Jumpers
Leased Line Data Modem LLM-336 User Guide – Hardware Details and Installation Switches and jumpers At the LLM-336D, the dipswitches are located at the side of the housing. For reaching the RS485 jumper inside the LLM-336D housing, release the 4 screws at the bottom of the housing. - Page 10 User Guide – Hardware Details and Installation Leased Line Data Modem LLM-336 This switch can be used to reset or restart the modem. SW1, Reset Switch This jumper is used to select 2-wire RS485 or 4-wire RS485/422. JP1, RS485 mode When the jumper is in position 1-2, both 2-wire and 4-wire Rx terminals can receive RS485 data.
-
Page 11: Operating Modes
Leased Line Data Modem LLM-336 User Guide – Hardware Details and Installation Operating modes Note: Profiles 2..40 are factory pre-set. (see notes on page 2-6) Consult chapter 3 if none of these operating modes suit your application. Operating modes Off Off Off Off Off Off... -
Page 12: Multi-Drop Operation
User Guide – Hardware Details and Installation Leased Line Data Modem LLM-336 For full-duplex operating modes 0 to 22, one modem must be set to Originate Originate-Answer mode and the other to Answer mode. See DS2.7 (page 2.4). mode selection... -
Page 13: Line Connector
Leased Line Data Modem LLM-336 User Guide – Hardware Details and Installation Connectors Fig. 5 LLM-336D Fig. 6 LLM-336S, LLM-336R (IOC-PSV board) Line Connector 1 = Not connected 2 = 4-wire transmit signal a (output) 3 = 4-wire receive signal a (input) / 2-wire receive-transmit a... - Page 14 User Guide – Hardware Details and Installation Leased Line Data Modem LLM-336 RS232 Connector V.24 Description Data Control Clock TxD – Transmitted data RxD – Received data RTS – Request to send CTS – Ready for sending ...
-
Page 15: Connector Pinout
Leased Line Data Modem LLM-336 User Guide – Hardware Details and Installation The LLM-336R card has a female 96pin ABC-row DIN 41612 connector. LLM-336R Interface circuits printed bold are compliant with ITU-T V.24/V.28 or RS232C. Connector pin-out Row A Row B... - Page 16 User Guide – Hardware Details and Installation Leased Line Data Modem LLM-336 page intentionally left blank Page 2-10...
-
Page 17: At Command Conventions
Stored factory profiles: These are profiles 2 to 40 as selected with DS1. They are stored in the factory and can be used as they are or changed and stored on profile 0 or 1. Factory profiles can be custom made on request. Contact MuLogic support for further information. AT command conventions Unless specified otherwise, all command lines must begin with the AT attention code. - Page 18 User Guide – Configuration Leased Line Data Modem LLM-336 Using settings of factory profiles for 11bit async. mode For example, factory profile 13 (9600 bit/s V.34 asynchronous) is configured for 10 bit data format operation. This can be used for asynchronous data formats like 9600-8-N-1, 9600-7-E-1 and 9600-7-O-1.
- Page 19 Leased Line Data Modem LLM-336 User Guide – Configuration AT Commands AT&V Display configuration settings The AT&V commands are used to give information on the current and stored settings of the modem. AT&V Using the AT&V command, the settings of the active profile and the stored user profiles are displayed.
-
Page 20: Modulation Modes
User Guide – Configuration Leased Line Data Modem LLM-336 The modem modulation modes of the LLM-336 are set by means of the AT+MS Modulation modes command for full duplex modes, and the ATF command for half duplex modes. Half duplex modulation modes... -
Page 21: Asynchronous Operation
Leased Line Data Modem LLM-336 User Guide – Configuration Asynchronous For asynchronous operation, it is important that the configuration commands are entered in the speed and data format at which the modem operation must operate. So, if the modem must work at an asynchronous data format of 8 data bits and Even parity, the configuration commands must be given in this format. - Page 22 2400 bit/s. Asynchronous buffered mode The LLM-336 supports a buffered interface for asynchronous data in all modem modulation modes. This allows for the attached device to run at a serial port rate other than the line speed of the modem.
- Page 23 Leased Line Data Modem LLM-336 User Guide – Configuration The data rate at which the commands are given is not relevant as the DTE port Applications with rate is determined by the modem. However, for using the escape code for line...
-
Page 24: Half Duplex Operation
V.27bis and V.33 are less effective for half-duplex use with short messages as in these modes the RTS-CTS times are quite long. Note: the V.23, V.27, V.29 and V.33 modes in the LLM-336 modem can only operate in half-duplex, regardless if 2-wire or 4-wire operation is selected. - Page 25 TxD data input. As soon as the block of data has left the transmit data buffer, the transmitter will stop sending and the receiver will be enabled. In ACC mode, the LLM-336 has a feature to suppress the spurious or garbage characters that occur at the RxD output when the remote modem’s carrier is dropped.
- Page 26 User Guide – Configuration Leased Line Data Modem LLM-336 For half-duplex operation the following commands apply: Half duplex modulation modes See page 3-4 AT%H Half duplex carrier control modes AT%H0 Half duplex operation disabled (Set in +MS full-duplex modes) AT%H1 Half duplex operation with RTS carrier control AT%H2 Half duplex operation with RTS control.
-
Page 27: Multi-Point Operation
“slave” modem the receive the poll requests and return the poll responses. Note: The LLM-336 can be used on 2-wire and 4-wire lines. However, on both 2-wire and 4-wire lines, the communication is half duplex, which means that the modem is either transmitting or receiving. -
Page 28: Transmit Level
User Guide – Configuration Leased Line Data Modem LLM-336 The default value of the transmit level is –11dBm (at 600Ω). This value is Transmit level suitable for nearly all applications. The transmit level can be changed by means of registers S91 and S92. Note that transmit levels higher than –11dBm may be in violation with the rules for operation on public leased lines. -
Page 29: Line Diagnostics
Leased Line Data Modem LLM-336 User Guide – Diagnostics Diagnostics For testing purposes, the LLM-336 can report the quality and attenuation of the Line diagnostics line and the actual data rate of the modem connection. To collect this information, an asynchronous terminal or PC with terminal emulation software such as Hyperterm can be used. - Page 30 User Guide – Diagnostics Leased Line Data Modem LLM-336 AT&V1 Report line status The AT&V1 command displays the current connection status. For example: LAST TX rate....26400 BPS HIGHEST TX rate..... 28800 BPS LAST RX rate....26400 BPS HIGHEST RX rate..... 28800 BPS PROTOCOL....
-
Page 31: Technical Specifications
Leased Line Data Modem LLM-336 User Guide – Technical Specifications Technical Specifications Full duplex modulation modes • ITU-T V.34 - 33k6, 28k8, 26k4, 21k6, 19k2, 14k4, 12, 9.6, 7.2, 4.8, and 2.4 kbit/s async/sync. ITU-T V.32bis -14k4, 12k and 7200 bit/s async/sync. -
Page 32: Rts-Cts Delay
User Guide – Technical Specifications Leased Line Data Modem LLM-336 Supported DTE (serial ports) interface signals RS232C – V.24/V.28: TxD, RxD, RTS, CTS, DSR, DCD, DTR, RxClk, • TxClk, TST. RS485 2-wire: TR+, TR- • RS422 - RS485 4-wire: TxD+, TxD-, RxD+, RxD- •... -
Page 33: Line Connection
Leased Line Data Modem LLM-336 User Guide – Technical Specifications Line connection • 2-wire or 4-wire leased lines, cable or voiceband port. Line connector type • - LLM-336D: 6P4C modular jack. - LLM-336S: 6P4C modular jack. - LLM-336R: on DIN 41612M connector. - Page 34 User Guide – Technical Specifications Leased Line Data Modem LLM-336 page intentionally left blank Page 5-4...
-
Page 35: Din Rail Mounting Bracket
Leased Line Data Modem LLM-336 User Guide – Din Rail Mounting Bracket Din Rail Mounting Bracket The LLM-336D is supplied with a mounting bracket for symmetrical rails of 35 mm according to DIN 46277-3, BS5584:1978 or EN 50-022. The bracket is mounted to the bottom of the housing by means of an adhesive strip and two screws. - Page 36 User Guide – Din Rail Mounting Bracket Leased Line Data Modem LLM-336 page intentionally left blank Page 6-2...
- Page 37 Leased Line Data Modem LLM-336 User Guide – Settings of Operating profiles Appendix A Settings of Operating profiles Fore reference the settings of the various operating profiles are given. Profile Port rate AT commands 0 (default) 115200,8,N1 AT&F +MS=11,0 1 (default) 19200,8,N1 AT&F &M +MS=11,0,19200,19200...
- Page 38 User Guide – Settings of Operating profiles Leased Line Data Modem LLM-336 page intentionally left blank Page A-2...
