Connection And Control Panel - ATC SCM25A Pro User Manual

SCM 25/45/
Diagram 4 - SCM25A and SCM45A Pro
Diagram 5 SCM50/100/110/150 -
6
50/100/ 110/ 150

connection and control panel

bass boost
+3dB 0dB (ref.)
can only be safely used lower than 2,000 metres altitude
2000m can only be safely used in non-tropical weather
Acoustic Transducer Co. Is a trading name and
connection and control panel
fault Designed and manufactured by
Acoustic Transducer Company
balanced input
PUSH
Apparaten skall anslutas till jordat uttag
Apparatet må tilkoples jordet stikkontakt
2 1
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
3
model
Input sensitivity
(full output)
2v/8.2dBu 1v/2.2dBu (ref.)
model serial no.
Is the registered Trade Mark of Loudspeaker Technology Ltd.
Tri - AmpPack
High Performance
Active Loudspeaker
bass boost
2v/8.2dBu
+6dB 0dB (ref.)
!
Gloucestershire GL6 8HR
England
MAINS INPUT
50/60 Hz
POWER
CONSUMPTION
625 WATTS MAX.
can only be safely used lower than 2,000 metres altitude
can only be safely used in non-tropical weather
2000m
serial no.
voltage
RETURN TO
MANUFACTURER
NO USER SERVICEABLE PARTS INSIDE
FOR DISPOSAL
CHECK VOLTAGE BEFORE USE
Acoustic Transducer Co. Is a trading name and Is the registered Trade Mark of Loudspeaker Technology Ltd.
I n s t a l l a t i o n
Designed and manufactured by
Acoustic Transducer Company
Gloucestershire GL6 8HR
England
Tri - AmpPack
High Performance
Active Loudspeaker
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
Apparatet må tilkoples jordet stikkontakt
Apparaten skall anslutas till jordat uttag
115/220 - 230 V
fuse:
115V :T6.3A H/250V
220 - 230V :T3.15A H/250V
1:
2:
3:
WARNING
MAINS INPUT
THIS EQUIPMENT
50/60 Hz
MUST BE EARTHED
POWER
CAUTION
CONSUMPTION
RISK OF ELECTRIC SHOCK
425 WATTS MAX.
DO NOT OPEN
CHECK VOLTAGE BEFORE USE
voltage
RETURN TO
MANUFACTURER
FOR DISPOSAL
NO USER SERVICEABLE PARTS INSIDE
Input sensitivity
(full output)
1v/2.2dBu (ref.)
WARNING
THIS EQUIPMENT
MUST BE EARTHED
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
100/115/220 - 230 V
fuse:
100V :T6.3A H/250V
115V :T5A H/250V
220 - 230V :T3.15A H/250V
