Megatron CILLO Instruction Manual

Outdoor Luminaire –
Instruction Manual
2

TECHNICAL SPECIFICATION:

Series Name CILLO Wall Lamp
Model Number MT69049
Color
Lamp Holder
Lamp Wattage
Voltage
Frequency
IP Rating
CAUTIONS:
•
Read the entire manual carefully before installation and operation.
•
Installation or replacement should be performed only by licensed and qualified electricians.
•
DO NOT disassemble the inner part of the luminaire. Doing so may result in luminaire damage or malfunction.
•
Switch OFF the power source before installation, replacement and cleaning!
•
Wearing gloves during installation is recommended to ensure the luminaire is kept in the best condition.
•
Before replacement of the lamp or luminaire, turn it off and allow it to cool down. Heat-resistant gloves are mandatory when handling the luminaire.
•
The manufacturer accepts no liability for any damage resulting from the misuse of the luminaire or from when it is used with inappropriate equipment.
•
Consult your dealer if you have any enquiries.
•
Important warning for drilling in walls: before drilling, make sure that there are no gas and water pipes or power lines behind or near the drilling spots. Drilling and
mounting should be performed only by qualified personnel. Be sure to pay attention at the condition and material of the walls, as the mounting material is not suitable
for all wall types. Please inquire about recommended screws and raw plugs for your wall type and wall condition. The manufacturer accepts no liability for improper
wall raw plug mounting and the herefrom resulting damages.
ATTENTION:
•
Instant start is allowed.
•
Designed for outdoor applications.
•
The operating temperature of the luminaire is -20�C to +50�C.

INSTALLATION Wall Lamp:

1
4
CILLO
OFF
4
CILLO Bollard
MT69048
Graphite
E27
max. 15W
220-240V~
50/60 Hz
IP65
2
OFF
5
Blue
Washer
O-Ring
Replace any cracked
6
protective shield
3
6
IP65
ON
Brown
Blue
O-Ring
Washer
ON
GB
