- Page 1 Digital Wireless System User & fitting guide User Guide & montage User & Einbau Anleitung Utente di montaggio e guida Guía de usuario y montaje User & montage handleiding Part No. 4286C...
- Page 2 Connections Connexions/Verbindungen/Connessioni/Conexiones/Aansluitingen 3 AMP 3 AMP IP67 FUSE FUSE Red: Power Connect to Reverse signal 12/24Vdc Camera connection Rouge: Pouvoir Connecter au signal de marche arrière 12/24 V c.c. Connexion à caméra Rot: Macht Anschluss an Rückwärtsfahrtsignal 12/24 V DC Kameraanschluss Rosso: Potenza Collega a segnale di retromarcia 12/24 Vdc...
- Page 3 Installation Installation/Zum Installieren/Montaggio/Instalación/Om te installeren...
- Page 4 Installation Installation/Zum Installieren/Montaggio/Instalación/Om te installeren Alcohol Prep Pad 70% Isopropyl Alcohol Alcohol Doekjes Isopropyl Alcohol70% Prèps D’Alcool Alcool Isopropilique70% Alkoholtupfer Isopropilische Alkohol70% Pairing operation Opération d’appariement/Pairing-Vorgang/Operazione di accoppiamento/ Operación de emparejamiento/Koppeling Flashing green: Pairing Solid green: Pairing complete Vert: Appariement Vert: Appariement terminé...
- Page 5 Pairing operation Opération d’appariement/Pairing-Vorgang/Operazione di accoppiamento/ Operación de emparejamiento/Koppeling When pairing - DO NOT TURN OFF ignition or disengage reverse gear - product could be permanently damaged! Pendant l'appariement – NE PAS COUPER LE CONTACT ni désenclencher la marche arrière car l'appareil risque d'être endommagé irrémédiablement ! Bei Kupplung –...
- Page 6 Specifications Spécifications/Spezifikationen/Specifiche/Especificaciones/Specificaties ENGLISH FRANCAIS TV system NTSC Système TV NTSC Video signal 1.0 Vp-p 75Ω Signal vidéo 1.0 Vp-p 75Ω Audio 3.0Vp-p@1KHz (Tone) line level Audio 3.0Vp-p@1KHz (Tone) niveau ligne Voltage 12~24Vdc input Voltage 12~24Vdc input Current consumption TX 820+/-20mA @12V Consommation de TX 820+/-20mA @12V Current consumption RX...
- Page 7 Brigade ou ses distributeurs n’assument aucune la responsabilidad de proceder con precaución a la hora responsabilité résultant de l’utilisation ou d’un défaut du de maniobrar con el vehículo. Brigade y sus distribuidores produit. comerciales no se responsabilizan de los daños derivados de un mal funcionamiento del producto.
- Page 8 FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
