Toshiba Satellite 1115-S107 Specifications

TOSHIBA
Satellite 1115 Series
Great Features at a Value Price
Model(s):
Satellite 1115-S107
P4 1800/14.1"TFT/256MB/20GB/DVD/Mdm/LAN/Li-Ion/WinXP Home

Product Highlights

Performance
• Intel® Pentium® 4 processor at 1.80GHz
• 256MB expandable to 512MB
All-in-one design
•
20GB* hard disk drive
• DVD-ROM drive
Great Features
•
14.1" TFT active-matrix display
• 16MB ATI M-6 video memory
Get On-Line
•
Integrated V.92/56K modem
• Integrated 10/100 Ethernet LAN
System Characteristics
CPU
•
Intel® Pentium® 4 processor at 1.80GHz **(See CPU
Performance Disclaimer)
•
Integrated co-processor
L2 Cache
•
512KB Level 2 Cache integrated on die
•
400MHz processor system bus clock speed (PSB)
Memory
• 256MB expandable to 512MB (Both slots may be occupied)
•
Expansion Memory: SODIMM, 128Mbit/256Mbit PC2100 DDR,
2.5V
•
Data/Address Bus Width; 64-bit/32-bit
• BIOS ROM: Inter FWH; 4Mbit
• Intel® 845MP Chipset
Mass Storage
•
Primary Hard Disk Drive: 20GB* hard disk drive; Enhanced IDE
(ATA-5) Interface; 4200rpm drive rotation; 9.5mm height, 0.2lbs,
13ms average access time (read), 3ms track to track seek time
(read), supports PIO mode4, Ultra DMA mode5 & Multiword DMA
mode2
•
DVD-ROM: Enhanced IDE (ATAPI Interface); Maximum speed:
8x; Compatibility: CD-ROM, CD-R(read-only), CD-RW(read
only), DVD-ROM, DVD-R(read only); supports PIO mode4, Ultra
DMA mode2 & Multiword DMA mode2
• Software Decoder: WinDVD
Graphics/Video
•
14.1"TFT color LCD active-matrix display; internal display supports
1024 x 768 Resolution
• 16MB ATI M6-C graphics controller; 16MB external DDR video
memory
•
3D Graphics Accelerator, AGP bus support; 2D Graphics
Accelerator, BitBLT hardware, Hardware cursor, Direct Draw
support
External Color Support/Refresh rate (depending on CRT):
• 800x600; 60/70/72/75/85/90/100/120/160Hz @16M
• 1024x768;
60/70/72/75/85/90/100/120HZ @16M
• 1280x1024; 60/70/75/85/100Hz @16M
• 1600x1200; 60/75/85/100 @ 64K
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 3mm key
stroke, 7mm height; Dedicated Windows & Application keys
support; HotKey function; TouchPad pointing device; Scroll
function (by help of driver)
Expandability
•
2 memory slots (Both slots may be occupied) ; 2 PC Card slots
support 2 Type II or 1 Type III PC Cards; 32-bit CardBus ready
Communications
• Integrated V.92/56K modem; Data and fax support
•
Integrated 10/100 Ethernet LAN
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2002 TAIS portables_satellite_1115S107.doc Created on 2/11/2003 2:08 PM
Part Number
PS111U-00L1MV
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds will
vary depending on line conditions.
Ports
•
Parallel printer port
•
RGB (Monitor) port
• TV-Out
•
3 Universal Serial Bus ports
•
RJ-11 modem port
•
RJ-45 LAN port
Physical Description
•
Dimensions (LxWxH): 12.6" x 10.9" x 1.5"
•
Weight: 6.9 lbs
• LED Indicators: Power, Power Save Mode, HDD, CD/DVD, FDD,
DC-IN, Caps Lock, Arrow, Numeric, Main Battery Charging
Status, System Sleep / Suspend status
Sound
•
Realtek ALC202A Codec Chip; Software sound
• 16-bit stereo, Windows Sound System; SoundBlaster Pro
compatible (in DOS box only); Built-in stereo speakers
• 3D sound support with HRTF 3D positional audio; Direct 3D Sound
(supported by sound driver); Hardware acceleration for
DirectSound and DirectMusic; Full Duplex and MIDI support
•
Sound Volume
• Ports: Microphone port, headphone port
Power Supply
•
AC Adapter: 75W AC Adapter, 100-240V / 50-60Hz frequency
(Universal) input voltage, 19V x 3.95A Output.
Dimensions (LxWxH): 4.3" x 2.4" x 1.2"
Weight: 0.7lbs
• Battery Pack: 8-cell, rechargeable, removable Li-Ion battery,
58Wh
Dimension (LxWxH): 5.0" x 3.8" 0.8"
Weight: 1.01lbs
•
Up to 2.0H battery life; Recharge time (Off/On): 3.5H / 3.5-8H
approx.
Battery life may vary depending on product model, configuration,
applications, power management settings and features utilized.
Recharge time varies depending on usage. Battery may not
charge while computer is consuming full power. After a period of
time, the battery will lose its ability to perform at maximum
capacity and will need to be replaced. This is normal for all
batteries. To purchase a new battery pack, see the accessories
information that shipped with your computer or visit
www.accessories.toshiba.com
Security
•
Cable lock slot, HDD and memory (by screw only), Built-in Modem
(screw only), User Power on Password, Supervisor Password,
Setup Security, Screen Blank (by Hotkey), Screen Saver by
software
Bios
•
ACPI, PnP, VESA, DPMS, SM BIOS, PC BIOS support
Operating System
• Microsoft Windows XP Home pre-installed
• Microsoft Windows 2000 component drivers on the web
Additional Software
•
Microsoft® Works
• Intuit® Quicken Basic 2001
• Norton® AntiVirus™ 2002
•
AOL® (3 –Month offer)
•
Adobe® Acrobat™ Reader
• AT&T® Worldnet® Service – 1 Month Free
Telephone access and other charges and other terms and
conditions may apply. Offer available to new customers only.
Offer expires 4/30/04.
•
Microsoft Internet Explorer
Page 1 of 2
