Summary of Contents for Home Decorators Collection HD19565FL
Page 1
THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this light fixture. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
Table of Contents Table of Contents ............2 Assembly ................. 4 Safety Information ............2 Care and Cleaning ............6 Warranty ................. 2 Troubleshooting ............. 6 Five (5) Year Warranty ............Service Parts ..............6 What is Covered ............... 2 What is Not Covered ..............
Pre-assembly PLANNING ASSEMBLY Read all instructions before assembling. To avoid damaging this product, place it on a soft, non-abrasive surface, such as carpet or cardboard. IMPORTANT: Inspect the wire insulation for any cuts, NOTE: This product requires one 60W maximum abrasions, or exposed copper that may have occurred medium base (E26) type "S"...
Assembly Assembling the column and socket assembly □ Pull the excess power cord (H) through the base (G) . □ Thread the columns (D/E/F), the arm (A), the socket assembly (B) and the base (G) together as shown. Hand-tighten until snug. □...
Page 5
Assembly (continued) Installing the shade and light bulb □ Remove the mounting screws (2) from the socket assembly (B). □ Attach the shade (C) to the cap on the socket assembly (B). □ Secure the shade (C) with the previously removed mounting screws (2). □...
Check the wire connections. □ Contact a qualified electrician or call the Customer Care Service Team at 1-800-986-3460. Service Parts MODEL: HD19565FL / HD19565FL1 / HD19565FL2 Part Description Socket assembly Shade Column 1...
Page 7
Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
Page 8
GRACIAS POR TU COMPRA. Apreciamos la confianza que has depositado en Home Decorators Collection al comprar esta lámpara. Nos esforzamos para continuamente crear productos de calidad diseñados para mejorar tu hogar. Visítanos por Internet para ver nuestra línea completa de...
ÍNDICE Índice................2 montaje................4 Información de seguridad..........2 Cuidado y limpieza............6 Garantía................2 Solución de problemas..........6 Cinco (5) años de garantía............. 2 Piezas de recambio............6 Lo que está cubierto..............2 ¿Qué no está cubierto?..............2 Antes de la montaje............3 Planificación de la montaje............
Antes de la montaje Planificación de la montaje Lea todas las instrucciones antes de realizar la instalación. Coloque este producto sobre una superficie suave y no abrasiva, como una alfombra o una base de cartón, para evitar dañarlo. IMPORTANTE : Revisa que el aislamiento de los NOTA: Este producto necesita uno bombillas de cables no haya sufrido ningún corte, abrasión ni tenga base media (E26) de 60 W como máximo de tipo...
Montaje Montaje de la columna y del conjunto del casquillo □ Tire del cable de alimentación (H) sobrante a través de la base (G). □ Enrosque las columnas (D/E/F), el brazo (A), el conjunto del casquillo (B) y la base (G) como se muestra. Apriete a mano hasta que queden fijos.
Page 12
Montaje (continuación) Instalación de la pantalla y la bombilla □ Retire los tornillos de montaje (2) del conjunto del casquillo (B). □ Coloque las pantalla (C) al tapón del conjunto del casquillo (B). □ Fije las pantalla (C) con los tornillos de montaje (2) retirados anteriormente. □...
□ de circuito se dispara. Contacte a un electricista calificado o llame al equipo de Servicio al Cliente al 1-800-986-3460. Piezas de recambio Modelo: HD19565FL / HD19565FL1 / HD19565FL2 Pieza Descripción Brazo Conjunto del casquillo Pantalla Columna 1 Columna 2...
Page 14
¿Preguntas, problemas o piezas faltantes? Antes de regresar a la tienda, llama al Servicio al Cliente de Home Decorators Collection, de 8 a.m. a 7 p.m., hora estándar del Este, de Lunes a Viernes, y de 9 a.m. a 6 p.m., hora estándar del Este, Sábados.
