User Manual LED Touch Panel IP0065, IP0075, IP0086 For further information, please visit / contact us on: Tel: (RSA) 010 140 4900 / Email: sales@parrot.co.za / www.parrot.co.za...
Description System 1.1 System Home Page Contents 1.1 System Home Page 1.2 Sidebar 1.3 Notication Panel 1.4 Status bar 1.5 System setting 2 Software Description • After the boot is completed, the system will enter the main interface by default. Writing Whiteboard •...
1.3 Notication Panel 1.4 Status bar Click icon to pop up the side menu, as shown in the gure below. The panel contains widget Adjust Screen Brightness Connection Status display, common application shortcut function, custom add application, brightness, sound, and notication center information Wallpaper Interface Unconnected State...
Page 4
3. Wallpaper Wallpaper is divided into static wallpaper and dynamic wallpaper. Click the corresponding wallpaper image to 2. Theme change the wallpaper. Static wallpaper can be added by yourself. Pictures of built-in storage and external storage Humanized design, you can change the theme style. Topics include regular themes and style themes. Regular can be added.
Page 5
6. Bluetooth Timed switch machine - When the integrated machine supports Bluetooth function, Bluetooth pairing can be implemented here to After setting the boot time and shutdown time, the system will automatically turn on or shut down when the set achieve Bluetooth transmission function.
Page 6
9. More multi-functional 12. Sound There is suspension menu, sidebar, pull up menu, environmental sensitivity, centralized control, ve ngers Adjust sound and set sound mode & output device. Sound mode: Standard, news, music, cinema, sports, user. screen out, three ngers screen out and other functions. 10.
Software Description 2.1 Writing Whiteboard Open A File - Click icon to open and save the le under the whiteboard le directory (the default path directory is built-in storage / writeboard), click the le to open directly, and you can edit and save again. 2.1.1 Interface Display - Click whiteboard icon in the main interface to start the whiteboard software...
Insert Info - Click icon to open the local storage or U disk image le, the user can select the image to insert on the - Click icon to view version information. whiteboard, and the picture can be marked and written. Email Exit - Click ...
Page 9
Table - Select Insert Table to insert a table on the screen. Ruler - Select the ruler, the ruler widget appears on the screen. You can draw the line and mark the scale of the line. Calculator - The Select the Calculator to open it on the screen. Compass - Choose a compass to draw a circle or arc on the screen.
Page 10
Spotlight - Select the spotlight to turn it on on the screen. Timer - Select a timer to open it on the screen. Multiple Screens - Select multiple screens, select the set split screen on the screen. Calender - Select Calendar to open it on the screen. Group Camera - Select Group, to select set Group on the screen.
2.1.4 Code Scanning and Sharing 2.1.5 Common Functions Brush - Click the icon to call up the brush tools menu. - Change brush thickness and color. Click the dot icon above to modify the stroke thickness, click the color box to select the brush color, and click the custom icon to expand the color palette to customize the brush color.
Page 12
Select Function - Click to select the selection function, and the interface switches from writing mode to selection mode. The handwriting and shape in the interface can be drawn, and then the functions of moving, deleting, copying and pasting can be realized for the inserted pictures. Move, delete, copy and paste, rotate and zoom. Slide screen cleaning function ...
2.2 Document Management 2.2.1 Interface Introduction Page Preview - Click the le manager icon , open the le management application, and the external SD card and USB - Open the page preview pop-up window: Click to show that the current page is selected. external storage device are displayed on the left side of the le browser.
Sort Audio - Sort: Click icon, the sorting list will pop up. The sorting method has four sorting options: size, name, - When user clicks "Audio”, the audio format le is displayed. type, and time. Users can sort and sort les according to their needs. Video 2.2.3 Extended Menu - When user clicks "Video", the video format le is displayed...
2.3 VIP Reception Favorites - File collection: Select the les you want to collect and click on the collection. - Viewing les: When viewing a le or folder in a favorite, user needs to double-click to receive the le or folder. - Remove the favorite le: Click to select the le or folder to be removed, and then click to remove the favorite 2.3.1 Interface Description - Exit the favorites: Click outside the Favorites interface to exit.
2.4 More Applications Write - Click icon to choose the thickness of the line and the color of the line. 2.4.1 APK Application APK - Click the More Apps icon to enter the More Application interface of the conference system. Users can view or open the APK application installed by themselves in this interface, as shown in the gure.
Page 17
IP0065, IP0075, IP0086 Technical Features: Category LED Touch Panel Resolution 40 Point Touch (Windows) Multi Touch 20 Point Touch (Android) Windows, Max, Android, Linux and OS Support Chrome Network Compatible Wired and Wireless Bluetooth Hotspot Enabled 2.4 and 5Ghz Screen Sizes 65", 75", 86"...
