- Page 1 RLC-1LV Manual for use and maintenance RLC-1LV Light Dimmer Ag/MIS/UmGb-2586-05/18 Rev 1.0 P/N: 116099...
- Page 2 Munters reserves the right to effect modifications to the apparatus in accordance with technical and legal developments. © Munters AB, 2018...
-
Page 3: Table Of Contents
----------------------------------------------------------------------------------------------------------------- PRECAUTIONS ------------------------------------------------------------------------------------------ 5 2.1 Grounding ---------------------------------------------------------------------------------------------------------- 2.2 Filtering -------------------------------------------------------------------------------------------------------------- 2.3 Checking the Battery Level ------------------------------------------------------------------------------------- INTRODUCTION TO THE RLC-1LV ------------------------------------------------------------------- 6 Main Display ------------------------------------------------------------------------------------------------------- 3.2 Setting Mode ------------------------------------------------------------------------------------------------------ 3.3 Menu ----------------------------------------------------------------------------------------------------------------- 3.3.1 Light Table .......................... 6 3.3.2 Growth Day ........................8 3.3.3 Auto/Manual Mode ...................... -
Page 4: Introduction
The information contained herein has been prepared by qualified experts within Munters. While we believe the information is accurate and complete, we make no warranty or representation for any particular purposes. The information is offered in good faith and with the understanding that any use of the units or accessories in breach of the directions and warnings in this document is at the sole discretion and risk of the user. -
Page 5: Precautions
2.3 Checking the Battery Level Check the battery once a year. The output must be 2.7 volts (minimum). Authorized personnel • only must replace the battery if the output is below the minimum required level or every five years. © Munters AB, 2018... -
Page 6: Introduction To The Rlc-1Lv
• 3.3.1 Light Table Every growth day has a “Light Cycle”, which is composed of one or more programming lines day. The RLC-1LV Light Table offers up to 99 programming lines. Each program line is composed of four events: •... - Page 7 Day 7 to Day 42. NOTE The time frame for each program can be set with 10 minutes resolution only. 3.3.1.2 Programming a Light Cycle To program an RLC-1LV: 1. In the main display, press Select. © Munters AB, 2018...
-
Page 8: Growth Day
When there is 0% output the relay activates. The relay is normally open and normally closed. NOTE When the RLC-1LV reaches the last programmed line, it continues working in that last light cycle. It does not automatically return to programming line number 1. -
Page 9: Auto/Manual Mode
7. Press Select, to return to the main display. 3.3.5 Main Display Light Time 48.6% 12:02 NOTE In case of a power failure or if the RLC-1LV is accidentally unplugged, the RLC-1LV is equipped with a battery, ensuring that the program is not erased. © Munters AB, 2018... -
Page 10: Installation
2. Place the required cables through the cable holders at the bottom of the unit. 3. Connect the wires according to the wiring diagrams. NOTE The wires that supply power to the RLC-1LV also supply power to the Light. Ensure that you use the correct wires for the load. -
Page 11: Technical Details
Water and dust tight (IP55) Fuses Main Fuse: 315 mA 5.1 Environmental Protection Recycle raw materials instead of disposing as waste. Sort the controller, accessories and packaging for environmental friendly recycling. The plastic components are labeled for categorized recycling. © Munters AB, 2018... -
Page 12: Warranty
Munters plant was required: if this is not done, the user is fully responsible for the damage which they could suffer. - Page 13 The use of non-original spare parts or incorrect assembly exonerates the manufacturer from all liability. Requests for technical assistance and spare parts can be made directly to the nearest Munters office. A full list of contact details can be found on the back page of this manual.
- Page 14 Munters Brasil Industria e Comercio Ltda, Phone +55 41 3317 5050, Canada Munters Corporation Lansing, Phone +1 517 676 7070, China Munters Air Treatment Equipment (Beijing) Co. Ltd, Phone +86 10 80 481 121, Denmark Munters A/S, Phone +45 9862 3311, India...
