Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be trademarks of their respective owners� No warranty as to accuracy or completeness is expressed or implied�... -
Page 4: Upgrade And Warranty
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor� Alternatively, please try the following help resources for further guidance� Visit the MSI website for technical guide, BIOS updates, driver updates and other information via https://www�msi�com/... -
Page 5: Battery Information
Preface Battery Information European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste� Please use the public collection system to return, recycle, or treat them in compliance with the local regulations� Taiwan: For better environmental protection, waste batteries should be collected separately for recycling or special disposal�... -
Page 6: Safety Instructions
Place the power cord in a way that people are unlikely to step on it� Do not place anything on the power cord� ◙ If this computer comes with an adapter, use only the MSI provided AC adapter approved for use with this computer� ◙... - Page 7 Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper disposal, take-back, recycling, and disassembly of MSI products�...
-
Page 8: Ce Conformity
1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com... -
Page 9: Weee Statement
Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products. - Page 11 Overview This system is integrated in design, selecting a stylish appearance with a mirror screen, which displays the simplicity of modern individualism and the comfort of home. With a touchscreen display, flawless audio/video capabilities and intuitive user interface, it blends technology with life, making computers easier and more fun to use —...
-
Page 12: Packing Contents
Packing Contents PRO 22X/ 22XT AC/DC Adapter AC Power Cord User Manual (Optional) Quick Guide Warranty Card/ Book Mouse (Optional) Keyboard (Optional) * Please contact us immediately if any of the items is damaged or missing� * The illustrations are for reference only and your packing contents may slightly vary depending on the model you purchased�... -
Page 13: System Overview
Overview System Overview Front View Display The 21�5-inch LED-backlit display provides 1920 x 1080 FHD resolution in a 16:9 widescreen format� Stand Use this stand to position your system on a flat and stable surface. - Page 14 Side View Card Reader Drive The built-in card reader may support various types of memory cards� USB 3�2 Gen 1 Port USB 3�2 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed data transfer for various devices, such as storage devices, hard drives, video cameras, etc�...
- Page 15 Overview Rear View Important We suggest that you connect the AC/DC adapter to your AIO PC first and then connect the AC power cord to the socket-outlet for safety concerns�...
- Page 16 TV format, including standard, enhanced, or high-definition video, plus multi- channel digital audio on a single cable� With MSI Instant Display Technology, when you connect power to the AIO PC successfully, the monitor will automatically enter “standby” mode without pressing the power button� When devices are connected to the HDMI-in port, the monitor will be turned on immediately�...
- Page 17 Overview RJ-45 LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN)� You can connect a network cable to it� Yellow Green/ Orange Color LED State Condition Left Yellow LAN link is not established� On (steady state) LAN link is established�...
-
Page 18: Component Replacement & Upgrade
Component Replacement & Upgrade Please note that certain components preinstalled in the product may be upgradable or replaceable by user’s request depending on the models users purchased� For any further information on the product users purchased, please contact the local dealer�... -
Page 19: Getting Started 2-1
Getting Started This chapter provides you with the information on hardware setup procedures� While connecting peripheral devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity�... -
Page 20: Safety & Comfort Tips
Safety & Comfort Tips The AIO PC is a portable platform that allows you to work anywhere� However, choosing a good workspace is important if you have to work with your PC for a long period of time� 1� Your work area should have enough illumination� 2�... -
Page 21: Hardware Setup
Getting Started Hardware Setup Important • The illustrations are for reference only� Your system may vary in appearance� • Please make sure the system has been grounded to earth through the AC power cord and the electrical outlet before powering on the system� •... - Page 22 3� Press the power button to power on the system�...
-
Page 23: System Operations 3-1
System Operations This chapter provides you with essential information on system operations� Important All information is subject to change without prior notice�... -
Page 24: Power Management
Power Management Power management of personal computers (PCs) and monitors has the potential to save significant amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your display or set your PC to sleep mode after a period of user inactivity�... -
Page 25: Network Connection (Windows 10)
System Operations Network Connection (Windows 10) Wired Network 1� Right-click [Start] and select [Network Connections] from the list� 2� Select [Ethernet] and then [Network and Sharing Center]� 3� Select [Set up a new connection or network]�... - Page 26 4� Choose [Connect to the Internet] and click [Next]� 5� Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user name and password� 6� Type the information from your Internet Service Provider (ISP) and click [Connect] to establish your LAN connection�...
- Page 27 System Operations Wireless Network 1� Go to [Start] , click [Settings] and select [Network and Internet]� 2� A list of available WLAN connections pops up� Choose a connection from the list� 3� To establish a new connection, select [Network and Sharing Center]� 4�...
-
Page 28: System Recovery (Windows 10)
System Recovery (Windows 10) The purposes for using the System Recovery Function may include: ■ Restore the system back to the initial status of original manufacturer’s default settings� ■ When some errors have occurred to the operating system in use� ■... - Page 29 System Operations Reset this PC 1� Go to [Start] , click [Settings] and select [Update and security]� 2� Select [Recovery] and click [Get started] under [Reset this PC] to start the system recovery� 3� The [Choose an option] screen pops up. Choose between [Keep my files] and [Remove everything]�...
- Page 30 Keep my files 1� Select [Keep my files]. 2� The [Your apps will be removed] screen shows a list of apps that will need to be reinstalled from the web or installation discs� Click [Next] to continue� 3� The next screen will show the changes to be made during the process� Click [Reset] to start the system reset�...
- Page 31 System Operations Remove everything 1� Select [Remove everything]� 2� If you have multiple hard drives, a screen will pop up, asking you to choose between [Only the drive where Windows is installed] and [All drives]� 3� Then select between [Just remove my files] and [Remove files and clean the drive]. 4�...
-
Page 32: System Recovery (F3 Hotkey Recovery) (Optional)
Recovering the system with the F3 Hotkey Follow the instructions below to continue: 1� Restart the PC� 2� Press the F3 hotkey on the keyboard promptly when the MSI greeting appears on the display� 3� On the “Choose an Option” screen, tap “Troubleshoot”�... -
Page 33: Osd Setup 4-1
OSD Setup This chapter provides you with essential information on OSD Setup� IMPORTANT All information is subject to change without prior notice�... -
Page 34: Navi Key
Navi Key The AIO comes with a Navi Key, a multi-directional control that helps navigate the On- Screen Display (OSD) menu� Navi Key... - Page 35 OSD Setup The Navi Key default settings are as follows� Input Source: PC Mode Operations Menu ■ Use the Up, Down, Left, Right buttons to adjust Brightness and Volume of your system� ■ Press Menu to enter sub-menus� ■ Press Menu again to show main menu� Sub-menus ■...
- Page 36 Input Source: Monitor Mode Operations Menu ■ Press Menu to enter sub-menus� ■ Press Menu again to enter Main Menu� Volume ■ Press the Up button to enter Volume function, and Left and Right buttons to adjust the value� ■ Press Menu to save and exit� ■...
-
Page 37: Osd Setup Via Navi Key
OSD Setup OSD Setup via Navi Key Press the Middle button of Navi Key to launch the On-Screen Display (OSD) main menu� Use the Up, Down, Left, Right buttons to tune the desired function menus to suit your personal preferences. Press Menu 3 seconds to shut the panel off. Press Menu again to wake it up�... - Page 38 Color Cool ■ Default is Normal� Temperature ■ Cool Mode is 9300K; Normal Mode is Normal 6500K; Warm Mode is 5000K� Warm ■ Customization Mode default R/G/B are Customization R (0-100) 50/50/50� G (0-100) ■ Color Temperature has to gray out while B (0-100) sRGB mode is selected�...
-
Page 39: Troubleshooting
Troubleshooting... - Page 40 My system does not start� 1� Check if the system is connected to an electrical outlet and it is turned on� 2. Check if the power cord and all cables are connected firmly. When I turn on my computer, the message “Operating System not found” appears or Windows does not start�...
- Page 41 Troubleshooting System speakers do not work� 1� Check the master volume setting in the Audio Mixer� 2� If you are using an application that has its own volume control, check if the volume is muted� 3� If you have connected an audio cable to the Headphone jack, disconnect it� 4�...
