AXA MX-100 Manual

®
®

Features

• The MX-100 condenser microphone provides smooth, extended
frequency response and is excellent for studio quality vocals, speech
and acoustic instruments.
• The MX-100's Uni-Directional, Cardioid Polar Pattern delivers
high-sensitivity, low-noise and a wide dynamic output.
• A Professional Suspension Shockmount isolates the studio condenser
mic reducing physical vibrations from the mic stand or desktop surface;
It also features an angle adjustment with locking knob.
• Portable, Foldable, Stable and Non-slip Tripod Stand
- Made of stainless steel with 3/8" threaded mount and 5/8" adapter;
non-slip rubberized feet and folding legs.
• The MX100 requires & is compatible with +48 Volt phantom powered
audio mixers & Audio interfaces for your computer.
Specifications
• Type: Condenser
• Pickup: Cardioid Uni-Directional
• Frequency Response: 30Hz ~ 20kHz
• Sensitivity: -38dB (±2dB)(0dB=1V/Pa
@1kHz)
• Output Impedance: 250 ohms,
(±30%)@1kHz
• Dynamic Range: 140dB

PACKAGE INCLUDES

Speak or sing
into the front of
the mic for the best
sound quality.
The frontside is the
AXA logo side.
6.25"
CONDENSER MICROPHONE
*Requires +48 Volt Phantom Power
MX-100
• ENL: 18dB A
• Max. Sound Pressure:
15dB (@1kHz ≥≤ 1% T.H.D.)
• S/N: 76dB
• Requires +48 Volt Phantom Power
• Power Consumption: 3Ma/hr
• Weight: 0.77Lbs (350g)
SHOCKMOUNT BALL TYPE
1.75"
XLR 3-PIN MICROPHONE CABLE
STUDIO CONDENSER MICROPHONE
WITH DESKTOP TRIPOD STAND
3.25"
TRIPOD DESKTOP
MIC STAND
(WITH HEIGHT ADJUSTMENT)
(10FT)
7.25"
5"
3.75"
MICROPHONE
WIND SCREEN
