5. Once the suspension fitting is adjusted and fastened to the side members, tighten the clamp bolt into the side of
the inner mounting tube.
Mounting of Camper Trolley
1. When mounting the Camper Trolley on the suspension fitting, adjust the height of the suspension fitting using the
nose/jockey wheel.
2. The suspension fitting mounted on the Camper Trolley fits into a slit on the underside of the mounting fitting on
the left side (seen from the ball catch) and can be pushed into place in this slot.
3. After pushing the Camper Trolley into the slot in the mounting fitting, attach the factory-provided cotter ring,
which locks the Camper Trolley in place.
4 . After attaching the cotter ring to the Camper Trolley, raise the support wheel to its highest position, and release
the hand brake. This shifts the weight of the caravan onto the Camper Trolley. You are now ready to tow your
caravan.
Illustration of the Camper Trolley mounted on the side
members of the caravan :
Using the Camper Trolley
VARIANTS
CT2500 is equipped with a tall or low tower with ball joint
CT2500 Tall tower CT2500
Height is adjustable Low tower
SOME ADVICE ON SAFETY AND OPEitATION BEFORE STARTING
1. Familiarize yourself with the operating manual, and practice maneuvering the caravan on a flat surface before
attempting to maneuver it on sloping surfaces. We recommend testing your Camper Trolley at home - also
without a caravan -so you can try out the different maneuvering options.
2. Load: The Camper Trolley is designed for moving caravans weighing up to approx. 2500 kg (Model CT2500) or
1500 kg (Model CT1500) . In order for Camper Trolley to function optimally, the ball weight must be at least 75-85
kg. This ball weight creates about 120-150 kg of pressure on the Camper Trolley. Too little weight on the Camper
Trolley may result in poor gripping and poor towing results. Greatest pressure is achieved by mounting the
Camper :rrolley as far back on the side members as possible.
3. level surfaces: To ensure optimal transfer of the Camper Trolley's power to the surface it is to operate on, the
Camper Irolley must move in the direction of the antenna, i.e . forward . (Except on sloping surfaces, see below).
4. Sloping surfaces: OperatinQ the Camper Trolley on sloping surfaces may shift and decrease the pressure on the
Camper Trolley, resulting in poor contact with the terrain.
When using your Camper-Trolley to move you r caravan or trailer UP a slope or edge, the CT must PUSH the
caravan up the slope- if necessary, one wheel at a time. Optionally, use a ramp.
o When moving your caravan DOWN a slope the CT must LEAD the caravan DOWN the slope.
ATTENTION: If going downhill
1
it is very important that the Camper Trolley is turned 180 degrees, so that it is
moving in reverse, down the hill, i.e. with the antenna opposite the maneuvering direction and facing the
cara van. This is important, as the Camper Trolley might otherwise tip over forward.
Special precaution
5. Be aware that if towing down very steep inclines or on wet, oily surfaces, it may be necessary to use the hand
brake on your cara van during operation if the Camper Trolley is unable to hold the caravan or the caterpillar
tracks cannot adequately grip the surface.
