Built-in, Hot Food Servers
Models 3A80A, 3B80A & 3C80A
3A80A
3B80A
Application
Hot food servers are designed to hold
cooked foods at a safe, thermometer
verified serving temperature and proper
moisture content. Hot food can be
placed into the drawer(s) either directly
or in separate open pans or containers.
Holding temperature and moisture
content can be set for the type of food
being held.
suspension system rails. Third
General Information
members have five (5) roller bearings
Built-in, drawer-type hot food server
(load support) and five (5) guide
comes in one or two drawer models.
bearings (smooth operation) each (i.e.
Each drawer is furnished with a
twenty (20) bearings per drawer).
removable, deep drawn stainless steel
Insulation
pan 5-1/2"H x 16-7/16"W x 16-1/3"D.
Fully insulated on all six sides,
See dimensional data and preheat
including drawer fronts, with blanket-
chart on reverse side.
type fiber glass insulation.
Construction
Electrical
The frame is of welded and reinforced
Provided with 48" flexible metal conduit
for electrical connection. Available in
sheet steel. The body is of aluminized
120V or 208/240V units, single phase
steel with stainless steel drawer fronts
and flange. The integral front flange
only. See electrical data chart on
reverse side.
extends beyond the body 1/2" at top an
bottom and 3/8" at the sides. Drawers
are equipped with a handle operated
Heating
latching mechanism and positive stop.
Heating is accomplished with
Drawers glide on third member
preformed tubular heating elements.
1400 Toastmaster Drive, Elgin IL 60120-9272 USA - Tel: 847-741-3300 - Fax: 800-635-4725 - www.toastmastercorp.com
Form 203 Rev 0 (02/05)
Foodservice Equipment
Job ________
Item# ________
Model 3A20A has one heating element
located in the bottom of the unit. 3B20A
has two heating elements located on
the lower sides.
Controls
Temperature is regulated by hydraulic
thermostat adjustable from 100
200
o
F, with "OFF" position. Thermostat
control is mounted on front below the
drawer(s) and is equipped with
adjacent signal light. Thermostat
control knob is protected by a knob
guard on model 3A20A. Model 3B30A
has a thermostat control knob mounted
in a recessed stainless steel mounting
cup. The moisture control adjustment
knob is located at the center front
above each drawer. A thermometer
3C80A
accurately reflects the temperature at
the coolest point inside the server. This
safety feature helps ensure that food
products are being held at a
temperature above the bacterial growth
level, and at temperatures below those
that may over cook or dry out food
product.
Capacity
Unit is designed to hold precooked
foods at serving temperature, ideal for
baked potatoes, vegetables, ribs, buns
and rolls. Nominal capacities per
drawer:
35 baked potatoes (120 count)
7 #10 cans vegetables
25 lb. ribs
5 doz. hamburger buns
6 doz. dinner rolls
No Quibble Warranty
Warranty includes one year parts and
labor, on-site service (USA only).
Ordering Information
!
3A80A - 120V, 1 phase
!
3A80A - 208/240V, 1 phase
!
3B80A - 120V, 1 phase
!
3B80A - 208/240V, 1 phase
!
3C80A - 120V, 1 phase
!
3C80A - 208/240V, 1 phase
!
Pan - ACCPANALL
o
F to
