HOUNÖ
MOUNTING INSTRUCTION
-
English
Replacing the ABB ACS55 0.37 kW and 0.75 kW frequency
inverter with the Mitsubishi CS82S model or the KBVF-26D
model
Visual Cooking
®
1.06, 1.08, 1.10, 1.12, 1.16, 1.20, 2.06, 2.10, 2.14 and 2.20 models
Version 12/2021
CAUTION: Read these instructions before servicing the oven
Advertisement
Summary of Contents for HOUNÖ Visual Cooking 1.06
- Page 1 HOUNÖ MOUNTING INSTRUCTION English Replacing the ABB ACS55 0.37 kW and 0.75 kW frequency inverter with the Mitsubishi CS82S model or the KBVF-26D model Visual Cooking ® 1.06, 1.08, 1.10, 1.12, 1.16, 1.20, 2.06, 2.10, 2.14 and 2.20 models Version 12/2021 CAUTION: Read these instructions before servicing the oven...
- Page 2 2 NOTICE DE MONTAGE - REPLACING FREQUENCY INVERTER, 12/2021...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION SAFETY INFORMATION TOOLS AND REQUIREMENTS BEFORE REPLACEMENT REPLACING THE FREQUENCY INVERTER STATUS MESSAGES ON MITSUBISHI FREQUENCY INVERTER MOUNTING INSTRUCTION - REPLACING FREQUENCY INVERTER, 12/2021 3... -
Page 4: Introduction
0.37 kW and 0.75 kW frequency inverter with the Mitsubishi FRCS82S model on one-fan ovens and with the KBVF-26D frequency inverter on two-fan ovens. This mounting instruction is valid for the Visual Cooking 1.06, 1.08, 1.10, 1.12, 1.16, 1.20, 2.06, 2.10, 2.14 and 2.20 ovens. -
Page 5: Safety Information
SAFETY INFORMATION SAFETY INFORMATION Read this document before using, installing or servicing the product. Installation and operation must comply with local regulations and accepted codes of good practice. All maintenance and repair must be carried out by qualified installation and service technicians only. Installation and/or service by others than qualified service technicians may result in injury to the operator and/or damage to the oven. -
Page 6: Replacing The Frequency Inverter
REPLACING THE FREQUENCY INVERTER REPLACING THE FREQUENCY INVERTER Switch off the power. Remove the ABB ACS55 frequency inverter. Remove the metal bracket that was holding the ABB ACS55 frequency inverter. IMPORTANT! Before you drill out the pop rivets, place a cover such as a piece of card board over the main contactor to avoid drilling shavings to fall into the main contactor points. - Page 7 REPLACING THE FREQUENCY INVERTER Cut out the template for either the KBVF-26D or the Mitsubishi frequency inverter. Select one of the following templates from the spare part kit: • 50000847 Drilling template for electric 1.06, 108, 1.10, 1.12, 1.16, 2.06, 2.10, 2.14 •...
- Page 8 REPLACING THE FREQUENCY INVERTER 8. Place the frequency inverter. Use the three M5x14 bolts and the three M5 washers to fit the frequency inverter on to the plate Mitsubishi FR-CS82S frequency inverter KBVF-26D frequency inverter 8 NOTICE DE MONTAGE - REPLACING FREQUENCY INVERTER, 12/2021...
- Page 9 REPLACING THE FREQUENCY INVERTER 10. Connect the wires to the frequency inverter. See the diagrams below. Mitsubishi FR-CS82S frequency inverter FREK L/R N FREK Brown Blue Black MOUNTING INSTRUCTION - REPLACING FREQUENCY INVERTER, 12/2021 9...
- Page 10 REPLACING THE FREQUENCY INVERTER KBVF-26D frequency inverter FREK L/R N FREK Brown Blue Black Motor wires 11. Switch on the power. 12. Test that the fan runs i both directions at both low and high speed. 13. After testing, the oven is ready for service. 10 NOTICE DE MONTAGE - REPLACING FREQUENCY INVERTER, 12/2021...
-
Page 11: Status Messages On Mitsubishi Frequency Inverter
STATUS MESSAGES ON MITSUBISHI FREQUENCY INVERTER STATUS MESSAGES ON MITSUBISHI FREQUENCY INVERTER MOUNTING INSTRUCTION - REPLACING FREQUENCY INVERTER, 12/2021 11... - Page 12 CONTACT US As your combi oven specialist we do our utmost to help our customers. Worldwide. HOUNÖ A/S ALSVEJ 1 DK-8940 RANDERS SV DENMARK T: +45 8711 4711 E: houno@houno.com www.houno.com...
