ChannelPlus H460 CAT-5 Manual

ChannelPlus Music Distribution System
The H460 CAT-5 Music Distribution System
delivers quality audio to as many as four rooms via a
TM
single CAT-5 connection to each location.
EMITTERS
comes with a wall plate and a hub. The wall plate
delivers audio to the hub which distributes audio to
each location.
LEFT RIGHT
STATUS
INPUT amplifier which is powered by the H460 Hub. The
POWER
system can be expanded with an additional hub for up
OpenHouse model H460
to 8 rooms.
Typical Installation
TM
EMITTERS
Plug in left and
right audio here.
LEFT RIGHT
STATUS
INPUT
POWER
OpenHouse model H460
front
Power light comes
back
on when system is
powered.
Punch down CAT-5 cable from
the wall plate and as many as
four remote amplifiers. Follow
wire colors as shown.
INPUT OUTPUT OUTPUT
Options Port
V+
V-
L+
L-
R+
PWR IR STAT R-
IR
OVERLOAD
Unplug to reset ST
CAT-5 Music Distribution System (1 input X 4 outputs)
TM ChannelPlus model H460 ChannelPlus model H460
Left
Speaker Speaker
-
+
INPUT EXP SPEAKERS
H470
All manuals and user guides at all-guides.com
Each location has its own local
AUDIO RECEIVER
Maximum cable
length = 100 feet
Insert wires into terminal
block and tighten screws.
Use the color bar to
match wire colors.
H460
APPLY
OUTPUT OUTPUT
POWER
V+
V-
LAST
L+
L-
R+
R-
IR
ST
SYSTEM LIGHTS:
PWR: System OK
OVERLOAD: System is shorted,
check wiring
IR&STAT: check web site for
details
No lights: Check fuse
Maximum cable
length = 100 feet
H470
Right
-
+
Insert wire into terminal block and
tighten screws. Color codes:
Brown: +24V
Brown/White: GND
Green: Left
Green/White: GND
Orange: Right
Orange/White: GND
Blue: n/a
Blue/White: na
OpenHouse
The H460
1) Hook from the top
2) Swing into place
3) Push button to lock
Installation Expansion & Using Other Amps
Input wall plate
TM
EMITTERS
LEFT RIGHT
STATUS
INPUT
POWER
OpenHouse model H460
To expand the system to eight
rooms, connect the output of
the first hub to the input of the
second using a CAT-5 patch
cord such as the H691 or H692.
Use only one input wall plate
and connect to first hub as
shown.
H470
SINGLE SPEAKER
To wire to a location
that has only a single
speaker, tie the Orange
and Green lines
together from the H460
and connect to the left
input of the amplifier.
Then connect the
speaker to the Left+
and Left- lines of the
amplifier as shown.
Audio power output per amplifier
Frequency response
Input Impedance
Input Power
tm modules attach from the top
1
3
R R
4
T T
R R
3 T T
2 R R
T T
R R
1
T T
2
Options Port
INPUT OUTPUT
V+
V-
L+
L-
R+
PWR IR STAT R-
IR
OVERLOAD
ST
Unplug to reset
CAT-5 Music Distribution System (1 input X 4 outputs)
TM
H691
Options Port
INPUT OUTPUT
V+
V-
L+
L-
R+
PWR IR STAT R-
IR
OVERLOAD
ST
Unplug to reset
CAT-5 Music Distribution System (1 input X 4 outputs)
TM
Russound A-VC or A-KP
Line level
outputs
to amp.
R+ R- L- L+ R+ R- L- L+
SPEAKER LINE OUT
+
Left
-
-
Right
+
COMPATIBLE AMPLIFIERS
The H460 system is compatible with Russound A-VC and A-KP
volume controls. With these models, systems features such as
IR control of the remote source and external amplified speakers
can be added. Visit www.openhousesystems.com
information about installation and operation of these models.
System Specifications
Continuous 6W per channel @ 8 ohm
20 Hz to 20KHz
20K ohm minimum
105 to 125 VAC
Telephone Master Hub (4 lines x 6 phones) Telephone Master Hub (4 lines x 6 phones)
ChannelPlus model H616
From From Expansion Expansion Telephones
Telco Telco Ports Ports
RJ31X
Out
H460
OUTPUT OUTPUT OUTPUT
V+
V-
L+
L-
R+
R-
IR
ST
1 X 4 Audio Distribution Hub
ChannelPlus model H460 ChannelPlus model H460
H460
OUTPUT OUTPUT OUTPUT
V+
V-
L+
L-
R+
R-
IR
ST
ChannelPlus model H460 ChannelPlus model H460
TM
External
Amplified
Speaker
TM
for more
