- Page 1 FOR THE ONLINE MANUAL CRAY X INSTRUCTION MANUAL Copy of the German original - as of 18.01.2023 German Bionic Systems GmbH info@germanbionic.com www.germanbionic.io August-Wessels-Straße 23 +49 (0) 821 907 497 80 86156 Augsburg www.germanbionic.com GERMANY Copyright © 2022 German Bionic Systems GmbH...
-
Page 2: Table Of Contents
2.9 Industry Canada Statement ----------------------------------------------------------------------------------------------- 6 2.10 ISED Canada ICES-003 Compliance Label ------------------------------------------------------------------------------ 6 2.11 RF Exposure Guidance ------------------------------------------------------------------------------------------------------ 6 3 DEVICE DESCRIPTION --------------------------------------------------------------------------------------------------------- 7 3.1 Cray X --------------------------------------------------------------------------------------------------------------------------- 7 3.2 Type label --------------------------------------------------------------------------------------------------------------------- 7 4 UNPACKING --------------------------------------------------------------------------------------------------------------------- 7 5 TRANSPORT --------------------------------------------------------------------------------------------------------------------- 7 6 OPERATION --------------------------------------------------------------------------------------------------------------------- 8 6.1 Donning/Fastening ---------------------------------------------------------------------------------------------------------- 9... -
Page 3: Instruction Manual
The German Bi- onic Cray X was specially designed for the manual lifting of heavy goods and tools and to reduce associ- ated compression forces in the lower back. -
Page 4: Safety
Any interventions and modifications, such as opening the covers or any manipulations that might affect the safety technology and functionality of the Cray X must carried out by German Bionic. Only original accessories and spare parts may be used, as only they guarantee the safe and malfunction-free operation of the Cray X. -
Page 5: User Requirements
2.6 Safety features Both leg connections of the Cray X are equipped with mechanical end stops that limit the angle of rota- tion of the connections around the drive axis to 180°. Limiting the extension of the leg connections pro- tects the wearer from the risk of injury during use of the Cray X. -
Page 6: Federal Communications Commission (Fcc) Statement
(2) this device must accept any interference received, including interference that might cause undesired operation. WARNING: Changes or modifications not expressly approved by German Bionic could void the us- er's authority to operate the equipment. -
Page 7: Device Description
13. Emergency stop button 14. Rear leg connection 3.2 Type label The identifying information for the Cray X (serial number, model name, etc.) are indicated on the type label. The type label is located on the support structure. 4 UNPACKING NOTICE Keep the carton and packing material for storage and subsequent transport. -
Page 8: Operation
Avoid direct skin contact in case of allergy. Wear long-sleeved outerwear and long pants. CAUTION Leaving the battery in the Cray X when not in use → risk from uncontrolled motor movements. Remove the battery from the device after use. -
Page 9: Donning/Fastening
7 DECOMMISSIONING/STORAGE NOTICE Leaving the battery in the Cray X when not in use → risk from uncontrolled motor move- ments. Always remove the battery of the Cray X for storage. Also follow the instructions of the battery manufacturer. -
Page 10: Disposal
A: Before starting work; B: After end of work; C: As required; D: In case of damage; E: Annually 9.2 Annual maintenance The Cray X is sent to the manufacturer for annual maintenance. Maintenance can also be carried out on site if previously arranged with a service employee from German Bionic. -
Page 11: Faults And Malfunctions
Cray X needs to be recalibrated. “Battery low” appears The battery charge has Switch off the Cray X, remove the battery, charge it on the display. dropped below 10%. and insert a fully charged battery (see online instruc- tion manual). -
Page 12: Specifications
70 Average airborne noise emission dB (A) <80 Max. airborne noise emission dB (A) <100 Protection class Fire protection class UMTS bands B1/B2/B4/B5/B6/B8/B19 LTE bands B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/ B26/B28/B66/B34/B38/B39/B40/B41 Wi-Fi 2.4 GHz Instruction manual __________________Cray X __________________________ German Bionic Systems GmbH...
