CAHABA SACHA CA401006-WH Manual

71 in. freestanding acrylic tub
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
SACHA 71 IN. FREESTANDING ACRYLIC TUB
CA401006-WH (White Pop-Up & Overflow)
FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101.
© 2021 CAHABA. ALL RIGHTS RESERVED.
Drain / Drenaje
43 1/4" [1100]
63 1/2" [1610]
71 1/4" [1810]
FEATURES
MODEL
CA401006-WH
71-1/4"L x 33-3/4"W x
SIZE
23-1/4" H
DEPTH
14-1/4" Soaking Depth
CAPACITY
63.5 gal Capacity
WEIGHT
79.4 lbs Empty
MATERIAL Acrylic
DRAIN
Center, Included
• Lightweight, durable acrylic
reinforced with fiberglass in a glossy
white finish
• Concealed, adjustable leveling legs
• Includes pre-installed white pop-
up drain and waste overflow; not
interchangeable
• No faucet holes - supports wall-
mounted, deck mounted or
freestanding faucets; Faucet not
included
• Limited 25-year residential warranty
BEFORE YOU BEGIN INSTALLATION
• Drawings are for reference ONLY.
This guide illustrates best practices.
• Carefully Read the instructions
before starting installation.
• This product should be installed by
an experienced plumber.
• Make sure the floor drain is already
installed and is compliant with your
local regulations.
• Piping and drain trap are not supplied
If you are missing any part, please
stop and contact us immediately at
(205) 702-9101.
1

Advertisement

Table of Contents
loading

Related Manuals for CAHABA SACHA CA401006-WH

Summary of Contents for CAHABA SACHA CA401006-WH

  • Page 1 • Piping and drain trap are not supplied If you are missing any part, please stop and contact us immediately at (205) 702-9101. FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.
  • Page 2 8 5/8” [220] Zone for P-Trap and Waste Outlet floor cut-out Extra zone for P-Trap & 33 7/8” [860] Waste Outlet floor cut-out Drain FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.
  • Page 3 2. Place the tub in the desired position and level it using the adjustable feet. 3. Remove the bathtub and put it on a throw rug to prevent damages. FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.
  • Page 4 Then assemble the top of the bathtub with the skirt, and secure the bolts at the bottom as shown in the illustration. FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.

  • Page 5: Installation - Option

    PVC pipe sealant to join the parts together. 2. Connect the P-trap to the adapter using PVC pipe sealant to adequately join the two parts. FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.

  • Page 6: Securing The Tub

    1. Test for leaks by filling up the tub and let it drain. 4. Let dry 24 hours. Then check all plumbing connections for leaks. FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.

  • Page 7: Recommended Cleaners

    USE OF THESE CHEMICALS WILL VOID YOUR WARRANTY. FOR WARRANTY ISSUES OR QUESTIONS, CONTACT CAHABA AT (205) 702-9101. © 2021 CAHABA. ALL RIGHTS RESERVED.

  • Page 8: Who Is Covered By The Warranty

    WHAT IS COVERED BY THE WARRANTY Cahaba warrants our bathtubs to be free from defects in workmanship and materials under normal use and service for a period of 25 years. • Cahaba warrants the acrylic surface against blistering or •...
