- Page 1 OPERATOR’S MANUAL Air-Operated Double Diaphragm Pump (1”) SDS10-AAT-TATS-02 OPERATION, INSTALLATION & MAINTENANCE PARTS LIST **STOP** READ THIS MANUAL CAREFULLY BEFORE INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT KEEP OFF THE LOSS UNNECESSARY.
-
Page 2: Table Of Contents
NOTICE OF OPERATION ........................... 3 NOTICE OF MAINTENANCE ..........................3 CHECK REGULARLY ............................4 DIMENSIONS & PART LIST – SDS10-AAT-TATS-02 ................... 5 INSTALLATION AND CONFIGURATION • Use the hose or soft tube to connect to the inlet and outlet. Reduces loss from vibration. -
Page 3: Notice Of Operation
NOTICE OF OPERATION • Check the installation if they are correct before starting the pump. If the pump operates while there are any loose fasteners, it will cause damage to surrounding people and equipment. • If the fluid is a flammable, it is recommended to link the ground wire to avoid chances of a fire or explosion from happening. -
Page 4: Check Regularly
CHECK REGULARLY • Clean any impurities in the air-inlet filter regularly. Otherwise the impurities will reduce the efficiency or breakdown the pump. • If regular checks on the pump are neglected, the pernicious fluid will invade the stratochamber of the pump when the diaphragm breaks, and the pump will breakdown. -
Page 5: Dimensions & Part List - Sds10-Aat-Tats-02
DIMENSIONS & PART LIST – SDS10-AAT-TATS-02... - Page 7 No. Component Component Amount No, Component Component Amount Name Name Hexagon Screw PC000003SW O-Ring PD000025 O-Ring PB000002 O-Ring PD000002 Hexagon Screw PC000002SW Thimble PA000201 Down Ball Seat PA000010 Thimble Cap PB000361 O-Ring PB000084 Hexagon Screw PC000101SW Up Ball Seat PA000022 Abnormal O- PD000138 Ring...
- Page 8 Address: 5 Lyn Parade, PRESTONS, NSW 2170 E-mail: sales@mtmwarehouse.com.au Telephone: (02) 9607 4300...
