- Page 1 KEEPS YOU GOING. OPERATING MANUAL LED WARNING BEACON B10512 series Original operating manual WWW.BEPCOPARTS.COM 11/2023 – V01...
- Page 2 © 11-2023. Bepco is a trademark of TVH Parts Holding NV. TVH Parts NV, Brabantstraat 15, B-8790 Waregem. All rights reserved. No part of this publication may be reproduced or communicated in any form or by any means, electronic or mechanical, including copying, recording or use in an information storage or retrieval system, without prior and explicit permission of TVH Parts NV.
- Page 3 Manuál vo vašom jazyku môžete nájst v priloženom vysvietenom riadku. Slovenian Ta priročnik najdete v svojem jeziku preko spodnje povezave. Swedish Du kan hitta denna manual på ditt språk via länken nedan. Turkish Bu kılavuzu aşağıdaki bağlantıdan kendi dilinizde bulabilirsiniz. www.tvh.com/B10512_RV01 3/20...
- Page 4 Thank you for using our product. For your safety and to ensure a correct operation, we would like to bring to your attention some aspects of this manual: • This booklet supplies useful instructions for the correct operation and maintenance of the product.
-
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................DESCRIPTION .. -
Page 6: Introduction
INTRODUCTION This manual contains all the necessary information on the installation and operation of the LED warning beacon B10512 series. Some of the maintenance operations should only be carried out by professional technicians. If you require this information and the maintenance steps, please contact your dealer. Also included in this manual are a number of safety instructions to create a safe working environment. -
Page 7: Description
DESCRIPTION 2.1. Technical data 167TA6912 167TA6915 Total height (H1) (mm) Total diameter (D1) (mm) Diameter of the lens (D5) (mm) Diameter of the base (D6) (mm) Wire length (L3) (mm) Type of mounting On pole Magnetic and hole without thread Diameter of mounting holes (D3) (mm) Distance between the mounting holes (D4) (mm) Minimum voltage (U1) (V) -
Page 8: Main Components Of The Product
2.2. Main components of the product 167TA6912 N° Component Wing nut for tightening or loosening Flexible DIN pole LEDs Lens Base Electrical connection 167TA6915 N° Component Mounting holes LEDs Lens Stretchable electrical connection cable Base Car plug 8/20... -
Page 9: Safety Instructions
SAFETY INSTRUCTIONS 3.1. General safety instructions • Never exceed the maximum allowed voltage that is indicated in this manual. • Do not use the LED warning beacon for any other purposes than those intended. • The person responsible for the use of the LED warning beacon must make sure that all of the safety rules in force in the country of its use are applied, to guarantee that the equipment is used in conformity with the use for which it is destined and to avoid any dangerous situation for the user. - Page 10 In the event that equipment, procedures, work methods or working techniques are used that are not specifically advised by the company TVH Parts NV, it is necessary to make sure that there is no danger to the operator or other people.
-
Page 11: Storage
STORAGE • Make sure to store the LED warning beacon in a sealed box and in a dry and frost- free environment. • Avoid direct sunlight. • Avoid temperature fluctuations. • Make sure that the cable of LED warning beacon 167TA6915 is not pinched or tightened with hard straps. -
Page 12: Installation
INSTALLATION 5.1. Packing list Description Amount Reference LED warning beacon* 167TA6912 LED warning beacon with electric cable* 167TA6915 Manual 168TA8037 * Only one reference applies. 5.2. Safety instructions for the installation of the product • Wear safety gloves when installing the product. •... -
Page 13: Assembly Of The Product
5.4. Assembly of the product 1. Choose the mounting location for the beacon on a flat, smooth surface. If the beacon is to be mounted on a curved surface, such as on the roof of the vehicle, choose a location with the least curvature. The mounting location for the beacon should be chosen so that there is maximum visibility for the oncoming traffic. -
Page 14: Operation
OPERATION 6.1. Safety instructions for operating the product • A damaged or malfunctioning machine must never be used. If damage or malfunctions are discovered during pre-operation inspection or function tests, the machine must be tagged and removed from service. • Do not operate the LED warning beacon unless you have been trained or authorised to do so. -
Page 15: Troubleshooting
TROUBLESHOOTING N° Problem Cause Action The LED The electrical connection of the Loosen the nut screw back. Make warning beacon LED warning beacon is no longer sure the LED warning beacon fits is not working properly connected to the electrical properly on the pole and screw it connection of the pole back on... -
Page 16: Final Decommissioning And Disposal
FINAL DECOMMISSIONING AND DISPOSAL Final, proper decommissioning or disposal of the product must be performed in accordance with the regulations of the country in which the product is used. In particular, regulations governing the disposal of batteries, fuels and electronic and electrical systems must be observed. -
Page 17: Annexes
ANNEXES 9.1. CE certificate 17/20... - Page 18 18/20...
