INSTALLATION AND
ADJUSTMENT MANUAL
M000257
T031U003-1A SMS Tipster Mobile B
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Advertisement
Related Manuals for SMS T031U003-1A
Summary of Contents for SMS T031U003-1A
- Page 1 INSTALLATION AND ADJUSTMENT MANUAL M000257 T031U003-1A SMS Tipster Mobile B DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage NL Handboek voor installatie en instellingen...
- Page 2 Advertencia Avertissement El montaje del producto no es responsabilidad de SMS Smart Media Solutions AB y es muy Le montage doit impérativement être effectué de façon correcte et ne relève pas de la importante que el producto sea montado correctamente. El montaje incorrecto puede responsabilité...
- Page 3 Sulla ricevuta devono essere chiaramente leggibili nome be clearly legible on the receipt. The owner is to pay the cost of returning the product to SMS, while del fornitore e data d’acquisto. Le spese di spedizione a SMS sono a carico dell’acquirente;...
-
Page 4: You Will Need
4 SMS TIPSTER MOBILE ASSEMBLY INSTRUCTIONS YOU WILL NEED No.13 Allen key No.5 NOT INCLUDED Max. weight 50 kgs. Display NUMBER OF PERSONS REQUIRED... -
Page 5: Screw List
SMS TIPSTER MOBILE LIST OF PARTS (1x) (1x) (2x) (2x) SCREW LIST Screw M6x25 (ISO4762) Washer M6/d6,4 Screw M6x25 (ISO7045) Dist. washer 8,2/15x15 Screw M6x16 (ISO7045) Nut M6 (DIN985) - Page 6 6 SMS TIPSTER MOBILE Mount frame on stand (2x) S1(M6x25) (2x) S2 (M6) (2x)
- Page 7 SMS TIPSTER MOBILE Guide all cables...
- Page 8 8 SMS TIPSTER MOBILE (Option1) For VESA 300x300 Attach display mounting screws S4 (4x)- optional S3 or S5 (4x) S4 to be used where cables obstruct mounting (4x) (M6x25) (4x) (8,2/15x15) (4x) (M6x16)
- Page 9 SMS TIPSTER MOBILE (Option1) Attach cable to display Mount display on stand Height adjustment +/- 50mm Tighten all Secure!
- Page 10 10 SMS TIPSTER MOBILE (Option 2) For VESA 400x400 Prepare display mounting brackets S6 (4x) (4x) (Nut M6) Attach display mounting brackets C1 (2x) S5 (4x) (4x) (M6x16)
- Page 11 SMS TIPSTER MOBILE (Option 2) Attach cable to display Mount display on stand Height adjustment +/- 50mm Tighten all Secure! (4x) No.13...
-
Page 12: Product Dimensions
12 SMS TIPSTER MOBILE PRODUCT DIMENSIONS 17,165 15,748 11,811 1,969 25,197 10,795 37,089 21,850 appr 9,449 All dimensions in mm. Dimensions in [brackets] are in inches. SMS Smart Media Solutions AB Hästholmsvägen 32, 5th floor, SE-131 30 Nacka, Sweden www.smartmediasolutions.se...
