INSTALLATION AND
ADJUSTMENT MANUAL
M000293
K05-151-2 / K05-151-6 SMS Presence Wall-Floor Speed 600x400
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SMS K05-151-2
Summary of Contents for SMS K05-151-2
- Page 1 INSTALLATION AND ADJUSTMENT MANUAL M000293 K05-151-2 / K05-151-6 SMS Presence Wall-Floor Speed 600x400 DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage...
- Page 2 Advertencia Avertissement El montaje del producto no es responsabilidad de SMS Smart Media Solutions AB y es muy Le montage doit impérativement être effectué de façon correcte et ne relève pas de la importante que el producto sea montado correctamente. El montaje incorrecto puede responsabilité...
- Page 3 Sulla ricevuta devono essere chiaramente leggibili nome be clearly legible on the receipt. The owner is to pay the cost of returning the product to SMS, while del fornitore e data d’acquisto. Le spese di spedizione a SMS sono a carico dell’acquirente;...
-
Page 4: You Will Need
4 SMS PRESENCE WALL-FLOOR SPEED 600X400 ASSEMBLY INSTRUCTIONS YOU WILL NEED Torx T20 No. 4 No. 5 NOT INCLUDED Max weight 60-90 kgs Display (1x) (8x) (8x) (8x) optional NUMBER OF PERSONS REQUIRED... -
Page 5: List Of Parts
SMS PRESENCE WALL-FLOOR SPEED 600X400 LIST OF PARTS (1x) (1x) (1x) (2x) (8x) ISO 7049 [3,5x 9,5] (1x) (1x) (2x) (1x) (4x) ISO 7380[M8x16] 600x400... - Page 6 6 SMS PRESENCE WALL-FLOOR SPEED 600X400 LIST OF PARTS (cont.) (3x) (1x) (2x) front top front bottom (1x) (1x) front middle front middle K1 SCREW KIT (1 kit/display) SCREW KIT (1 kit/display) Screw M6x10 Screw M6x16 Screw M6x30 Screw M8x20...
- Page 7 SMS PRESENCE WALL-FLOOR SPEED 600X400 Adjust position and depth of bracket 2. Adjust bracket depth 1. Adjust bracket position 1. Adjust bracket position 2. Adjust bracket depth...
- Page 8 8 SMS PRESENCE WALL-FLOOR SPEED 600X400 Mark drill holes (8x) Drill holes (8x) Min 70mm Min 70mm...
- Page 9 SMS PRESENCE WALL-FLOOR SPEED 600X400 Bolt bracket to wall & floor Slide B2 B2 (1x) Slide B1 rear view B1 (1x) Check level before proceeding...
- Page 10 10 SMS PRESENCE WALL-FLOOR SPEED 600X400 Slide B3 (2x) Mount with B4 (8x) Adjust B4(8x) Adjust Tighten B4 (8x) Torx T20 (8x)
- Page 11 SMS PRESENCE WALL-FLOOR SPEED 600X400 Mount cable hooks and guide cables INSIDE OUTSIDE Cable hook E1 (3x) Mount top front cover after guiding cable Guide cables through cable hooks INSIDE Click! Leave enough slack in cable for height adjustment...
- Page 12 12 SMS PRESENCE WALL-FLOOR SPEED 600X400 Mount middle front & bottom front cover Click! (For procedure to open/ close bottom cover see page 17, step 14)
- Page 13 SMS PRESENCE WALL-FLOOR SPEED 600X400 Mount display bracket 600x400 C3(4x) (4x) Mount bracket on display Loosen K1(4x) C1(2x) SCREW KIT (1 kit/display)
- Page 14 14 SMS PRESENCE WALL-FLOOR SPEED 600X400 Mount display Lock display Pull Tighten Secure all!
- Page 15 SMS PRESENCE WALL-FLOOR SPEED 600X400 Adjust spring tension to balance the weight of the display. See below ‘Procedure to adjust spring tension’ Procedure to adjust spring tension Loosen screw Loosen screw Repeat process till both springs are approx. at same height and display...
- Page 16 16 SMS PRESENCE WALL-FLOOR SPEED 600X400 Mount top cover and cap Adjustment & Alignment ADJUST!
- Page 17 SMS PRESENCE WALL-FLOOR SPEED 600X400 To open or close bottom covers Use this space to store cables, codecs, accessories, etc.
-
Page 18: Product Dimensions
18 SMS PRESENCE WALL-FLOOR SPEED 600X400 PRODUCT DIMENSIONS K05-151-2 / K05-151-6 SMS Presence Wall-Floor Speed 600x400 28,35 15,75 23,05 CL D - Centrum Line Display 7,87 7,87 0,33 max 400 - min 200 3,65 27,93 30,53 5,91 All dimensions in mm.
