- Page 1 Bender MP9500 More metal fabrication for your money OPERATIONS MANUAL 4715 136th Avenue, Hamilton, MI 49419 (262) 679-0504 metalprocorp.com August 2022...
-
Page 2: Table Of Contents
Bender MP9500 More metal fabrication for your money TABLE OF CONTENTS Introduction ..............1 Warranty .................1 Return and Refund Policy..........1 Safety ................2 Unboxing and Installation Process .........2 Machine Description ............3 Dimensions ..............4 Capacity................4 Specifications ..............4 Hardware and Components..........4 Bill of Material ..............5 - 6 Tube and Pipe Die Sets ..........7 - 9... -
Page 3: Introduction
WARRANTY INFORMATION Metalpro Corporation (seller) will, within one (1) year from date of purchase replace F.O.B. the factory, any goods which are defective in materials and/or workmanship provided the buyer, at the seller’s option, return the defective goods prepaid to the seller. Punches, dies, and/or blades are warranted to be free of defects in materials and workmanship with thirty (30) days of purchase date. -
Page 4: Safety
For assembly and installation, refer to the exploded views as well as the bill of materials. • Using a forklift or pallet jack, move the crated MP9500 Bender as close as practical to the workstation where the Bender will be assembled and installed. -
Page 5: Machine Description
The tubing is formed against the rotating die. The MP9500 Bender is a single stroke machine. The foot switch controls stroke direction. When the foot switch pedal is held in one direction, the bender cylinder rod will travel in that direction and will stop only if the pedal is released, or the maximum stroke is reached. -
Page 6: Dimensions
Approximately 4 to 5 strokes per minute for the smallest pipe Maximum force 12 Tons BENDER CAPACITY The MP9500 Bender easily handles a wide variety of professional, farm, and industrial production jobs. Using different dies, the 1/2 1/2 1/2 1/2... -
Page 7: Bill Of Material
Bender MP9500 More metal fabrication for your money BILL OF MATERIAL Item MP Number Description 1004 bender head mounting plate ....1 1002 side plate ....... .2 1003 sunburst . - Page 8 Bender MP9500 More metal fabrication for your money BILL OF MATERIAL ( CONTINUED ) Item MP Number Description see pages 7 & 8 rotating die .......1 see pages 7 &...
-
Page 9: Tube And Pipe Die Sets
Bender MP9500 More metal fabrication for your money TUBING DIE SET Tube Size MP Number Description C/L Radius Min Wall Max Wall Weight 1/2 1/2 5/8 5/8 3/4 3/4 1/2 1/2 5/8 5/8 3/4 3/4 ", ", " 9500 ", ",... - Page 10 Bender MP9500 More metal fabrication for your money PIPING DIE SET Pipe Size MP Number Description C/L Radius Min Wall Max Wall Weight 1/2 1/2 3/4 3/4 1/2 1/2 3/4 3/4 ", " 9550 ", " pipe rotating die 3"...
-
Page 11: Leg Stand Assembly
Bender MP9500 More metal fabrication for your money LEG STAND ASSEMBLY – Refer to Figure 1 Step 1: Place the two legs (59) on edge and position the lower shelf (57) and the upper shelf (58) with pump/motor assembly between them. -
Page 12: Bender Head Assembly
Bender MP9500 More metal fabrication for your money BENDER HEAD ASSEMBLY – Refer to Figure 2 Step 1: Lift and position the bender head assembly over the leg stand assembly on top of the leg stand assembly. Lower the bender head until it is properly positioned and resting on the base. -
Page 13: Hydraulic Installation
Bender MP9500 More metal fabrication for your money HYDRAULIC INSTALLATION – Refer to Figures 1, 2, 3 CAUTION: DO NOT ALLOW PIPE TAPE TO OBSTRUCT THE FITTING OPENINGS. IF YOU USE PIPE SEALANT, USE ONLY ENOUGH TO ACHIEVE A GOOD SEAL. DO NOT ALLOW ANY OF THE PIPE SEALING COMPOUND TO GET IN THE HYDRAULIC SYSTEM. -
Page 14: Bender Die Installation
(2). Push shoulder bolt through the "front" side plate, rotating die (90) and the "rear" 1/16 1/16 side plate (Figure 6). Note: Some MP9500 Tubing Benders may have the 3" x " urethane discs (35) epoxied to the side plates (2). - Page 15 Bender MP9500 More metal fabrication for your money BENDER DIE INSTALLATION FIGURE 4 FIGURE 5 FIGURE 6 FIGURE 7 DOWN POSITION FIGURE 8 READY POSITION metalprocorp.com (262) 679-0504 page 13...
-
Page 16: Bending Tube And Pipe
(15). Mark the tubing at the end of the moving die and loosen the set screw (93). Remove the hitch pin and moving die. Step 10: Slide the bent tubing out of the MP9500 Bender and measure the bend angle. It is very likely the tubing will be slightly under bent. - Page 17 Bender MP9500 More metal fabrication for your money BENDING TUBE AND PIPE tubing FIGURE 9 FIGURE 10 feed cage FIGURE 11 metalprocorp.com (262) 679-0504 page 15...
-
Page 18: Bending Instructions And Terminology
More metal fabrication for your money BENDING INSTRUCTIONS AND TERMINOLOGY WARNING: WEAR APPROVED EYE PROTECTION WHEN OPERATING THE MP9500 TUBING BENDER. OBSERVE THE WARNINGS DISPLAYED AND KEEP HANDS AND CLOTHING CLEAR OF ALL MOVING PARTS. The movement of the foot switch determines the direction of travel. Depressing one pedal down causes the cylinder rod to extend, moving the other foot pedal causes the cylinder rod to retract. - Page 19 – Refer to Figures 9, 10 The MP9500 Bender is equipped with an adjustable 'feed cage.' The purpose of the feed cage is to support the tubing as it is drawn through the bender head to ensure that the degree of bend remains accurate and consistent. Additionally, the feed cage absorbs the downward pressure of the tubing created by the bending process.
- Page 20 Bender MP9500 More metal fabrication for your money BENDING 2" PIPE – Refer to Figure 14 5/8 5/8 The 2” pipe die does not use the “Feed Cage” to support the tube. Instead, a " steel support plate laid directly on bottom plate (#9) supports the pipe.
-
Page 21: Tube Usage
Bender MP9500 More metal fabrication for your money TUBING USAGE Square Tubing Bend Angle in Degrees Usage per degree 1/2 1/2 ", 3" radius .85" 1.7" 2.55" 3.40" 4.25" 5.10" 6.81" 8.51" 10.21" .057" 4" radius 1.11" 2.22" 3.34" 4.45"... - Page 22 Bender MP9500 More metal fabrication for your money TUBING USAGE Round Tubing Bend Angle in Degrees Usage per degree 3" die radius .79" 1.57" 2.36" 3.14" 3.93" 4.71" 6.28" 7.85" 9.42" .053" 4" die radius 1.05" 2.09" 3.14" 4.19" 5.24"...
-
Page 23: Maintenance
More metal fabrication for your money MAINTENANCE During maintenance of the MP9500 Bender, also check condition of all hydraulic and moving parts. Repair any damage and replace any worn parts. Call METALpro customer service with any questions or concerns. CLEANING WARNING: ALWAYS WEAR EYE PROTECTION WHEN CLEANING THE Bender Step 1: Keep the Tubing Bender clean.
