22950
Operating, Maintenance &
Parts Manual
Series 622
Rated Loads:
1/2, 1, 2, 3, 5 and 10 tons
(500,1000, 2000, 3000, 5000,
and 10,000kg.)
F
ollow all instructions and warnings for
inspecting, maintaining and operating this hoist.
The use of any hoist presents some risk of personal injury or property
damage. That risk is greatly increased if proper instructions and
warnings are not followed. Before using this hoist, each operator
should become thoroughly familiar with all warnings, instructions and
recommendations in this manual.
Retain this manual for future reference and use.
Forward this manual to operator.
Failure to operate equipment as directed in manual
may cause injury.
Before using the hoist, fill in the information below.
Model Number
Serial Number
Purchase Date
Columbus M c Kinnon Corporation
Industrial Products Division
140 John James Audubon Parkway
Amherst, New York 14228-1197
H-8535
®
Price: $5.00
Manual No. B622-E
0120 IH-8535VND

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 622 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for U-Line 622 Series

  • Page 1 Operating, Maintenance & Parts Manual Series 622 Rated Loads: 1/2, 1, 2, 3, 5 and 10 tons (500,1000, 2000, 3000, 5000, and 10,000kg.) ollow all instructions and warnings for inspecting, maintaining and operating this hoist. The use of any hoist presents some risk of personal injury or property damage.
  • Page 2 CM HOIST PARTS AND SERVICES ARE AVAILABLE IN THE UNITED STATES AND IN CANADA As a CM Hoist and Trolley user you are assured of reliable repair and parts services through a network of Master Parts Depots and Service Centers that are strategically located in the United States and Canada.
  • Page 3 H-8535 0120 IH-8535VND...

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS Each Series 622 Hand Hoist is built in accordance with the specifications contained herein and at the time of manufacture complies with our interpretation of applicable sections of the * American Society of Mechanical Engineers Code B30.16 “Overhead Hoist” and the Occupation Safety and Health Act. The safety laws for elevators and for dumbwaiters may specify construction details that are not necessarily incorporated in CM industrial hoists.

  • Page 5: General Information

    Operate the hoist with no load and then a light load of approximately 50 pounds (23 GENERAL INFORMATION Kg.) times the number of load supporting chains to make sure it operates properly and the brake holds the load when the hand chain is released; then operate with a rated load as shown on the capacity plate.

  • Page 6: Hook Inspection

    h. Hooks — dye penetrant, magnetic particle or other suitable crack-detecting inspections should be performed at least once a year, if external conditions WARNING indicate there has been unusual usage. Any deficiencies noted are to be corrected before the hoist is returned to service. Power operation may result in structural damage or premature wear that may Also, the external conditions may show the need for more detailed inspection which, cause a part to break and allow the load to fall.

  • Page 7: Hand Chain

    Max. Length No. of Links Allowable for WARNING Chain Stock Hoist Used Chain Diameter Rated Load Gage In. (mm) In. (mm) Tons (Kg.) Used motor oils contain unknown carcinogenic materials. 7.031 (178.6) 0.197 (5) (500) 8.531 (216.7) 0.236 (6) 1 (1000) TO AVOID HEALTH PROBLEMS: 14.125 (358.7) 0.394 (10)
  • Page 8 through the last link of the chain. Slide the loose end pin into hole in the handwheel side 2. The latch is secured to the hook (upper and lower) by a rivet. To plate (622-4). until the cotter pin hole is visible. Secure the loose end pin by reinstalling remove the latch, it is necessary to remove the head of the rivet by the cotter pin and spreading the legs of the cotter pin.

  • Page 9: Ordering Information

    ORDERING INFORMATION DEAD LOOSE BLOCK LOOSE The following information must accompany all correspondence or repair parts orders. Hoist Capacity Serial Number -- stamped on the capacity label. DEAD For parts orders also specify: BLOCK Quantity desired Key Number of Part Part Name Part Number When ordering replacement parts, consideration should be given to the need to...
  • Page 10 SERIES 622 HAND HOIST PARTS LIST PART NUMBER REQ’D PART NUMBER Rated Load—Tons (Kg.) 3 (3000) 5 (5000) 10 (10000) 1/2 (500) 1 (1000) 2 (2000) 622-1 Handwheel Cover with Studs 22910 22791 22812 Handwheel 22911 22792 22813 622-2 Brake Set (2 Friction Washers, Ratchet 622-3 22912 22793...
  • Page 11 622-40, 10 Ton Hoist Hanger Assembly. Except for Latch Kit, Hoist Hanger Kit and Dead End Kit, individual parts are 622-19 not available for repairs. NOTE: Metric Tools Required for Fasteners. 622-24 622-7 622-36 622-36 622-6 622-20 622-8 622-17 622-10 622-19 622-38 622-17...
  • Page 12 Note: When ordering parts, always furnish rated load and serial number of hoist on which the parts are to be used. To quickly obtain the name of the Master Parts Depot or Service Center located nearest you, call (800) 888-0985. Fax: (716) 689-5644. LIMITATION OF WARRANTIES, REMEDIES AND DAMAGES THE WARRANTY STATED BELOW IS GIVEN IN PLACE OF ALL recommendations.
