Summary of Contents for PLENBO G-CASE
- Page 1 － －－－－ ＿...
- Page 2 Handheld Mode Attach your Switch 1. Open the top flap of the G-case. 2. Slide Switch down till it sits properly. Then snap on the flap. *Note: G-case comes in two models: one for Switch Regular and one for Switch OLED. Make sure you choose the right one to fit perfectly.
-
Page 3: Turn On/Off Power
Handheld Mode Turn on/off power Press battery power button to start charging. Press it again to stop charging. KEEP OUT... - Page 4 Handheld Mode Pair Bluetooth 1. Press both buttons on the G-case at the same time to activate them. 2. Press either Bluetooth button. The indicator will flash slowly, showing it's ready to connect. 3. Press and hold the same button until the indicator flashes quickly, indicating pairing mode.
- Page 5 Handheld Mode Change Grips Push the grips downward to take them off. Slide grips upward the rails till you hear a click. Card slot is hidden here; KEEP OUT...
- Page 6 Handheld Mode Recharge other devices Take the battery off the G-case, charge the phone or other digital devices via the USB-C port. *Note: fuel the battery with a USB-C fast charger, recharge other devices with a USB-C to USB-C cable.
- Page 7 Tabletop Mode Step 1 Detach the Switch from the G-Case. Push the left Joy-con holders upward and the right downward to remove them. KEEP OUT...
- Page 8 Tabletop Mode Step 2 Slide to attach the left and right Joy-Con holders together. Open the side stands from the holders, then slide the Joy-Con controllers down. KEEP OUT...
- Page 9 Tabletop Mode Step 3 Put the Switch into the G-Case, lock into place. Flip out the kickstand on the back of G-Case and set it on a flat surface. KEEP OUT...
- Page 10 TV Mode TV Connection 1. Plug in the OneDock to a wall outlet; 2. Connect the G-case to the USB-C port on the OneDock with the original Type-C cable; 3. Put one end of the HDMI cable into the terminal of the OneDock and connect the other end into the HDMI port on the TV.
- Page 12 For Charging 1. Plug OneDock into a power outlet. 2. Connect the Switch with the OneDock via the USB-C to USB-C cable included. KEEP OUT...
- Page 13 1. Plug OneDock into a power outlet. 2. Connect Switch with OneDock via a USB-C to USB-C cable. 3. Connect OneDock with TV/screen via HDMI cable. *Note: Please do not use the USB-A port on the dock to connect the G-case. KEEP OUT...
- Page 14 For Data Transferring 1. Connect computer with OneDock via a USB-C to USB-C cable. 2. Insert USB flash drive into the USB-A port on the OneDock. KEEP OUT...
- Page 15 Switch / Switch OLED PC / Android TV Box Consoles Controllers PS5 / PS4 / PS3 Switch Pro...
- Page 16 Connect to Controllers 1. Go to the Switch’s “System Settings”, select “Controllers and Sensors”, then turn on “Pro Controller Wired Communication”. 2. Plug OneDock into a power outlet and connect it with Switch. 3. Connect Adapter with console via USB-A port.
