NVR335 QUICK INSTALLATION GUIDE
V1.0 010318

Advertisement

loading
Need help?

Need help?

Do you have a question about the NVR335 and is the answer not in the manual?

Questions and answers

Related Manuals for Watchguard NVR335

Summary of Contents for Watchguard NVR335

  • Page 1 NVR335 QUICK INSTALLATION GUIDE V1.0 010318...
  • Page 2 CAMERA COMPATIBILITY NOTE: The NVR4WF is only intended for use with the VSIPW-3VDIR & VSIPW-3FBIR Watchguard WiFi Series 3.0MP Wireless Infrared Fixed Mini Dome/Bullet. Other cameras are not guaranteed to work with this recorder.
  • Page 3 You can also set a prompt question, which can help remind you what your password is. Then, while close to the recorder, power on the Watchguard™ Wireless Mini Dome/Bullet Cameras (VSIP-3VDIR/3FBIR). The cameras should automatically be detected by the recorder.
  • Page 4 Once you have drawn the pattern, or skipped on to the next page, you can now setup your recovery information. Input an email address, and choose questions and answers to the recovery questions. Select “OK” to complete the password setup. You will now be at the startup wizard screen.
  • Page 5 6. Enter your login password, or pattern. 7. Once logged in, select “Date & Time”. Set the correct date and time, then press the “Save” button. Once complete, select the “Next” button.
  • Page 6 8. On the network page, select the “Edit” button. 9. Ensure “DHCP” is selected. Select the “OK” button and then select “Next”.
  • Page 7 10. Put a tick in the “Enable” box. If you already have the mobile application installed on your phone, scan the “SN”, see page 10 for more information. 11. Select the “Next” button. 12. If all the cameras have successfully connected via WiFi, you will see them listed below with a green status icon, indicating they are online.
  • Page 8 14. The green lines running across the screen indicate that the schedule is setup for full time recording. If you wish to change this to motion detection, see the included CD for setup instructions. 15. Select the “Finished” button.
  • Page 9 To Begin Recording Once you have successfully set up the cameras, and have a HDD installed in the recorder, the recorder will start recording footage. To tell if each camera is recording, will be displayed on each camera’s live view screen. When the HDD is full, the oldest recorded footage will be overwritten automatically.
  • Page 10 QR Code Remote Access Setup An internet connection, and compatible smartphone are required. The mobile application is available for Android, and iOS From your compatible Smartphone, access the App Marketplace and download the free App. iDMSS Lite for Apple iOS gDMSS Lite for Android There are two versions of each mobile application.
  • Page 11 5. Ensure “DHCP” is selected. Select the “OK” button and then select “Apply”. 6. Select “EASY4IP”. 7. Ensure “Enable” is ticked. Then select the “Apply” button. The “Status” will change to “Connect Success” once the recorder has a connection to the P2P server. This normally takes 1 minute.
  • Page 12 8. Open the application you have installed on your Smartphone, and select “Camera”. 9. Select the Menu button . Then select “Device Manager”...
  • Page 13 10. Select the Add button 11. Press the “OK” button on the pop up message. 12. Select “WiFi Device”...
  • Page 14 13. You can now select the image of the QR Code and use your phone to scan the code on the recorder. 14. Enter a name for your device, this is for your reference. Enter in your username and password that you set previously.
  • Page 15 15. Select “Start Live Preview”. If the correct details are entered, you phone will connect to your recorder, and you will see your cameras displayed. You have now setup remote access on your mobile device. If you find that the live view is delayed, see page 9 for information on adjusting your Sub Stream settings. For more information on the mobile application, select the Menu button “...
  • Page 16 How to Playback Video Footage 1. Right click anywhere on the screen and select “MAIN MENU”. Use the mouse to enter the recorders password. 2. Once logged in, select the “SEARCH” option. 1. You will now see the Playback screen. On the right-hand side, there is a calendar in which you can select the month and day you wish to playback.
  • Page 17 How to Backup Video Footage To backup Video Footage from your recorder you will first require a USB Flash Drive or USB Hard Drive (we strongly recommend having a FAT32 file system). 1. Inset your USB Flash Drive 2. Right click anywhere on the screen and select “MAIN MENU”. Use the mouse to enter the recorders password.

  • Page 18: Troubleshooting

    Troubleshooting Please refer to the FAQ table below for easy troubleshooting. The table below describes some typical problems and their solutions. Please read this information before contacting your dealer. Problem Solution - Ensure the power cable is firmly connected No power - Confirm that there is power from the outlet.

  • Page 19: Limited Warranty

    Limited Warranty Cornick Pty Ltd (Seller) warrants its products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for forty-eight months from the date of original purchase. Sellers obligation shall be limited to repairing or replacing, at its option, free of charge for materials or labor, any part which is proved not in compliance with Sellers specifications or proves defective in materials or workmanship under normal use and service.
