Cool Collection SeeMag AP864025 Instruction Manual

AP864025
SeeMag wireless charger
80mm
Instruction manual
Do not disassemble the device by yourself. This product is not
equipped with any self-disassembly/maintenance parts.
Wireless charger with multiple protection functions, charging
abnormal, check the status of the mobile phone, re-processing,
the new placement of mobile phone.
In order to give full play to the best charging performance, the
use of the company's Charger is recommended.
If the wireless charging products are not placed correctly, it
may lead to failure to charge properly.
Note: If you place a magnetic stand, protective case, metal or
room card, bus card, bank card, passport, etc. with an NFC or
RFID chip between the phone and the Charger, may degrade
the performance of the charger, causing heat, or even damage
to items.
80mm

Security Information:

Please read and follow the following notes before using and
operating the device.
In medical and health-care settings where the use of wireless
devices is explicitly prohibited, please comply with the site
regulations and turn off the devices.
When using this device, keep at least 30 cm away from the
implanted medical device (such as pacemaker, cochlear implant,
etc.) .
Please keep the equipment dry. Please do not use the
equipment in the dusty, damp place, in order to avoid causing
equipment failure.
Please do not use this equipment in the thunderstorm day, lest
cause the equipment failure or the electric shock danger.
Use the device at a temperature range of -10 ° C to 45 ° C, and
store the device at a temperature range of -40 ° C to 70 ° C to
avoid device faults.
50mm

Product schematic:

1
2
1
2
3
50mm
Do not expose your equipment to high temperatures or heat, such
as sunlight, heaters, microwaves, ovens, or water heaters.
Do not use this product beyond its maximum output parameters.
Overload output may cause risk of fire or injury.
Please treat the equipment according to the local regulations. Do
not treat the equipment as domestic waste. Please comply with
this equipment and its attachments for handling of local
ordinances, and support recovery actions.
Do not allow children or pets to swallow equipment as this may
cause harm to them.
This equipment and its accessories may contain some small parts,
please put the equipment and its accessories in a place that
children can not reach. Children may inadvertently damage the
device and its accessories, or swallow small parts causing
asphyxiation, asphyxiation, or other hazards.
Please do not drop, squeeze or puncture equipment, so as to
avoid causing equipment failure.
Use of unauthorized or incompatible power supplies, chargers, or
batteries can cause fire or other hazards.
This item is in conformity with the following standards:
RoHS Directive 2011/65/EU and its subsequent amendments Directive
(EU) 2015/863
Radio Equipment Directive (RED) - Directive 2014/53/EU
UK Electrical Equipment (Safety) Regulations (SI 2016/1101)
UK Radio Equipment Regulations (SI 2017/1206)
This symbol both in the product and its user manual indicates that
at the end of the devices electrical life, it should be recycled
separately from your household waste. There are adequate
means to dispose of this material for proper recycling. For more
information, contact your local authorities.
3
50mm
Wireless charging area
LED Lights
USB
3
No foreign objects
between the
phone and
the wireless
charger！
1
50mm
Distributor: Cool Collection
1476, Budapest,
POB:176. Hungary
Registration nr. 01-09-276783
Made in China
4
50mm

Specifications:

Input: DC 5V/2A, 9V/2A
Wirelwss Output: DC 5V/1A, 9V/1.1A; 10W
Maximum power: 10W
Operating temperature: 0℃ to 25℃
Operation Frequency :110-205KHZ

How to use wireless charging:

① This product has 2 white LED indicator lights. When the power
comes on, the LED lights flash and then go out.
② Once connected, place the supporting wireless charging mobile
device in the wireless charging area. During charging, the LED
indicator will always be on.
③ The phone will start charging automatically.

Attention:

When using the wireless charging function, if the
LED indicator flashes, the device does not support wireless
charging or there is foreign body interference between the
device and the wireless charging surface, or overheating.

Points to note:

Before using this product, please be sure to read the product
manual carefully, and according to the instructions of the use of
the correct operation.
2
