- Page 1 Global Green Energy Industry Eco-Integrator PV Module Installation Manual V.2311...
- Page 2 Global Green Energy Industry Eco-Integrator List of Applicable Modules Module type Module model HY-NT10/54H HY-NT10/54BH HY-NT10/72H HY-P10/54H Single-glass module HY-P10/54BH HY-P10/72H HY-NT12/66H HY-NT10/54GDF HY-NT10/54BGDF HY-NT10/72GDF HY-NT10/78GDF Double-glass module HY-P10/54GDF HY-P10/72GDF HY-NT12/66GDF...
-
Page 3: Table Of Contents
Global Green Energy Industry Eco-Integrator CONTENTS 01 Introduction 1.1 Purpose 1.2 Scope of liability 02 Law rules and regulations 03 Safety measures 3.1 General safety measures 3.2 Operation safety measures 04 Handling & unloading and unpacking 4.1 Handling & unloading 4.2 Unpacking 4.3 Stacking of modules 05 Mechanical installation... -
Page 4: Introduction
Since the use of this manual and the installation, operation, use and maintenance of PV modules are beyond the con- trol of HY SOLAR, this manual does not have the any significance of warranty, whether expressed or implied. HY SOLAR will not be liable for any kind of injury, including but not limited to loss, damage, personal injury or extra expenses caused by improper installation, operation, use and maintenance of PV modules and systems. -
Page 5: General Safety Measures
• For field wiring, special photovoltaic cables with minimum 90℃ temperature resistance, light resistance, and cross section of not less than 4mm² shall be used as the PV connection line. HY SOLAR PV Module Installation Manual V.2311... -
Page 6: Operation Safety Measures
• Connectors must be kept dry and clean to ensure they are in good working condition. Do not insert other metal ob- jects into the connector or make electrical connections in any other way. HY SOLAR PV Module Installation Manual V.2311... -
Page 7: Handling & Unloading And Unpacking
4.1 Handling & unloading When the PV module is transported to the project site, it must be transported in the packing box provided by HY SOLAR, and shall be stored in the original packing box before installation. Please protect the packing from damage. - Page 8 3. When the manual hydraulic lift is used for turnover, the distance between the upper surface of the forks and the ground shall be ≤75mm. Cushioning material Safety rope Safety guardrails ≥75mm Schematic Diagram for Height Requirement of Schematic Diagram of Forklift Turnover Turnover Forks of Hydraulic Forklift Truck HY SOLAR PV Module Installation Manual V.2311...
-
Page 9: Unpacking
(8) Tear off the anti-dump adhesive tape on both sides, notice to tear off only one piece of anti-dump adhesive tape with module thickness at a time, and then take out the modules one by one in sequence. Long-side vertical unpacking steps HY SOLAR PV Module Installation Manual V.2311... -
Page 10: Stacking Of Modules
Objects such as installation tools, etc. shall be avoided from being placed on the surface of the PV module. Current classification is adopted for HY SOLAR modules. The handling personnel shall place them separately and mark them according to the identification on the power list of the outer package of PV modules. According to the require- ments of system design, the same current grade is generally required in the same array during installation. -
Page 11: Mechanical Installation
PV module installers. The installation incli- nation angle of the PV module recommended by HY SOLAR is not less than 10 ° , so that the dust on the surface of the PV module is easy to be taken away by rain when it rains, so as to reduce the cleaning times of the PV module;... -
Page 12: Fixing Method Of Bolt
④ The tightening torque of M6 bolt is recommended to be 9~12Nm, and the tightening torque of M8 bolt is recommended to be 17~23Nm. Due to possible differences in bolt material, the specific torque value shall be subject to the information confirmed by the bolt supplier. HY SOLAR PV Module Installation Manual V.2311... - Page 13 Inner four holes External four holes (tracking system) HY-NT10/54GDF 3600/1600 HY-NT10/54BGDF 3600/1600 HY-P10/54GDF 3600/1600 HY-NT10/72GDF 1600/1600 3600/1600 HY-P10/72GDF 1600/1600 3600/1600 HY-NT10/78GDF 1600/1600 3600/1600 HY-NT12/66GDF 1600/1600 3600/1600 Note: Test load=ym (1.5 times safety factor)×design load. HY SOLAR PV Module Installation Manual V.2311...
-
Page 14: Fixing Method Of Clamp
430 ≤ D≤ 530 3600/1600 HY-NT 10/ 72GDF 430 ≤ D≤ 530 3600/1600 HY-NT 10/ 78GDF 480 ≤ D≤ 580 3600/1600 HY-NT12/66GDF 475 ≤ D≤ 525 3600/1600 Note: Test load=ym (1.5 times safety factor)×design load. HY SOLAR PV Module Installation Manual V.2311... - Page 15 ≥5mm, material 6005-T6, Rp0.2>225MPa, and Rm265MPa. Technical requirements and de- tails of pressing blocks can be consulted by after-sales service team of HY SOLAR. Grasping length is...
-
Page 16: Electrical Installation
1000W/m2, AM1.5, cell temperature 25 ° C). For the main electric performance parameters, maximum system voltage and Isc, Voc and Pmpp errors, please refer to the product datasheet or nameplate of HY SOLAR Module. In some circumstances, the current or voltage generated by the PV Module may be greater than the operating current or voltage in its standard testing environment (STC). - Page 17 PV module. When suspecting or finding that the diode is faulty, please contact HY SOLAR and do not try to open the junction box cover by your- self.
-
Page 18: Grounding
PV module. Holes marked with grounding marking on the frame can only be used for grounding, and cannot be used for PV module installation. Do not do electrical connections between modulesbefore grounding. HY SOLAR PV Module Installation Manual V.2311... -
Page 19: Maintenance
8) The PV module shall be cleaned by qualified professionals, and they must wear safety helmets, safety belts, plastic gloves, insulating shoes, protective clothing and other safety protection tools correctly before and during cleaning to prevent falling and electric shock. Revised version and date November 2023 HY SOLAR PV Module Installation Manual V.2311... - Page 20 Group Headquarter https://module.hoyuan.com No. 158 Nanhu Middle Road, BinhuDistrict, Wuxi City, Jiangsu Province, China E-mail Module Manufacturing Base Public：info@hoyuan.com China：cn@hoyuan.com ① No.118 Guibin Road, Jiangyin City, Jiangsu Overseas：overseas@hoyuan.com Province, China ② No. 99 Jiuzi Road, Dingcheng Town Economic Contact us Development Zone, Dingyuan County, Chuzhou +86 510-85958787 City, Anhui Province, China...
