- Page 1 HSL-32 Hibachi Griddle Operator Manual...
- Page 2 HSL-32 Hibachi Griddle Operator Manual April 2023 The content of this manual is the property of Paradise Grills International, Inc. All rights reserved. Any reproduction, in whole or in part, is strictly prohibited without express written consent of Paradise Grills International, Inc.
-
Page 3: Table Of Contents
Installation ....................11 Outdoor Rated Electric Cord ..............12 Safety Equipment ..................12 Griddle Covers ..................... 12 Griddle Island Preparation Paradise Grills Island Ventilation ................13 Griddle Location ....................... 14 Clearances ........................ 15 Surface Clearances ..................15 Custom Island Construction ................... 15 Planning Considerations ................ - Page 4 Adjust the Burner Orifice ..................40 Adjust Air Gap ......................40 Convert to Another Gas Type ................41 Griddle Diagram Limited Manufacturer’s Warranty Limited Warranty ...................... 45 Warranty Claim Submission ................... 47 ii • Contents HSL-32 Hibachi Griddle Operator Manual...
-
Page 5: Safety Considerations
EXPLOSION HAZARD – Do not use the griddle as storage area for flammable materials. Keep area clear and free from combustible materials, gasoline, and other flammable vapors and liquids. Failure to do so can result in death, explosion, or fire. HSL-32 Hibachi Griddle Operator Manual Safety Considerations • 3... -
Page 6: Gas Safety
The installation must conform with local codes, or, in the absence of local codes, with one of the following, as applicable: • National Fuel Gas Code, ANSI Z223.1/NFPA 54 • Natural Gas and Propane Installation Code, CSA B149.1 Propane Storage and Handling Code, CSA B149.2 • 4 • Safety Considerations HSL-32 Hibachi Griddle Operator Manual... -
Page 7: Natural Gas Supply Requirements
UL listed Overfill Protection Device (OPD) with a unique triangular hand wheel (Figure 1) • A collar to protect the cylinder threads on the customer supplied tank A QCC–1 fitting connection compatible with connection to outdoor cooking appliances • Figure 1 LP Cylinder Valve HSL-32 Hibachi Griddle Operator Manual Safety Considerations • 5... -
Page 8: Filling And Refilling Lp Gas Cylinders
If the leak cannot be stopped by closing the tank valve, leave the area and call the fire department immediately 7. Leak check the connections as described in the Leak Testing section below 6 • Safety Considerations HSL-32 Hibachi Griddle Operator Manual... -
Page 9: Leak Testing
With all burners off, open the gas source valve and spray a soap/water solution on all joints. Growing bubbles indicate leaking gas. Correct any leaks immediately. See Leak Test on page for more detail. HSL-32 Hibachi Griddle Operator Manual Safety Considerations • 7... -
Page 10: Transporting And Storing Lp Gas Cylinder
The gas supply must be turned off at the LP Gas supply cylinder and the LP Gas supply cylinder must • be disconnected from the regulator when this outdoor cooking gas appliance is not in use 8 • Safety Considerations HSL-32 Hibachi Griddle Operator Manual... -
Page 11: Specifications
Limited Lifetime Warranty on Warranty stainless steel housing; 5 years on burners (no burn through); 1 year (See page 45 for details) on all other parts Gas Type Available in LP or NG HSL-32 Hibachi Griddle Operator Manual Specifications • 9... -
Page 12: Customer Required Items
You must equip your griddle island with an appropriate mounting base or bracket to hold a 20 lb. LP cylinder upright, such as the examples shown in Figure 3: Figure 3 Example LP Cylinder Mounts 10 • Specifications HSL-32 Hibachi Griddle Operator Manual... -
Page 13: Gas Regulator
This does not apply to portable propane installations using a 20 lb. cylinder. Delivery company employees are not licensed electricians or plumbers and shall NOT install or connect any gas regulators or supply lines, electrical connections or lines, or plumbing. HSL-32 Hibachi Griddle Operator Manual Specifications • 11... -
Page 14: Outdoor Rated Electric Cord
Outdoor Rated Electric Cord Your Paradise Grills Outdoor Kitchen’s base griddle is pre-wired with a Ground Fault Circuit Interrupter (GFCI) electrical outlet installed. This electrical box has a hanging plug pigtail for connection to an existing GFCI electrical outlet for power supply. The customer must supply an outdoor-rated extension cord long enough to reach your chosen electrical outlet. -
Page 15: Griddle Island Preparation
Griddle Island Preparation Paradise Grills Island Ventilation BBQ Griddle Islands and Island Bars manufactured by Paradise Grills are portable and must be adequately vented as shown in Figure 4: a. Use the provided adjustable footers to ensure the island’s entire bottom edge, on all sides, is always at least 1”... -
Page 16: Griddle Location
Paradise Grills manufactured Islands use adjustable footers to allow sufficient airflow for effective ventilation (Figure 5). Figure 5 Air Gap Footers Griddle Location Consider important factors such as wind exposure and foot traffic patterns when choosing a location for the griddle. -
Page 17: Clearances
Do not install or operate the griddle in or on a recreational vehicle, trailer, boat, marine craft, or other moving conveyance. Paradise Grills makes no warranties or representations as to the safe and proper design, construction, ventilation, or installation of a custom-built griddle island. -
Page 18: Planning Considerations
Figure 6 illustrates examples of possible venting locations for custom-built griddle islands. Figure 6 Example Vent Locations 16 • Griddle Island Preparation HSL-32 Hibachi Griddle Operator Manual... -
Page 19: Custom-Built Island Cut-Outs
Please allow for a tolerance of +/- 1/8"; we recommend having your appliances in hand to measure before making final cutouts in your custom-built griddle island Figure 7 Example Island Cut-outs for Paradise Grills Appliances HSL-32 Hibachi Griddle Operator Manual... -
Page 20: Griddle Dimensions
Griddle Dimensions Figure 8 HSL-32 Dimensions 18 • Griddle Island Preparation HSL-32 Hibachi Griddle Operator Manual... -
Page 21: Griddle Assembly
File your claim for damages immediately with the delivery company, regardless of the extent of damage. Paradise Grills shall not be held liable for any damage that occurs during shipment. If damages are unnoticed until the product is unpacked, notify the delivery company immediately and file a concealed damage claim with them within 5 days of the delivery date. -
Page 22: Install The Griddle
Ensure the burner air shutter (Figure 10, left) is positioned appropriately for the gas source; the shutter should be opened to about 3/8” for LP gas or 1/8” for NG Figure 10 Burner Air Gap 20 • Griddle Assembly HSL-32 Hibachi Griddle Operator Manual... - Page 23 4. Carefully snip the zip ties around the electrical cable at the right rear corner of the griddle (Figure 13); DO NOT CUT THE WIRE Figure 13 Electrical Cable 5. Attach the gas supply line to the griddle per Connect Griddle to Gas Source procedure on page 25 HSL-32 Hibachi Griddle Operator Manual Griddle Assembly • 21...
- Page 24 If the griddle is not level or is unstable, use non-combustible shims under the outside lip to level and stabilize it • Proper leveling of your griddle is essential to its safe and proper operation; a non-level griddle will result in erratic burner combustion, and inefficient, uneven heating 22 • Griddle Assembly HSL-32 Hibachi Griddle Operator Manual...
-
Page 25: Griddle Setup
4. Plug in the LED light power supply and test the lights: press the light button to turn on the control knob lights; press again to turn them off (Figure 18) HSL-32 Hibachi Griddle Operator Manual Griddle Assembly • 23... -
Page 26: Electrical Precautions
Do not operate any outdoor cooking gas appliance with a damaged cord, plug, or after the appliance malfunctions or has been damaged in any manner; contact Paradise Grills to discuss service options, or call a licensed professional for inspection and repair Do not let the cord hang over the edge of a table or touch hot surfaces •... -
Page 27: Connect Griddle To Gas Source
Any use of the griddle without a proper gas regulator will void the warranty. HSL-32 Hibachi Griddle Operator Manual Connect Griddle to Gas Source • 25... -
Page 28: Connection
1. Ensure all griddle control valves are in the OFF position 2. Connect a suitable natural gas flex connector to the griddle regulator 26 • Connect Griddle to Gas Source HSL-32 Hibachi Griddle Operator Manual... -
Page 29: Lp Gas
Do not insert a tool or foreign object into any gas valve, which could cause damage and cause a leak. Leaking propane may result in explosion, fire, severe personal injury, or death. HSL-32 Hibachi Griddle Operator Manual Connect Griddle to Gas Source • 27... -
Page 30: Leak Test
Do not attempt to repair an LP cylinder valve if it is damaged. The cylinder must be returned to a proper LP tank supplier and replaced. Always conduct the leak test outdoors in a well-ventilated area. 28 • Connect Griddle to Gas Source HSL-32 Hibachi Griddle Operator Manual... - Page 31 4. If bubbles appear and/or grow, turn the gas source OFF, remove, reconnect and tighten the connection, and re-test 5. To leak test the burner orifices, remove the griddle plate and burners per the Install the Griddle procedure on page 20 HSL-32 Hibachi Griddle Operator Manual Connect Griddle to Gas Source • 29...
- Page 32 9. Repeat the leak check as needed; when there are no more leaks, wipe away the soap solution 10. Replace the burners and griddle plate and proceed 11. Do not use the griddle until all leaks are resolved 30 • Connect Griddle to Gas Source HSL-32 Hibachi Griddle Operator Manual...
-
Page 33: Operating The Griddle
Use barbecue tools with wood handles and insulated griddle mitts when operating the griddle. The use of accessories, regulators, or components not recommended by the appliance manufacturer may cause injuries and will void warranties. HSL-32 Hibachi Griddle Operator Manual Operating the Griddle • 31... -
Page 34: Lighting The Griddle
Failure to remove the griddle cover before lighting the burners, or not waiting 15 minutes to allow gas to clear if a burner does not light, may result in a fire or explosion causing serious bodily injury, death and/or property damage. 32 • Operating the Griddle HSL-32 Hibachi Griddle Operator Manual... - Page 35 10. Completely turn off the gas supply valve at the source NOTE: It is normal to hear a popping sound when the burners are turned off. Always keep the gas supply turned off when not operating the griddle. HSL-32 Hibachi Griddle Operator Manual Operating the Griddle • 33...
-
Page 36: Griddle Tips And Tools
Preheat the griddle before cooking, with the main burners on HIGH for at least 10 minutes. For cooking, use an infrared thermometer to fine tune the temperature for the food on the griddle. Do not leave the griddle unattended when the burners are lit. 34 • Operating the Griddle HSL-32 Hibachi Griddle Operator Manual... -
Page 37: Cleanup
When cooking is complete, clean the griddle per the Clean the Griddle Plate procedure on page 37, then turn off the burners and the gas supply. Put the hood on the griddle and cover the appliance. HSL-32 Hibachi Griddle Operator Manual Operating the Griddle • 35... -
Page 38: Cleaning And Maintenance
Routinely wipe down the exterior and interior of the griddle to remove grease and splatters. Use a good stainless steel cleaner to clean and polish the exterior surfaces. Doing so on a regular basis minimizes the 36 • Cleaning and Maintenance HSL-32 Hibachi Griddle Operator Manual... -
Page 39: Corrosive Environmental Conditions
Follow these recommended cleaning steps each time you finish cooking on your griddle: 1. Set both temperature control knobs to Low 2. Pour room temperature or warm water on griddle; if desired squeeze a lemon into the rinse water HSL-32 Hibachi Griddle Operator Manual Cleaning and Maintenance • 37... -
Page 40: Clean The Drip Tray
If the griddle was uncovered during rain, check the drip tray to drain any standing water. Preventive Maintenance Replacement parts are available from Paradise Grills International, Inc. Contact us at 800-604-2023 for assistance. At least twice a year conduct the following inspections to ensure safe griddle operation:... -
Page 41: Burner Inspection
Check and clean burner/venturi tubes every 6 months for insects and insect nests, and clean as needed. HSL-32 Hibachi Griddle Operator Manual Cleaning and Maintenance • 39... -
Page 42: Troubleshooting
Adjust Air Gap If adjusting the burner orifice doesn’t result in an appropriate flame, adjusting the air flow at the air mixers should help. 1. Remove the burners per the Install the Griddle procedure 40 • Troubleshooting HSL-32 Hibachi Griddle Operator Manual... -
Page 43: Convert To Another Gas Type
This procedure must be completed by a licensed plumber or gas professional. 1. Shut off and disconnect the gas source from the griddle 2. Remove griddle plate to expose the main burners HSL-32 Hibachi Griddle Operator Manual Troubleshooting • 41... - Page 44 Remove the old inlet and replace hand tight with new; do not overtighten Figure 31 Gas Inlets 8. Connect the gas supply per the Connection section 9. Complete a leak check of all affected gas fittings per the Leak Test procedure 42 • Troubleshooting HSL-32 Hibachi Griddle Operator Manual...
- Page 45 Align the knob opening with the shaft and press the knob back into position Figure 33 Flame Adjust Setscrew 12. Replace burner flame tamers and cooking grates 13. Repeat this process for both burners HSL-32 Hibachi Griddle Operator Manual Troubleshooting • 43...
-
Page 46: Griddle Diagram
Griddle Diagram 44 • Griddle Diagram HSL-32 Hibachi Griddle Operator Manual... -
Page 47: Limited Manufacturer's Warranty
Limited Manufacturer’s Warranty Limited Warranty Paradise Grills International, Inc. (PGI) warrants the HSL-32” HIBACHI GRIDDLE from the later of the date of purchase or delivery as follows: limited lifetime warranty on structural integrity of stainless steel housing to be free from original manufacturing defects;... - Page 48 EXPRESS OR IMPLIED WARRANTY OR GUARANTY GIVEN BY ANY PERSON OR ENTITY WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON PARADISE GRILLS. Paradise Grills shall not be liable to the ORIGINAL PURCHASER (or any other person or entity) for any incidental, indirect, special, reliance, general, ordinary, nominal, pain and suffering, lost profits, exemplary,...
-
Page 49: Warranty Claim Submission
Final Sales Agreement either: via email to Warranty.Claim@paradisegriddles.com; or (ii) via U.S. mail to Paradise Grills International, Inc., Attn: Warranty Claim, 640 Ocoee Business Parkway, Suite 80, Ocoee, Florida 34761. For more information, please call Paradise Grills International, Inc. at 800-604-2023.
