- Page 1 GS-SB1 Single Side Burner Operator Manual...
- Page 2 GS-SB1 Single Side Burner Operator Manual June 2023 The content of this manual is the property of Paradise Grills International, Inc. All rights reserved. Any reproduction, in whole or in part, is strictly prohibited without express written consent of Paradise Grills International, Inc.
-
Page 3: Table Of Contents
Damage Upon Delivery ................... 19 Install the Single Side Burner ................. 19 Gas Specifications ....................21 Connection ........................ 22 Natural Gas ....................22 LP Gas ......................23 Leak Test ........................25 GS-SB1 Single Side Burner Operator Manual Contents • i... - Page 4 Spiders and Other Insects ................. 32 Troubleshooting Adjust the Burner Orifice ..................33 Convert to Another Gas Type ................34 Single Side Burner Diagram Limited Manufacturer’s Warranty Limited Warranty ...................... 38 Warranty Claim Submission ................... 40 ii • Contents GS-SB1 Single Side Burner Operator Manual...
-
Page 5: Safety Considerations
3. Remove burner unit hood and open all access doors and drawers to release any accumulated gas vapor. 4. If a gas odor persists, keep away from your appliance and contact your gas supplier or fire department immediately. GS-SB1 Single Side Burner Operator Manual Safety Considerations • 3... - Page 6 Keep children and pets away from the appliance at all times. Do not allow children to operate the appliance. This accessory is for single family/residential use only, and not intended for commercial use. 4 • Safety Considerations GS-SB1 Single Side Burner Operator Manual...
-
Page 7: Gas Safety
Before and during pressure testing, the burner unit and its individual shutoff valve must be • disconnected from the gas supply piping system, and the burner unit must be isolated from the gas supply piping system by completely closing its individual manual shutoff valve GS-SB1 Single Side Burner Operator Manual Safety Considerations • 5... -
Page 8: Lp Cylinder Requirements
1. Turn all burner knobs to OFF and close the LP cylinder valve 2. Disconnect the regulator hose from the LP cylinder 3. Remove cylinder from the enclosure; have it replaced or filled at your local qualified LP gas dealer 6 • Safety Considerations GS-SB1 Single Side Burner Operator Manual... - Page 9 When attaching components, ensure all connections are secured and fully tightened to prevent leakage. Turn off the gas supply – Natural Gas or LP Gas – when burner unit is not in use. GS-SB1 Single Side Burner Operator Manual Safety Considerations • 7...
-
Page 10: Leak Testing
Do not store cylinders in a building, garage, or any other enclosed area • The gas supply must be turned off at the LP Gas supply cylinder when this outdoor cooking gas appliance is not in use 8 • Safety Considerations GS-SB1 Single Side Burner Operator Manual... -
Page 11: Specifications
Piezo Ignition System Limited Lifetime Warranty on Warranty stainless steel housing; 5 years on (See page 38 for details) burners; 1 year on all other parts Gas Type Available in LP or NG GS-SB1 Single Side Burner Operator Manual Specifications • 9... -
Page 12: Customer Required Items
You must equip your grill island with an appropriate mounting base or bracket to hold a 20 lb. LP cylinder upright, such as the examples shown in Figure 3: Figure 3 Example LP Cylinder Mounts 10 • Specifications GS-SB1 Single Side Burner Operator Manual... -
Page 13: Gas Regulator
STATE OF MASSACHUSETTS – Massachusetts requires all gas be installed by a plumber or gas fitter carrying the appropriate Massachusetts license. All permanently-installed natural gas or propane GS-SB1 Single Side Burner Operator Manual Specifications • 11... -
Page 14: Outdoor Rated Electric Cord
Outdoor Rated Electric Cord Your Paradise Grills Outdoor Kitchen’s base burner unit is pre-wired with a Ground Fault Circuit Interrupter (GFCI) electrical outlet installed. This electrical box has a hanging plug pigtail for connection to an existing GFCI electrical outlet for power supply. -
Page 15: Grill Island Preparation
Grill Island Preparation Paradise Grills Island Ventilation Grill islands and Island Bars manufactured by Paradise Grills are portable and must be adequately vented as shown in Figure 4: a. Use the provided adjustable footers to ensure the island’s entire bottom edge, on all sides, is always at least 1”... -
Page 16: Single Burner Location
Paradise Grills manufactured Islands use adjustable footers to allow sufficient airflow for effective ventilation (Figure 5). Figure 5 Air Gap Footers Single Burner Location Consider important factors such as wind exposure and foot traffic patterns when choosing a location for the burner unit. -
Page 17: Clearances
Do not install or operate the Single Burner in or on a recreational vehicle, trailer, boat, marine craft, or other moving conveyance. Paradise Grills makes no warranties or representations as to the safe and proper design, construction, ventilation, or installation of a custom-built grill island. - Page 18 (Figure 6); the burner unit edges must rest on the lip of the frame. Figure 6 Burner Unit fits in Island Frame 16 • Grill Island Preparation GS-SB1 Single Side Burner Operator Manual...
-
Page 19: Custom-Built Island Ventilation
Please allow for a tolerance of +/- 1/8"; we recommend having your appliances in hand to measure before making final cutouts in your custom-built grill island Figure 8 Example Island Cut-outs for Paradise Grills Appliances GS-SB1 Single Side Burner Operator Manual... -
Page 20: Single Side Burner Dimensions
Single Side Burner Dimensions Figure 9 GS-SB1 Dimensions 18 • Grill Island Preparation GS-SB1 Single Side Burner Operator Manual... -
Page 21: Single Side Burner Assembly
File your claim for damages immediately with the delivery company, regardless of the extent of damage. Paradise Grills shall not be held liable for any damage that occurs during shipment. If damages are unnoticed until the product is unpacked, notify the delivery company immediately and file a concealed damage claim with them within 5 days of the delivery date. - Page 22 7. Ensure the burner cover is in place on the mounting pins (below left) Figure 11 Install cover and grate 8. Align the two grate mounting pins with the holes and insert into place (above right) 20 • Single Side Burner Assembly GS-SB1 Single Side Burner Operator Manual...
-
Page 23: Gas Specifications
Any use of the burner unit without a proper gas regulator will void the warranty. GS-SB1 Single Side Burner Operator Manual Single Side Burner Assembly • 21... -
Page 24: Connection
To connect the burner unit to a natural gas source: 1. Ensure all burner unit control valves are in the OFF position 22 • Single Side Burner Assembly GS-SB1 Single Side Burner Operator Manual... -
Page 25: Lp Gas
2. Inspect the head of the gas cylinder and head of the regulator valve to ensure there is no debris; use a soft brush to remove any debris GS-SB1 Single Side Burner Operator Manual Single Side Burner Assembly • 23... - Page 26 9. Lift the burner unit as needed to gain access to the regulator and gas connection point in the rear 10. To disconnect the LP gas tank, turn off the main cylinder valve; rotate the black coupling nut counterclockwise until disengaged 24 • Single Side Burner Assembly GS-SB1 Single Side Burner Operator Manual...
-
Page 27: Leak Test
On LP systems, turn the cylinder valve knob counterclockwise one turn to open 3. Spray the soapy water solution on all joints of the gas delivery system (Figure 17) GS-SB1 Single Side Burner Operator Manual Single Side Burner Assembly • 25... - Page 28 9. Repeat the leak check as needed; when there are no more leaks, wipe away the soap solution 10. Replace the burner and grate and proceed 11. Do not use the burner unit until all leaks are resolved 26 • Single Side Burner Assembly GS-SB1 Single Side Burner Operator Manual...
-
Page 29: Operating The Single Burner
Use tools with wood handles and insulated burner unit mitts when operating the unit. The use of accessories, regulators, or components not recommended by the appliance manufacturer may cause injuries and will void warranties. GS-SB1 Single Side Burner Operator Manual Operating the Single Burner • 27... -
Page 30: Lighting The Burner Unit
15 minutes to allow gas to clear if a burner does not light, may result in a fire or explosion causing serious bodily injury, death and/or property damage. 28 • Operating the Single Burner GS-SB1 Single Side Burner Operator Manual... - Page 31 9. Completely turn off the gas supply valve at the source NOTE: It is normal to hear a popping sound when the burner isturned off. Always turn off the gas supply when not operating the burner unit. GS-SB1 Single Side Burner Operator Manual Operating the Single Burner • 29...
-
Page 32: Cleaning And Maintenance
Routinely wipe down the exterior and interior of the burner unit to remove grease and splatters. Use a good stainless steel cleaner to clean and polish the exterior surfaces. Doing so on a regular basis minimizes the 30 • Cleaning and Maintenance GS-SB1 Single Side Burner Operator Manual... -
Page 33: Corrosive Environmental Conditions
Clean the Single Burner Routinely wash with warm soapy water and apply a good stainless steel polish to protect the burner unit exterior. Keep the burner unit covered when not in use. GS-SB1 Single Side Burner Operator Manual Cleaning and Maintenance • 31... -
Page 34: Preventive Maintenance
Preventive Maintenance Replacement parts are available from Paradise Grills International, Inc. Contact us at 800-604-2023 for assistance. At least twice a year conduct the following inspections to ensure safe burner unit operation: Ventilation Ensure burner area is clear and free from combustible materials, gasoline, and other flammable •... -
Page 35: Troubleshooting
3. Replace the knob by aligning the flat part of the knob opening with the flat top of the shaft and press into place 4. Test the burner and readjust as needed GS-SB1 Single Side Burner Operator Manual Troubleshooting • 33... -
Page 36: Convert To Another Gas Type
(Figure 21) NOTE: Brass fittings are fragile. Very little pressure is needed for a secure connection. 5. Replace the orifice with the change-out orifice; follow these precautions: 34 • Troubleshooting GS-SB1 Single Side Burner Operator Manual... - Page 37 11. Open the gas supply, light the burner, and test for proper flame height; flame should stand between 1/2” – 1” on LOW and 1 1/2” – 2” on HIGH a. Light the burner unit and rotate temp knob to LOW flame setting GS-SB1 Single Side Burner Operator Manual Troubleshooting • 35...
- Page 38 Align the knob opening with the shaft and press the knob back into position Figure 24 Flame Adjust Setscrew 12. Replace the cooking grate and ensure the burner unit is fully seated into the grill island 36 • Troubleshooting GS-SB1 Single Side Burner Operator Manual...
-
Page 39: Single Side Burner Diagram
Single Side Burner Diagram NOTE: The cover handle is attached to the cover. GS-SB1 Single Side Burner Operator Manual Single Side Burner Diagram • 37... -
Page 40: Limited Manufacturer's Warranty
Limited Manufacturer’s Warranty Limited Warranty Paradise Grills International, Inc. (PGI) warrants the GS-SB1 Single Side Burner from the later of the date of purchase or delivery as follows: limited lifetime warranty on structural integrity of stainless steel housing to be free from original manufacturing defects;... - Page 41 EXPRESS OR IMPLIED WARRANTY OR GUARANTY GIVEN BY ANY PERSON OR ENTITY WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON PARADISE GRILLS. Paradise Grills shall not be liable to the ORIGINAL PURCHASER (or any other person or entity) for any incidental, indirect, special, reliance, general, ordinary, nominal, pain and suffering, lost profits, exemplary,...
-
Page 42: Warranty Claim Submission
Warranty.Claim@paradisegrills.com; or (ii) via U.S. mail to Paradise Grills International, Inc., Attn: Warranty Claim, 640 Ocoee Business Parkway, Suite 80, Ocoee, Florida 34761 For more information, please call Paradise Grills International, Inc. at 800-604-2023. 40 • Limited Manufacturer’s Warranty...
