Summary of Contents for SCM SCM-36100
- Page 1 User Manual Golf Cart Lithium Ion Battery Attn: Mr Izak Krige Tel: +27 82 558 8206 Email: battery@scmsystems.co.za Web: www.scmsystems.co.za...
- Page 2 Welcome to SCM Systems products SCM Systems provides safe deep cycle golf cart batteries. Our golf cart lithium battery packs are a type of Lithium iron phosphate battery (LiFePO4), it is a reliable power source that doesn’t fade over time. The batteries are the best replacement for the lead-acid battery, and are available for drop-in replacement in the Club Car, EZ-GO and other makes of golf carts.
-
Page 3: Battery Specification
Battery Specification Model SCM CODE SCM-36100 SCM-48100 Technical Nominal voltage Nominal capacity 100Ah 100Ah Life cycles >2000 times >2000 times Parameter Self discharge Max 3% per month Max 3% per month Power support 3 Rounds Golf 4 Rounds Golf Standard charge... -
Page 4: Safety Operation
Safety Operation Improper handling of batteries and electrical components can result in serious injury. ⚫ Do not remove the battery pack cover. Do not attempt to remove battery cells or battery cables. ⚫ Do not use the battery pack without the control module installed. All battery and electrical service must be performed by an authorized service facility and personnel. - Page 5 Storage ⚫ For storage over one month, place the battery in a dry and ventilated room that is 32°F~95°F. ⚫ Do not store near corrosive material, fire, and heat sources. ⚫ In order to avoid over discharge, for long-term storage, the power must be turned off and the SOC is kept above 60% to avoid over discharge.
- Page 6 3.Open Charger box and take out the charger– Note Instruction manual 4.Unbox the battery, connect the battery manager, connect the charger to the blue Anderson connector. Charge until 100% full. The indicator light on the charger will turn green. 5.The battery rests on a base board, which is supplied with every battery. It has to be cut to size and painted. The battery is lowered into the cart and screwed onto the base board which is fixed with bolts and nuts.
- Page 7 6. The on-board charge port is removed and replaced with a new charge port that contains the blue Anderson connector that is on the battery charging lead. Various charge port configurations are available. Small round, bigger round, square and oblong. 7.
- Page 8 Only authorized personnel are allowed to operate or make adjustments to the battery! Extended storage without recharging or repairs done by an unauthorized person or modification. This warranty is in lieu of all other express warranties. SCM Systems will not be liable for consequential or incidental damage. 7 / 8...
