AS1503 (3 PRO)

Scan Reader Pen

User Guide

Thank you for purchasing the Scan Reader Pen.

In order to use the product safely and correctly, please read

this manual carefully before starting to use the product.

In addition,this manual contains a warranty card,

so please keep it in a safe place.The company reserves the

right to revise this manual.

Table of Contents

Need help?

Do you have a question about the AS1503 and is the answer not in the manual?

Questions and answers

Summary of Contents for NEWYES AS1503

Page 1 AS1503 (3 PRO) Scan Reader Pen User Guide Thank you for purchasing the Scan Reader Pen. In order to use the product safely and correctly, please read this manual carefully before starting to use the product. In addition,this manual contains a warranty card, so please keep it in a safe place.The company reserves the...
Page 2: Table Of Contents
Contents Introduction ······················ Equipment Handling ··············· ···················· About Cleaning ··········· About the Built-in Battery ···················· About Charging About Wi-Fi Function ··············· Package Contents ·················· Product Overview ·················· ···················· Body Structure ·················· Charging Method ··················· The Main Screen First Operation ···················· Turn on The Power ·················...
Page 3: Introduction
Introduction Thank you for purchasing our product. Please be sure to read this manual to maximize the performance of this product and use it safely The illustrations and screen diagrams in this manual may be diﬀerent from the actual ones. When using overseas, please check the laws and regulations of the country/region and other conditions.
Page 4: Equipment Handling
Equipment Handling This unit is not waterproof. Do not use it in places with high temperature and humidity (working temperature 5°C to 35C, humidity 45% to 85%)and dusty places such as bathrooms, kitchens, and toilets. vibration. lf excessive force is applied to the monitor, it may damage the internal board and cause malfunction, so do not place it under heavy objects.
Page 5: About Charging
When you use it for the ﬁrst time or have not used it for a long time, please charge the battery before use. A message will be displayed when the battery is low, and it will turn oﬀ after a period of time. lf you start charging when the battery is empty, charging may not start immediately when you turn on the power.In this case, please charge for a while, and then turn on the...
Page 6: Package Contents
Package Contents The package contains the following items. Please conﬁrm before use. Scan Reader Pen User Guide (including warranty) USB Charging Cable Storage Bag ※The appearance and speciﬁcations of accessories are subject to improvement without notice. Product Overview Scan Reader Pen is an artiﬁcial intelligence hardware product that integrates multiple technologies such as speech recognition, OCR (character recognition)，...
Page 7: Charging Method
Power button (Turn on/oﬀ the power, turn oﬀ/on the ① screen.) ② Speech translation/ volume key (+) ③ Speech translation/ volume key (-) ④ 2.98-inch touch screen (The protective ﬁlm is attached to the machine when it leaves the factory. Tear it oﬀ before use) ⑤...
Page 8: The Main Screen
When connecting, please check the shape of the charging device connector, and then proceed to the correct direction.lf you cannot connect successfully， please do not force the connection. Standby time: about 80 hours Use time: about 3 hours ※Depending on the operating environment and settings, it may become shorter.
Page 9: First Operation
Dyslexia Aid ④ Read the word of the text one by one. Dyslexia Recording ⑤ Tap the icon to start recording. Recording Favorites ⑥ The translation result selected in the favorites folder is displayed in the list. Only the translation results of Favorites "text translation"...
Page 10: Language Settings
Power oﬀ / Restart If you press and hold the "Power button" (3 seconds or more) while the main unit is running, a conﬁrmation message will be displayed on the LCD screen. To turn oﬀ the power, please click "power oﬀ". To restart, click "Reboot".
Page 11: Setup Complete
Setup Complete After the ﬁrst time setup is completed, then you can use the machine for each function. Text Dictionary Speech Text Dyslexia Recording Translation Translation Scanner How to Use How to Scan Correctly recognize the character you are looking for. Please keep the angle between 90°...
Page 12: Translation
Translation Text Translation The text scanned by this machine can be translated.lt supports online scanning and recognition in 55 Text languages, and oﬄine scanning and Translation recognition in Chinese/English/ Japanese/Korean/German/French/ Italian/Spanish/Dutch/Filipino/Indonesian/Russian/ Finnish/Danish/Norwegian/Czech/Romanian. Setting ※The following is an example of translating English to Japanese.
Page 13: Collins English Dictionary
After the translation is completed, the text will ④ be displayed on the screen and read aloud automatically. Clicking the "Original"/" Translation" button will read the corresponding language. Click the" " button in the upper right ⑤ corner to add the scanned content and translation results to "Favorites", You can view it from [Favorites] by adding to favorites.
Page 14: Speech Translation
Click the top menu to choose the dictionary. Collins English Japanese Please scan as vertically as posslble Choose the Dictionary to use it. Dictionary Collins English Dictionary Collins English Japanese collins English Arabic Speech Translation This function can translate voice calls and can translate 112 languages in real time.
Page 15 English(US) Japanese Dialogue translation Please long press the corresponding voice button to speak, then release it to translate Speaking language Slide the screen to select a language Press and hold the volume button (-) and talk to ③ the device in "English". Release the button after speaking.
Page 16 <Notes when using Speech translation> To ensure accurate translation,please press and hold the translation key for 1 second,take a breath, and then start speaking Check the screen to see if the conversation is correctly recognized. lf the word is recognized as incorrect, it will be translated incorrectly.
Page 17: Text Scanner
Text Speech Characters can be extracted from documents by scanning with this machine. Text Scanner Click" " on the right side of the screen to ① scan the document. Please click + to add excerpts Offline support for 13 languages such as Chinese,Japanese and Korean ？...
Page 18 Website:https://ai.newyes.com/scanpenh5 ?penld=ac3f5045e079d456&channel=000049 1.Scan the code or manually enter the URL to open the page 2.Click " Start Scanning" (Save the URL on the computer, then you don't need to type the URL next time.) Start Scanning There are 55 languages for scanning on line, and 13 ⑤...
Page 19: Dyslexia Aid
Dyslexia Aid How to use it? Dyslexia Click Dyslexia Aid Dictionary Speech Text Dyslexia Recording Favorites Setting Translation Scanner Click on this icon Default setting is to read the whole sentence. (Sentence) Sentence Word Text Reader Scan the text and it will read the word one by one. You can tap any word to restart the reading from that word.
Page 20: Recording
You can click “Word” on the top to read the targeted word and check it in the dictionary. Icons on the right Setting: On the setting, you can choose British or America pronounce; replace or append sentences; reading speed; word and punctuation pause time. Dictionary: Check the translation of the word you click on in the Collins English Dictionary.
Page 21: Favorites
Favorites [Note] Only "Text Translation" and " Dictionary" can be added as favorites. Favorites On the main screen, click "Favorites" ① Display the translation results added as ② favorites in "Text Translation"/"Dictionary" Tap to read aloud. tap to cancel the ③...
Page 22 Options Display Explanation You can choose to turn on the Wi-Fi ON/OFF button and WIFI choose the Wi-Fi SSID that can surf the lnternet, enter thepassword. Turn on/oﬀ Bluetooth. Only Bluetooth Bluetooth headsets are supported. You can adjust the speaker volume and speed ofthis unit by sliding left and...
Page 23 Options Display Explanation When operating this unit, you can choose Holding whether it is suitable for left-handed or Direction right-handed use. Select the display language of this unit. You can set Chinese, Device English, Japanese, Language Korean, Spanish, French, German, ltalian.
Page 24: Product Specifications
Product Speciﬁcations Product name Scan Reader Pen Model AS1503 MTK6580、 Ouad core、 13GHz TFBGA520/P0.4/B0.25/102X11 Operating Android 8.1 System WIFI 2.4GHz: 802.11b/g/n Native Memory 16GB (ROM) Run Memory (RAM) 2.98-inch LCD Display DOTS:260*800 Bluetooth Bluetooth 4.0 Playback MEMS microphone Microphone 1W x1...
Page 25: Troubleshooting
Storage -20°C~+60°C Temperature Range Continuous About 3 hours Running Time Continuous About 80 hours Standby Time Product Size 144*33*14mm/ 5.66*1.29*0.55inch Weight 80g/0.17lb Material Plastic+Metal Troubleshooting lf a problem occurs while using this machine, please check the following items before sending it for repair. lf you have tried the following items but the problem persists, please contact your dealer or customer support center.
Page 26 Can't connect · Can the selected Select a Wi-Fi SSID · to Wi-Fi Wi-Fi be used on that can use the the Internet? Internet and enter Is the password the password. · · correct? Check the password Is the WiFi that and re-enter it.
Page 27 Slow · Restart the Wi-Fi translation function (router,home network, etc.). · Check the signal strength of the connected Wi-Fi. · If the Wi-Fi signal is weak, move to another location and reconnect where the signal is strong. · Connect to Wi-Fithat can use otherInter- net.
Page 28: Warranty Policy
We are not liable for any special, accidental or indirect loss or damage caused by negligence in contracts or civil disputes. This warranty applies to all regions of the country. Warranty Card Product Name:AS1503 Name Customer Address Store name Customer...
Page 29: Fcc Statement
Customer after-sales support Consultation via email E-mail:service@newyes.com ※After receiving the email, we will reply you as soon as possible. FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmfuln interference.
