- Page 1 LED Light Meter System User Guide Excelitas Canada Inc. 2260 Argentia Road Mississauga (ON) L5N 6H7 Canada +1 905.821.2600 www.excelitas.com 035-00434R Rev. 3...
- Page 2 User Guide USER GUIDE 035-00434R Excelitas Canada Inc. 2023 All rights reserved No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in and form by any means without the prior written consent of Excelitas Canada Inc.
- Page 3 User Guide Trademarks: OmniCure® is a trademark of Excelitas Canada Inc. All rights reserved. All other product names are trademarks of their respective owners. All product or software photos shown are for reference only and are subjected to change without notice. Made in Canada.
-
Page 4: Table Of Contents
Safety and Electromagnetic Compatibility: ..............15 12.2 China RoHS ........................16 12.3 WEEE Directive ......................16 13 Warranty ........................ 17 14 Returning Equipment to Excelitas Technologies for Service ......18 15 Contact Information ....................19 http://www.excelitas.com/omnicure Excelitas Canada Inc. 2023 All rights reserved. Page 3... - Page 5 User Guide 16 Replacement Parts and Accessories ..............20 Figure 1 LED Light Meter ......................4 Figure 2 LED Light Sensor Connection ..................5 Figure 3 USB Connection ......................5 Figure 4 LED Light Sensor ......................8 Figure 5 LED Light Sensor Aperture ..................8 Figure 6 LED Light Meter GUI Control Panel ................11 Figure 7 Lithium Battery Compartment ..................13 http://www.excelitas.com/omnicure...
-
Page 6: Introduction
1 Introduction The main purpose of this LED Light Meter System is to provide accurate absolute power/irradiance measurements for various lens options and wavelengths of an Excelitas LX series UV LED spot curing system or any other commercially available UV LED spot curing system. This product will complement the Excelitas LX series and will also cater to commercially available LED UV spot curing systems. -
Page 7: Safety Precautions
Safety Precautions DIN Multi Pin Connection Port For External Sensors (for use only with sensors supplied by Excelitas Technologies) For using the Sensor, connect cable to this port. WARNING When using LED Heads do not stare directly at the LED Aperture(s). This may be harmful, resulting in eye injury. - Page 8 The lithium battery supplied in this system DOES NOT contain: mercury, lead, manganese or cadmium. Substitution of any other type of battery is not recommended and may void warranty. Caution The detection window operational life can be significantly shortened if it is handled incorrectly.
-
Page 9: System
3 System LED Light Meter (model# LM2011, LM2011-xx) LED Light Sensor with removable Aperture (model# LS100, LS200) Component Part Number 010-00281R, LED Light Meter System 019-00427R Lithium Battery (qty. 2) 055-00007R 4 LED Light Meter Features LCD DISPLAY PEAK HOLD WAVELENGTH SELECT POWER... - Page 10 LED LIGHT SENSOR CONNECTION Figure 2 LED Light Sensor Connection CONNECTION Figure 3 USB Connection http://www.excelitas.com/omnicure Excelitas Canada Inc. 2023 All rights reserved Page 5...
-
Page 11: Power On/Off
Power ON/OFF Press ‘ON/OFF’ button to switch on the unit. The power on sequence will flash full 4.1.1 screen information for 5 seconds and then display current wavelength. 4.1.2 The Meter will auto power off after 5 minutes (system will remember the last mode and wavelength on power up). -
Page 12: Power/Irradiance
Power/Irradiance 4.4.1 This button will toggle between the Power and Irradiance mode. Sensor Aperture Light Meter Select Power Removed Power Irradiance Installed Irradiance The display will show “ ” if the output power exceeds 500mW or 25W/cm² (when 4.4.2 used with a LS100) The display will show “... - Page 13 DETECTION WINDOW WITH THREADED APERTURE INSTALLED DETECTION WINDOW WITH THREADED APERTURE REMOVED Figure 4 LED Light Sensor – REMOVE APERTURE COUNTER CLOCK WISE DIRECTION TIGHTEN APERTURE CLOCK WISE DIRECTION Figure 5 LED Light Sensor Aperture http://www.excelitas.com/omnicure Excelitas Canada Inc. 2023 All rights reserved Page 8...
-
Page 14: Calibration
6 Calibration 6.1.1 It is recommended that the LED Light Meter system be calibrated every 12 months to ensure valid measurements. The calibration is traceable to NRC and a calibration certificate is included at each calibration cycle. 6.1.2 Irradiance calibration is only valid with the correct aperture supplied, Exchanging other apertures invalidates the calibration. -
Page 15: Installation And Basic Operation
7 Installation and Basic Operation: XY Alignment Tool: Provisions for an alignment tool/fixture is recommended to eliminate the alignment challenges which may be encountered to capture accurate peak power or irradiance measurement. 7.1.1 Connect the LED Light Sensor to the LED Light Meter via the DIN Multi-pin Connection. -
Page 16: Gui Operation
8 GUI Operation Driver Installation Minimum Computer Specifications. 600+ MHz Intel Compatible processor. Windows XP, Windows Vista, Windows 7. 256 Mb for RAM. 10 Mb for software installation. 20 Mb for data storage. SVGA video 1024x768 resolution, 16 bit color. ... -
Page 17: Care And Maintenance
8.2.4 Click Exit to exit out of the program. 9 Care and Maintenance General 9.1.1 The LED Light Sensor can be stored in its original individual packaging, or in the plastic case with the LED Light Meter – there is a special cut-out in the foam insert for this purpose. -
Page 18: Lithium Batteries
9.3.3 Use the batteries supplied by Excelitas Technologies, do not substitute with another brand. The batteries in the Meter are not standard AA batteries. The voltage of the standard AA batteries will not supply enough power to operate the LED Light Meter. -
Page 19: Technical Specifications
10 Technical Specifications Wavelength Range: 5 wavelengths are user-selectable within the range of 320nm - 750nm Irradiance (LS100): 50mW/cm² - 25W/cm² 1mW –500mW Power Range (LS100): Irradiance (LS200): 50mW/cm² - 40W/cm² 1mW –2000mW Power Range (LS200): Measurement Resolution: 1% of displayed reading (worst case) Sensor Uncertainty: The uncertainty is claimed to be ±10.0%. -
Page 20: Regulatory Compliance
12 Regulatory Compliance 12.1 Safety and Electromagnetic Compatibility: The LED Light Meter system (model # LM-2011/LM-2011-xx/LS100/LS200), has been tested and found to comply with product safety and electromagnetic compatibility requirements. For a complete list of tests and for certification details, please contact your OmniCure representative or visit: https://www.excelitas.com/product/omnicure-lx500-led-uv-radiometer-and-calibration-kit CE Marking... -
Page 21: China Rohs
12.2 China RoHS The symbol above indicates that this product is in compliance with China RoHS requirements. Hazardous Substances Hexavalent Polybrominated Polybrominated Part Name Lead Mercury Cadmium Chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE) Printed circuit board assemblies This table is compiled according to SJ/T 11364. -
Page 22: Warranty
13 Warranty Excelitas Technologies warrants, to the original purchaser for a period of one (1) full year, calculated from the date of purchase, that the equipment sold is free from defects in material and workmanship. -
Page 23: Returning Equipment To Excelitas Technologies For Service
1. Original packaging should be kept for future use. Please use this packaging when sending equipment to Excelitas Technologies for servicing or calibration to protect the sensitive optical and electronic components. It is safe to ship the LED Light Detector in the plastic carrying case with the LED Light Meter provided it is placed in its foam cut-out. -
Page 24: Contact Information
15 Contact Information Excelitas Canada Inc. 2260 Argentia Road Mississauga, Ontario L5N 6H7 CANADA Tel.: +1 905 821-2600 Toll: +1 800 668-8752 (USA and Canada) Fax: +1 905 821-2055 https://www.excelitas.com/product/omnicure-lx500-led-uv-radiometer-and-calibration-kit https://www.excelitas.com/ox_service_request_form https://www.excelitas.com/omnicure-x-cite-inquiries Technical Assistance: techsupport@excelitas.com https://www.excelitas.com/ox_service_request_form For a complete listing of Authorized OmniCure Distributors and Service Centres, please go to https://www.excelitas.com/dealer-search http://www.excelitas.com/omnicure Excelitas Canada Inc. - Page 25 16 Replacement Parts and Accessories Replacement components can be purchased directly from Excelitas Technologies. For ordering and pricing information, contact the Inside Sales Department at: Tel.: +1 905 821-2600 Toll: +1 800 668-8752 (USA and Canada) https://www.excelitas.com/contact Part Number Description...
