Summary of Contents for Bally Modularm 75
- Page 1 INSTRUCTION MANUAL Modularm 75 Install & Operation IM-419-13 Installation & Operating Instructions for Modularm 75 REV: 3/2013 IM-419-13...
- Page 2 MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 MODEL 75, 75B & 75C INSTALLATION & OPERATING INSTRUCTIONS MODULARM MODEL 75 (B) QUICK SETUP INSTRUCTIONS 1) SLIDE DISPLAY RESET SWITCH (A) TO LEFT TO STOP DISPLAY FROM BLINKING. 2) SELECT FAHRENHEIT OR CENTIGRADE WITH DISPLAY MODE SWITCH (B).
-
Page 3: Table Of Contents
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 TABLE OF CONTENTS MODEL 75 & 75B GENERAL DESCRIPTION ......1 CONTROLS, INDICATORS &... -
Page 4: Controls, Indicators & Functions
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 CONTROLS, INDICATORS, & FUNCTIONS (REFER TO FRONT COVER) DISPLAY RESET, ALARM TEST SWITCH – Holding switch momentarily to left stops Digital Readout from blinking and provides constantly on temperature display. Holding switch to right provides TEST MODE. -
Page 5: Setting Up The Alarm
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 Run the probe into the monitored compartment and locate the sensor in a spot which will typify the average ambient temperature. Recommended location is in front of the blower on the ceiling in the center of the room. -
Page 6: Operating Sequence Of Alarm
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 EXAMPLE: SET FOR 70 MINUTES DELAY (BLACK SQUARE = PUSHED IN) OPERATING SEQUENCE OF ALARM Once properly installed and set up, virtually all user alarm functions are controlled by the ALARM CONTROL SWITCH. -
Page 7: Model 75C Control Instructions
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 3) After probe has stabilized for a few minutes, use the CALIBRATION SWITCHES to change the displayed temperature agrees with reference. 4) After calibration is complete, check and readjust setpoints. MODEL 75C CONTROL INSTRUCTIONS The Model 75C expands the functions of the regular Model 75 by offering temperature control capability. -
Page 8: Special Options
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 ONCE ADJUSTED, RETURN THE JUMPER TO THE PROBE POSITION IN ORDER TO DISPLAY PROPER MONITORED TEMPERATURE. SPECIAL OPTIONS 1) PANIC ALARM: This option provides a means by which the alarm will annunciate when personnel are inadvertently locked in a compartment. -
Page 9: Wiring Diagram
MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 WIRING DIAGRAM TYPICAL REMOTE NOTIFICATION APPLICATIONS:... - Page 10 MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 ADDENDUM: ADDITIONAL INSTRUCTIONS FOR UL LISTED VERSIONS OF MODEL 75 AND 75B TEMPERATURE ALARMS. THE MODEL 75 AND 75B TEMPERATURE ALARMS ARE NOW OFFERED AS UL LISTED PRODUCTS (FILE #E187350).
- Page 11 MODULARM CORPORATION 61 MALL DRIVE, COMMACK, NY 11725 TEL 631-864-3860 ∙ FAX 631-864-3863 SPECIFICATIONS: DIMENSIONS: SURFACE MOUNT - 9”L x 4”W x 1.8”D FLUSH MOUNT – FLANGE DIMENSION – 10.375”L x 4.75”W CUTOUT DIMENSION - 9.375:l x 4.375”W ENCLOSURE: DRAWN ALUMINUM WITH STAINLESS STEEL FACEPLATE. TEMPERATURE RANGE: -40ºF TO 212ºF, -40ºC TO 100ºC.* SETPOINT RANGE: -40ºF TO 120ºF, -40ºC TO 50ºC.* TIME DELAY: 10 TO 150 MINUTES IN 10 MINUTE INCREMENTS.*...
