Page 1 YO Analog User guide v3.2...
Page 2: Release Notes
Added speciﬁcations of the device, Installation instruction, 26.08.2022 upgraded device conﬁguration and operation of the device, updated payloads description, added compliance statement Added conﬁguration node with Yosensi Management 20.07.2023 Platform. Changed description of connecting nodes with Yosensi Management Platform. 26.10.2023 Added conﬁguration with Yosensi Mobile App.
Page 3: Table Of Contents
Installation guide Operation IoT system components Device conﬁguration Conﬁgurable parameters Parameters description Conﬁguration node with Yosensi Management Platform Configuration node with Yosensi mobile app Connecting node with network Yosensi Management Platform configuration Adding a node manually Adding node via Bluetooth...
Page 4: Product Description
By means of the application algorithm developed by the Yosensi Team, and despite the limitations of data transfer in the LoRaWAN network, it is possible to establish accurate mapping of current and power consumption.
Page 5: Physical Interfaces
LoRaWAN communication: connecting to LoRaWAN network. Buttons YO Analogis equipped with one reset button inside the device on the PCB board under the inscription “reset” shown on the device. It is possible to press it with a thin stick. www.yosensi.io...
Page 6: Specifications
Height: 90 mm Width: 71,2 (4 pole) mm Depth: 58 mm Colour Light grey Mounting method 35 mm DIN rail Vertical (can be screwed to the wall) Enclosure material Polycarbonate Fire resistance class UL94-VO Level of protection IP20 Weight 127 g www.yosensi.io...
Page 7: Operating Conditions
6 - 30 V DC 5 - 21 V AC Power consumption Typical: 80 mA DC (12 V DC) Maximum: 180 mA DC (12 V DC) Measured values MEASUREMENT RANGES Accuracy Parameter Measuring range Current 4-20 mA Voltage 0-10 V www.yosensi.io...
Page 8: Current
IoT devices. YO Analog can monitor up to 6 signals depending on the conﬁguration. Figure 4 Current ﬂow on ﬁrst channel of the device exemplary chart. Figure 5 Current ﬂow on the second channel of the device exemplary chart. www.yosensi.io...
Page 9: Voltage
This helps customers to monitor control signals in the industry network connected to the IoT devices. YO Analog can monitor up to 6 signals depending on the conﬁguration. Figure 7 Voltage on the fourth channel of the device exemplary chart. www.yosensi.io...
Page 10 YO Analog User guide v3.2 page 10/30 Figure 8 Voltage on the ﬁfth channel of the device exemplary chart. Figure 9 Voltage on the sixth channel of the device exemplary chart. www.yosensi.io...
Page 11: Installation
To maintain the level of protection device cover screws must be properly tightened. Device shouldn’t be used without cover. Any actions inside the device's enclosure (excluding replacing batteries) must be performed by trained personnel only. Clean the device only with damp cloth. Device is intended for outdoor and indoor use. www.yosensi.io...
Page 12: Installation Guide
The conﬁguration is possible via BLE. 2. Connect a 4-20 mA signal source and/or a 0-10 V voltage measuring cable to the individual inputs of the device according to the polarity shown on the enclosure label. www.yosensi.io...
Page 13 User guide v3.2 page 13/30 Figure 11 Connect the inputs to the individual channels of the device. 3. Screw the power supply wires to the device regardless of polarity (6 - 30 V DC, 5 - 21 V AC). www.yosensi.io...
Page 14 YO Analog User guide v3.2 page 14/30 Figure 12 Instruction on how to fasten the current clamps around the wires. Figure 13 Final look of the device. www.yosensi.io...
Page 15: Operation
3. Server – in most cases, a cloud-based service where data is processed, stored, analysed, and presented in user-friendly ways (via a user interface); Yosensi default and recommended tools are Yosensi Management Platform (for IoT structure management) and Grafana (for data presentation).
Page 16: Device Configuration
"deveui": "0123456789abcdef", "appeui": "fedcba9876543210", "appkey": "000102030405060708090a0b0c0d0e0f", "trials": 3 "abp": { "devaddr": "01234567", "nwkskey": "0123456789abcdef0123456789abcdef", "appskey": "000102030405060708090a0b0c0d0e0f" "ble": { "power": 0, "interval": 1600 "device": { "measinterval": 300, "measthreshold": 20, "ch1func": "0-20mA", "ch2func": "0-20mA", "ch3func": "0-20mA", "ch4func": "0-10V", "ch5func": "0-10V", "ch6func": "0-10V" www.yosensi.io...
Page 17 [ms] LoRa radio chipset used deﬁnes the LoRaWAN region: SX1261 - EU868; SX1262 - AU915, US915, AS923 Uplink subband list for speciﬁc LoRaWAN regions - UPLINK SUBBAND Table. Calculation formula: MS_INPUT = INTERVAL_MS × 1.6. Change currently not supported. www.yosensi.io...
Page 18: Parameters Description
‘meastreshold’ , it queues this data for sending. Measurement difference is reported in subsequent LoRa packets along with measurement time. ch1func…ch6func: numbers of channels with measurement of current or voltage ﬂow in the network connected to the device. www.yosensi.io...
Page 19 Sub-band 6; 923.2 - 924.6MHz; channels 40-47 Sub-band 7; 924.8 - 926.2 MHz; channels 48-55 Sub-band 8; 926.4 - 927.8 MHz; channels 56-63 Sub-band 1; 922.0 -923.2 MHz; channels 0-8 AS923 supported Sub-band 2; 923.2 - 924.5 MHz; channels 9-17 www.yosensi.io...
Page 20: Configuration Node With Yosensi Management Platform
YO Analog User guide v3.2 page 20/30 Conﬁguration node with Yosensi Management Platform Connect to the device as follows: 1. Log in at app.yosensi.io 2. You’ll see the dashboard organization view. Go to the Application section in the sidebar. 3. Select the application and locate and select the device by looking for the DEV EUI on the device label that matches the NODE ID in the list.
Page 21: Configuration Node With Yosensi Mobile App
Conﬁguration node with Yosensi mobile app Connect to the device using Yosensi app as follows: 1. Login to Yosensi App using your credentials. 2. Go to the Devices section and choose the device you want to conﬁgure. If you can not see the device ensure that you are in the correct organization.
Page 22: Connecting Node With Network
IoT systems management (like the root directory in operating systems). It can be created only by Yosensi staff, and all clients using Yosensi Management Platform have one created for them by default. In case of any questions, you can ﬁnd us at support@yosensi.io.
Page 23 (YO Analog). You can also set the node’s ‘Location’ , if locations have been pre-deﬁned. If you haven’t deﬁned a suitable location, leave this ﬁeld set at <None>. Figure 19 Adding node to the Yosensi Management Platform section view. www.yosensi.io...
Page 24 5. New nodes must be added in OTAA mode. Nodes can be switched to ABP mode after activation in the Yosensi Management Platform by changing the Node conﬁguration. Click on the link in the ‘Node Name’ column. Go to the ‘KEYS’ tab and switch ‘LoRa Type’ from OTAA to ABP and ﬁll in the blank spaces, then press update.
Page 25 (‘NODES LIST’ tab) status changes from ‘never’ to a few ‘seconds ago’ . 7. Open charts by clicking on the ‘OPEN’ button in Dashboard columns or by entering the node’s ‘DETAILS’ tab (‘Node Name’ column link) and clicking ‘CHARTS’ . www.yosensi.io...
Page 26: Adding Node Via Bluetooth
26/30 Adding node via Bluetooth 1. Log in at app.yosensi.io. 2. You’ll see the default organization view. To switch to another organization, click on the user avatar in the right top corner and select ‘Switch Organization’ . 3. To create an application, click the bottom right ‘+’ button. Fill in the ‘Name’ and ‘Description’...
Page 27 = 2 (4,83 [V]) Sixth measurement (CH1 - voltage) 0x32 0x00 0x11 0x06 0x01 0xE2 type = 12 addr_len = 1 val = 482 md [s] = 0 addr = 6 prec = 2 meas_len = 2 (4,82 [V]) www.yosensi.io...
Page 28: Compliance Statements
