Summary of Contents for Smarthome SM1507
- Page 1 ASSEMBLY INSTRUCTIONS SM1507 BASE SIZE: 1.520m x 0.685m...
-
Page 3: Before You Start
CONGRATULATIONS ON PURCHASING A DURATUF SMART STORE SHED. BEFORE YOU BEGIN THE ASSEMBLY PLEASE NOTE SOME IMPORTANT POINTS BEFORE YOU START: • Read all instructions carefully • Identify all parts and check quantities against parts list • Select a level site •... - Page 4 SM1507 PARTS LIST CLADDING + FLASHING + HARDWARE PACK 1 DESCRIPTION DIAGRAM CHECKED Back Wall - 1.900m Side Wall Angle- 1.925m Side Wall Angle 1 Pan Sheets- 1.905m Front Wall Narrow Sheets—1.940 Roof - 0.885m Door Sheets - 1.900m Door Sides - 1.900m Door Jamb - 1.940m...
- Page 5 SM1507 PARTS LIST PACK 2 TIMBER PACK DESCRIPTION DIAGRAM Front/Back Bottom Plates - H4 (Green) 1.520 m Front/Back Top Plate - H1 (Red) 1.520 m Side Wall Bottom Plates - H4 (Green) 0.685 m Side Wall Top Plates - H1 (Red)
-
Page 6: Parts Location
PARTS LOCATION Roof Sheets Barge Flashing Spouting Back Wall Sheets Top Plate Side Top Plate Back Top Plate Front Front Wall Sheet Door Side Flashing Door Brace Door Sheet Side Wall Sheets Hinge Bottom Plate Side Door Jambs Front 3/4 Wall Sheet Padbolt Support Bottom Plate Front Door Top/Bottom... - Page 7 FOUNDATION No doubt by now you will have decided what sort of base you are putting down. Please read the section that applies to your situation. If you choose to pour a concrete base you will need to decide whether you wish to raise the base plate of your shed. This allows the cladding to protrude below the surface of the concrete and ensures a water tight pad.
- Page 8 ASSEMBLE DOOR SELECT: 1 x 1.900 m Door Sheet 2 x 0.545 m Door Top/Bottom Flashings 2 x 1.900 m Door Side Flashings 2 x 0.915 m Door Braces 1 x Padbolt Support Flashing 2 x Hinges 50 x Rivets fig.1 STEP 1: •...
- Page 9 ASSEMBLE SIDE PANELS SELECT: IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER BASE PLATE –READ THE FOLLOWING; 2 x 1.925 m Side Wall Sheets (Angled) 2 x 1.905 m Side Wall 1 pan Sheets (Angled) For sheds with Raised Base Plate option only (see page 6), deduct 2 x 0.687m Top Plates (Red) 30mm from measurement shown between Top and Bottom Plates on 2 x 0.685m Bottom Plates (Green)
- Page 10 ASSEMBLE BACK PANEL IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 3 x 1.900 m Wall Sheets For sheds with Raised Base Plate option only (see page 6), deduct 1 x 1.520 m Top Plate (Red) 30mm from measurement shown between Top and Bottom Plates on 1 x 1.520 m Bottom Plate (Green) all wall panels, so cladding protrudes 20mm below bottom plate...
- Page 11 ASSEMBLE FRONT PANEL IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 1 x 1.520 Top Plate (Red) For sheds with Raised Base Plate option only (see page 6), deduct 1 x 1.520 Bottom Plate (Green) 30mm from measurement shown between Top and Bottom Plates on 2 x 1.940 Wall Sheets all wall panels, so cladding protrudes 20mm below bottom plate...
-
Page 12: Wall Panel Assembly
WALL PANEL ASSEMBLY SELECT: 4 x Pre-made Wall Panels SIDE 16 x 40mm Screws OVERLAPS BACK 16 x Rivets TOP PLATE STEP 1: BACK WALL • Stand the Back Panel and the Side Panel BOTTOM PLATE up using someone to support the panels while they are screwed together. - Page 13 ROOF ASSEMBLY IMPORTANT IMPORTANT SELECT: Use 50mm Clouts only on outside ribs covered by Barge flashings. Predrill Use 50mm Clouts only on outside ribs covered by Barge flashings and back holes using a 3.5mm drill bit. Use Roofing Screws on all other ribs. wall top plate.
- Page 14 SECURING SHED Secure your shed using Treated Timber Pegs or a Bolt Down Kit TIMBER PEGS—WOODEN FLOOR • The optional Duratuf Timber Peg Down Kit includes six H5 treated timber pegs that can be hammered into the ground and then attached to the Base Plate with stainless steel screws.
-
Page 16: Year Warranty
20 YEAR WARRANTY Riverlea Group Ltd warrant that the cladding used in the manufacture of the Smart Store shed will not rust within 20 years from the date of purchase. Any liability for product failure that may arise will be limited to repair or replacement of the defective product and will only apply for the benefit of the original purchaser.
