ClearCube TEMPEST CD7724T-L2 Bundle Zero Client Quick Start Manual

CD7724T-L2 TEMPEST Bundle
Zero Client Quick Start Guide
Package Contents
• CD7724T-L2 TEMPEST zero client
• TEMPEST display
• TEMPEST keyboard and mouse
• Zero client power adapter and cable
• Y-cable adapter for single-link-to-dual-link DVI,
enabling single 2560 × 1600 display
• This Quick Start Guide
Smart Card Reader Smart Card
Activity Indicator Reader
Headset
Port
USB
Microphone
Port
Port
DVI-I Connectors
USB Ethernet
Ports Connector
ClearCube Technology, Inc.
Front
PCoIP Session
Indicator
Power Button
and Indicator
Rear
AC
Audio
Out Input
MAC Address and
Serial Number Label
(on bottom)
3700 W Parmer Lane
CD7724T-L2 Zero Client Overview
A zero client is a remote computing device that connects a
user's monitors, keyboard, mouse, speakers, and other
peripherals to remote ClearCube
to virtual desktops (VMs). As shown below, computing
resources are typically located in remote data centers. Zero
clients enable users to work on a blade or VM as if it is a local
PC. The connection between the zero client and the remote
®
device is over PCoIP
host card manages the PCoIP session.
Network Infrastructure
Ethernet
Zero Client with Monitors
and Peripherals
Zero client connected to blade or to VM
Zero Client Features
ClearCube CD7724T-L2 zero clients connect to supported
ClearCube PC blades containing Tera1 or Tera2 host cards
and to virtual machines to provide:
• Three USB ports
• Support for fiber Ethernet media
• Support for independently-configurable monitors
– 2 DVI monitors up to 1920 × 1200
– 1 DVI monitor up to 2560 × 1600
(requires single-link-DVI-to-dual-link-DVI Y-cable
adapter, included, and Teradici Host Driver software)
Austin, Texas 78727 (512) 652-3500
®
PC blades (computers) and
protocol. Inside the remote device, a
Ethernet
Chassis with
Blades and VMs
