- Page 1 AUSTERE - MAINS POWER Installation & maintenance instructions.
-
Page 2: General Information
General Information • Designed for indoor use only. Do not expose to elements of nature. • All plumbing and electrical connections must be made in accordance with AUS / NZ standards. Warnings • Read all instructions before attempting to install this system. It is recommended a qualified &... -
Page 3: Specifications
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/ or property damage. Retain instructions for future reference. Sanela Austere Sensor Tap Sensor activated tapware for cold and pre-mixed water. High quality electronics combined with elegant aesthetics. -
Page 4: Standard Functions
Components Faucet Components o-ring Angel Valve & gasket Connection hoses Filter mounting Solenoid Valve plate hex nut mounting screws wago connectors to to solenoid external power supply valve adapter Standard Functions Hands within active Hands removed from range, water flows active range, water stops SENSING RANGE Operating pressure range... -
Page 5: External Power Supply Installation
External Power Supply Installation Input 230V / 50 Hz Output 24 V DC IP rating IP 55 Operating 5°C - 40°C temperature Rated power 10W 230V input 24V output (to faucet) Important To be installed in accordance with all NZ electrical regulations. It must be carried out by a qualified professional. - Page 6 Drill and insert appropriate wall anchors if required Remove cover from mounting box Fix mounting box to wall Pass mains (230V) power supply into mounting box via grommet and terminate accordingly Note: Power supply should be secured via current breaker before the external supply (not included) Reinstall cover of mouting box and ensure sealed.
-
Page 7: Faucet Installation
Faucet Installation Ø35mm Recommended hole size From external power supply Install 1/2” angel valve Flush lines thoroughly Fit mounting screw, o-ring and rubber gasket Pass mounting screw, hose and electrical Fit mounting plate and hex nuts connections through vanity. splwashrooms.co.nz... - Page 8 Fit filter into angel valve Note arrow on solenoid valve Fit connection hose and solenoid. Note 8 Connect faucet to solenoid valve Connect external power (24V outlet) supply to wago Turn angel valve on and check all connections connectors on faucet. (Note polarity: brown to brown, white to white) splwashrooms.co.nz...
- Page 9 It is necessary, for the proper function, to keep the unit under constant voltage (don´t connect the power supply unit behind the switch into the light circuit) Do not come within active range Turn power supply on Once power turned on, faucet will automatically adjust sensing range during first 10 seconds.
-
Page 10: Maintenance
Note: If you require to modify any of the factory settings please request the Sanela remote SLD03. Activation Range Time Delay Hygienic Flush Maintenance • It is recommended that the solenoid valve and all filters be inspected for foreign debris and cleaned annually (more frequently if necessary) •... -
Page 11: Troubleshooting
Troubleshooting Symptom Possible Cause Corrective Action No water flow - a. Water supply a. Ensure water at source is LED on sensor b. Water connections b. Ensure connections flashing red when c. Clean filter (angel valve c. Filter is clogged hands are within d. - Page 12 Supreme Comprehensive Warranty Your Supreme sensor tap is fully guaranteed against defective materials and faulty workmanship commencing from the date of sale (according to SPL’s records), subject to it being installed and maintained in accordance with the manufacturer’s instructions. SPL (2021) Limited warrants that should any part of the sensor tap fail within the given warranty period (24 months), it will be remedied by SPL.
