页 次： 第 1
ECBM-15W Wireless charging Alarm User Manual
页 共 2 页
.
Thanks for choosing us; this is a smart phone 15W /3coils wireless charger
Please kindly read the user manual before using and keep it for future reference.
Specification
TYPE-C Input：12V/2A
Wireless Output (Standard Model): 5W for all Qi standard wireless RX
Wireless Output (Fast Model): 7.5W for IPHONE
Wireless Output (Fast Model): 10W for Samsung
Wireless Output (Fast Model): 15W for Qi EPP certificate Mobiles
3 Coils: 1 Coil* 3
Charging distance: ≤ 8mm
Frequency: 115KHZ - 205KHZ
Standard: Qi1.3.2
Conversion Rate for wireless charging: up to 80%
LED Panel for status indicator
Product Size: L*W*H=125*60*10mm
Product Outline and Power Supply
① M button; ② + button; ③ – button , operating button.
④ USB-A output port: Output 5V/2A
