ZIM 676 EH
OPERATING INSTRUCTIONS
EN
DISHWASHER
Please carefully read these Operating Instructions before using the appliance!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZIM 676 EH and is the answer not in the manual?

Questions and answers

Related Manuals for Hansa ZIM 676 EH

Summary of Contents for Hansa ZIM 676 EH

  • Page 1 ZIM 676 EH OPERATING INSTRUCTIONS DISHWASHER Please carefully read these Operating Instructions before using the appliance!

  • Page 2: Table Of Contents

    THANK YOU FOR PURCHASING AN HANSA APPLIANCE DEAR CUSTOMER, Carefully read the operating instructions before plugging dishwasher to a power outlet and using the appliance. Operating instruction include tips that will help you avoid the risk of injury and damage to the appliance.

  • Page 3: Safety Instructions For Use

    SAFETY INSTRUCTIONS FOR USE Before you install the • Do not use an exten- appliance sion cord to connect Check the appliance for the appliance to the transport damage. Never wall outlet. Extension install or use a damaged cords are not suffi- appliance.
  • Page 4 SAFETY INSTRUCTIONS FOR USE Child safety Daily maintenance • Do not allow children • Use the appliance for to play with the appli- household dishwash- ance. ing only. • Dishwashing deter- • Do not use solvents in gents can be caustic the appliance as there and irritate the eyes, is a risk of explosion.
  • Page 5 SAFETY INSTRUCTIONS FOR USE Recommendations • Plastic dishes that are not resistant to high • To save energy and temperature, contain- water, rinse food resi- ers made of copper or due of the dishes be- tin; fore loading the dishes •...
  • Page 6 CARE FOR THE ENVIRONMENT RECYCLING At the end of its useful life, this product must Packaging and some not be disposed of with parts of the appliance normal municipal waste. are made of materials Instead, it should be tak- suitable for recycling. en to an electronic waste They are marked with the collection and recycling...

  • Page 7: Install The Appliance

    INSTALL THE APPLIANCE Placement of the product NOTE: Aquastop water supply is used in some dishwasher models. Dangerous volt- • When choosing the place of installation, age could occur with Aquastop. Do not cut make sure you will be able to easily load and the Aquastop water supply.
  • Page 8 INSTALL THE APPLIANCE Electrical connection at lower voltage the dishwashing efficiency will deteriorate and may damage the ap- Grounded plug must be connected to a grounded pliance. power outlet with a proper voltage. If there is no grounding, refer this to a qualified electrician. If The power cord may only be replaced by you operate the appliance without proper ground- authorized service or a qualified electri-...

  • Page 9: Features And Components

    FEATURES AND COMPONENTS The features and components of the appliance (fig. 1): Upper basket Inner tube Lower basket Salt container Dispenser Cup shelf Spray arms Filter assembly Water supply hose connector Water drain hose...
  • Page 10 FEATURES AND COMPONENTS Control panel (fig. 2): 1.Power indicator: To show when the power on. 2.Salt and rinse aid warning lights: To show when the salt container or dispenser need to be refilled. 3.Delay indicators: to show the delay time (3h/6h/9h/). 4.Half load indicator: To show when you select the half load function.

  • Page 11: Prepare The Appliance For Operation

    PREPARE THE APPLIANCE FOR OPERATION Before first use (2) using the supplied funnel (2). Replace and close the lid. If the salt indicator on the control • Before using the appliance, verify panel lights up, refill the special salt dispenser. that the data given on the rating plate matches that of local power outlets.
  • Page 12 PREPARE THE APPLIANCE FOR OPERATION Fill the detergent dispenser the programme with a higher wash temperature. Press latch to open the detergent dispenser, as Generally, using multi-component detergents shown in figure. (1) The detergent dispenser suitable results are obtained only under certain features volume marking.
  • Page 13 PREPARE THE APPLIANCE FOR OPERATION Stop using multi-component detergents • Add special salt and rinse aid to dispensers. • Set the water hardness to the highest level (6) and run an empty dishwasher. • Adjust the water hardness. • Adjust rinse aid setting. Add rinse aid to the dispenser and adjust set- ting Use rinse aid to prevent the formation of white...
  • Page 14 PREPARE THE APPLIANCE FOR OPERATION...
  • Page 15 PREPARE THE APPLIANCE FOR OPERATION Water hardness table Water hard- Water hard- German de- French de- British degrees Salt consump- ness level ness grees [dH] grees [dF] [dE] tion [g/cycle] indicator H1-Rapid 6-11 10-20 7-14 H2-90 Min H3-90 Min and 12-17 21-30 15-21...

  • Page 16: Load Dishes Into Dishwasher

    LOAD DISHES INTO DISHWASHER Upper basket Raise the basket Press the handle upward to lower the The upper basket is designed for washing delicate basket. dishes such as glasses, cups, plates, etc. Dishes that are placed in the upper basket should be less soiled than dishes in the lower basket.
  • Page 17 LOAD DISHES INTO DISHWASHER Cutlery basket Place knives and forks separately from each other, and make sure they do not touch as this may cause poor washing results. For best washing results place knives and forks in the cutlery basket, and make sure: ■...
  • Page 18 LOAD DISHES INTO DISHWASHER The standard load and test results Capacity: The upper and lower basket: 14 place settings. Set the upper basket to the upper position. Place the cups on the shelves. Detergent/rinse aid 5+30g, in accordance with the EN 50242, IEC 436 international standards/rinse aid dose: 6 Test programme Eco, in accordance with the EN 50242 international standard Cutlery basket...

  • Page 19: Turn On The Appliance And Select Programme

    TURN ON THE APPLIANCE AND SELECT PROGRAMME Turn on the appliance Only turn on the dishwasher once you load the dishes, add the necessary detergent, rinse aid and salt into dispensers and you check that spray arms can rotate freely and close the door: 1.
  • Page 20 TURN ON THE APPLIANCE AND SELECT PROGRAMME Change programme You can change the programme only if it ran for a short time. Otherwise, the appliance has already released the detergent and drained water. In this case, you must add the detergent. 1.

  • Page 21: Table Of Programmes

    TABLE OF PROGRAMMES Table*: ** Standard programme This is a reference program for research institutes. Tests according to EN 50242. This programme is suitable for washing normally soiled tableware. This is the most effective pro- gramme taking into account the total energy and water consumption for this kind of tableware. Programme duration, energy and water consumption value given in the table have been determined under laboratory conditions.

  • Page 22: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Regular dishwasher cleaning can extend its life- • Never use the dishwasher without the time of trouble-free operation. filter assembly. • Improper mounting of the filters reduces Grease and limescale can accumulate in dish- the dishwashing effectiveness. washer chamber.

  • Page 23: Error Codes And Troubleshooting

    ERROR CODES AND TROUBLESHOOTING Programme indicators: a) all indicators off — standby b) one programme indicator lights steady — programme paused pause or waiting to start the programme c) one indicator flashing — programme in progress, the appliance operates d) an indicator is flashing fast — error (see the following table) DESCRIPTION OF THE ERROR CODE ACTION...

  • Page 24: Practical Advice And Useful Information

    PRACTICAL ADVICE AND USEFUL INFORMATION high water hardness. dispenser. • Water softening system is at very low setting. • The appliance is improperly grounded. • The special salt dispenser lid is not closed properly. If the problem could not be corrected or, in the case of a defect not described above, please If the dishes won't dry contact our service centre.

  • Page 25: Product Fiche

    Commission Regulation (EU) No 1016/2010. Supplier’s name or trade mark Hansa Type ZIM 676 EH Rated capacity Energy efficiency class Annual energy consumption in kWh (AEC ) ( 280 cycles ) Energy consumption of the standard cleaning cycle (Et ) (kWh per cycle)

  • Page 26: Install The Appliance In A Cabinet

    INSTALL THE APPLIANCE IN A CABINET INSTALL THE APPLIANCE IN A CABINET Locate the dishwasher near the existing drain pipe, water supply valve and wall power outlet. Choose one side of the cabinet to route the drain hose. Note: make sure you have all the necessary installation accessories (hook for the front panel and screw) Carefully read the installation instructions.
  • Page 27 INSTALL THE APPLIANCE IN A CABINET max 720 mm 20 mm NOTE: Due to the design of some built-in furniture you may need to trim the base strip.
  • Page 28 INSTALL THE APPLIANCE IN A CABINET • Dimensions and installation of the front panel 1. You can prepare the wooden finishing front panel according to Figure 3a or 3b (depending on the appliance width). [Figure 3a] 45 cm models — Prepare 416 0.2 ±...
  • Page 29 INSTALL THE APPLIANCE IN A CABINET 2. Install the hook on a wooden finishing front panel and insert the hook into the exterior dishwasher door (see Figure 4a). When you align the panel, attach it to the external door using screws and bolts (see Figure 4b).
  • Page 30 INSTALL THE APPLIANCE IN A CABINET Adjust the door spring tension The door springs are adjusted at the factory for proper tension. If you install the wooden finishing panel, you will need to adjust the door spring tension. Turn the adjusting bolt to tighten or loosen the steel link (see Figure 5).
  • Page 31 INSTALL THE APPLIANCE IN A CABINET 3. Connect the water supply hose. 4. Connect the drain hose. Check against the diagram. (Figure 6). 5. Connect the power supply cord. 6. Place the condensation strip under the cabinet worktop. Make sure that the condensation strip is flush with the edge of the worktop.
  • Page 32 INSTALL THE APPLIANCE IN A CABINET The dishwasher must be level to ensure the highest dishwashing effectiveness. 1. Place the spirit level on the door and basket rail inside the chamber, as shown in the illustration to check the dishwasher level. 2.
  • Page 33 IO-DWS-1218 (07.2018)
