Table of Contents
Summary of Contents for Rossato Panel CSC TS
- Page 1 ...
- Page 2 responsible for inaccuracies and omissions. © The contents, images, texts and layout of this document are the property of Rossato Group srl and may not be reproduced ...
- Page 3 Panel CSC TS 7” - Manual of installation and use Table of contents 1.Introduzione 1.1 Informazioni generali 1.2 Contenuto del manuale 1.3 Garanzia 1.4 Descrizione dei simboli 1.5 Norme di servizio 2. Installazione 2.1 Installazione pannello remoto a muro ...
-
Page 4: General Instructions
Panel CSC TS 7” - Manual of installation and use 1.General instructions G eneral information Maintenance Provide for periodic inspections and maintenance to avoid and limit repair costs. Disconnect the voltage before any intervention. Modifications Any type of modification to the unit will void the manufacturer's warranty and liability. ... -
Page 5: Service Regulations
Panel CSC TS 7” - Manual of installation and use 1.5 Service regulations The service regulations described in this manual are an integral part of the supply. Furthermore, these standards are intended for the operator who has already been specifically trained ... -
Page 6: Installation
Panel CSC TS 7” - Manual of installation and use 2. Installation 2.1 Remote wall panel installation In the flush-to-wall version, the 7" TS comes with the appropriate recessed housing. This structure ... -
Page 7: Main Screen
Panel CSC TS 7” - Manual of installation and use 3. Operating Instructions 3.1 Main screen The main screen shows a summary of the entire control system where all configured climate zones, ... - Page 8 Panel CSC TS 7” - Manual of installation and use From firmware version 0.31 the external temperature via external sensor is also supported. If no ...
- Page 9 Panel CSC TS 7” - Manual of installation and use 3.1.8 ON/OFF system This feature is compatible from touch version 2.4 and you must have a firmware version greater than or ...
- Page 10 Panel CSC TS 7” - Manual of installation and use 3.2.1 Zone name During the start-up phase, all climate zones configured by the installer are named "Zone 1", "Zone 2" ...
- Page 11 Panel CSC TS 7” - Manual of installation and use Zone on/off Icon Description Status O n : normal operation of the zone Status O ff : the zone is disabled Velocità fan coil Icon ...
- Page 12 Panel CSC TS 7” - Manual of installation and use 3.2.3 Zone Monitor In the center of the screen is the temperature and humidity information measured in the zone and the ...
- Page 13 Panel CSC TS 7” - Manual of installation and use Icon Description DEHUMIDIFICATION is active The zone air-conditioning in COOLING mode is active The zone air-conditioning in HEATING mode is active MECHANICAL CONTROLLED VENTILATION (VMC) is active. ...
-
Page 14: Technical Information
Panel CSC TS 7” - Manual of installation and use 4. Technical information 4.1 Technical features Feature Description Item Panel CSC TS 7” Power supply Micro USB socket 24V, 2.5 A Processor Broadcom BCNM2387 chipset WiFi 802.11 b/g/n a 2.4 GHz ... - Page 15 Panel CSC TS 7” - Manual of installation and use 5. Disposal 5.1 Disconnection Unit’s disposal should be made according to national laws. Under no circumstances the unit must be disposed with ordinary household refuse. _ EN_1.00 Pag.
- Page 16 Panel CSC TS 7” - Manual of installation and use _ EN_1.00 Pag. 16 di 16 R ossato Group Srl Panel CSC TS 7” ...
