OWNER'S MANUAL
SCAR-10
10" GAS OR PROPANE SCARIFIER
USER & MAINTENANCE BOOK
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCAR-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for DiamaPro Systems SCAR-10

  • Page 1 OWNER’S MANUAL SCAR-10 10” GAS OR PROPANE SCARIFIER USER & MAINTENANCE BOOK SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...

  • Page 2: Warranty Registration Card

    W ARRANTY REGISTRA TION CARD Form must be completed and submitted within 30 days from the date of purchase. Customer Information First and Last Name Company Name Address City State Zip Code Phone Number Email Machine Information Machine Type Machine Model Serial # Purchase Date (dd/mm/yy) DiamaPro...

  • Page 3: California Prop 65 Warning

    DiamaPro SCAR-10. For your own safety and protection from injury, ® DiamaPro SCAR-10. For your own safety and protection from injury, carefully read, understand, and observe the safety instructions described carefully read, understand, and observe the safety instructions described in this manual. Keep this manual or a copy of it with the machine. If you in this manual.
  • Page 4 OPERATING ENVIRONMENT A limit of 1500 ppm CO in exhaust flow has been established by the The DiamaPro SCAR-10 can be operated outdoors within the tempera- CGA. ture range of 41°F to 86°F (5°C to 30°C). It’s crucial to avoid using the Occupational Health and Safety Administration (OSHA) machine during rainy or snowy weather conditions.

  • Page 5: General Instructions

    OPERATION INSTRUCTIONS GENERAL INSTRUCTIONS IMPORTANT! Equipment should only be operated by trained personnel in good physical condition and mental health (not fatigued). The operator and Read the engine manufacturer’s manual, familiarize yourself with engine maintenance personnel must be physically able to handle the bulk weight start procedures.

  • Page 6: Maintenance

    OPERATION INSTRUCTIONS (cont). FINE CUTTING This assembly should be used for very shallow or cleaning operations. STARTING THE CUT Check with DiamaPro Systems or an authorized dealer for special ® Slowly lower the cutter head to the slab surface with the engagement cutter wheels for removal of paint build-up or similar surface coatings.
  • Page 7 BLADES & DRUM REMOVAL/REPLACEMENT CUTTING DRUM ASSEMBLY Pull the Cutting Disc Shafts out the Assemble the Cutting Drum using Continue Step B until the Cutting open side of the Cutting Drum as Cutting Discs and Disc Spacers Drum assembly is complete. shown.
  • Page 8 BLADES & DRUM REMOVAL/REPLACEMENT (cont.) CUTTING DRUM INSTALLATION 1. Be sure the machine is turned off with the battery disconnected with the key switch in the off position. Remove the safety switch tether for added protection. Engage the parking brake to ensure the machine does not move during this operation. 2.
  • Page 9 BLADES & DRUM REMOVAL/REPLACEMENT (cont.) 4. To remove the plate from the machine, thread the 2 socket head bolts into the threaded holes on the left and right of the bearing plate. Be sure not to cross-thread these holes. Gently tighten the bolts one after another, a few turns at a time, to press the plate off of the shaft. 5.
  • Page 10 SCAR-10 PROPANE/GAS MAINTENANCE SCHEDULE MAINTENANCE TASK ALTERNATE DAILY WEEKLY Inspect belts and belt tensions Warning stickers Inspect cutting drum Inspect machine for damage Clean machine Check bolt tightness on the machine Unplug battery from machine after use Check propane lines for wear...
  • Page 11 SCARIFIER ACCESSORIES APPLICATION GUIDE KEY Preferred method to produce maximum performance or productivity rates for most job applications Acceptable performance or productivity rate for most job applications Limited performance productivity rates for most job applications Applications ← → PREPARATION GUIDE LIGHT REMOVAL HEAVY SCALING Removal of paints &...
  • Page 12 DP-SCAR-10 MAIN ASSEMBLY...
  • Page 13 DP-SCAR-10 MAIN ASSEMBLY ITEM # DESCRIPTION PART # Handrail Bracket Assembly for DiamaPro 10" Scarifier DP-SCAR10-HRBA Outer Hexagonal Locknut for DiamaPro 10" Scarifier DP-SCAR10-LM10 Washer for DiamaPro 10" Scarifier DP-SCAR-SW10 Cushion Block for DiamaPro 10" Scarifier DP-SCAR10-CBL Outer Hexagonal Bolt for DiamaPro 10" Scarifier DP-OHB-M10X40 Flat Washer for DiamaPro 10"...
  • Page 14 TANK BRACKET ASSEMBLY (Propane Units Only) ITEM # DESCRIPTION PART # Outer Hexagonal Nut for DiamaPro 10" Scarifier DP-NUT-M6 Spring Washer for DiamaPro 10" Scarifier DP-SCAR10-SW6 Clasp for DiamaPro 10" Scarifier DP-SCAR10-CLSP Propane Tank Holder for DiamaPro 10" Scarifier DP-SCAR10-GTH Hoop Pin Shaft for DiamaPro 10"...
  • Page 15 HANDLE SCREW ASSEMBLY...
  • Page 16 HANDLE SCREW ASSEMBLY ITEM # DESCRIPTION PART # Grease Nipple for DiamaPro 10" Scarifier DP-SCAR10-GN10 C-Clip for DiamaPro 10" Scarifier DP-SCAR10-CIRC25 Flat Washer for DiamaPro 10" Scarifier DP-FLAT-25 Copper Sleeve for DiamaPro 10" Scarifier DP-SCAR10-OFCS Knob for DiamaPro 10" Scarifier DP-SCAR10-KNOB Adjustable Screw for DiamaPro 10"...
  • Page 17 REAR WHEEL FRAME ASSEMBLY ITEM # DESCRIPTION PART # Outer Hexagonal Bolt for DiamaPro 10" Scarifier DP-OHB-M8X16 Spring Washer for DiamaPro 10" Scarifier DP-SCAR10-SW8 Large Washer for DiamaPro 10" Scarifier DP-SCAR10-LGWS8-1 Rubber Wheel for DiamaPro 10" Scarifier DP-SCAR10-RWHL Rear Wheel Frame for DiamaPro 10" Scarifier DP-SCAR10-RWF Lifting Rod Pin for DiamaPro 10"...
  • Page 18 PARKING BRAKE ASSEMBLY DESCRIPTION PART # Niagara Machine UNLESS OTHERWISE SPECIFIED: NAME DATE Complete parking brake assembly for DiamaPro 10” Scarifier DP-SCAR10-PBASM DRAWN DIMENSIONS ARE IN INCHES TOLERANCES: TITLE: CHECKED FRACTIONAL ANGULAR: MACH BEND ENG APPR. TWO PLACE DECIMAL CONTROL PANEL WIRING SHROUD ASSEMBLY THREE PLACE DECIMAL MFG APPR.
  • Page 19 REGULATOR BRACKET ASSEMBLY (Propane Units Only) ITEM # DESCRIPTION PART # Main Assembly DP-SCAR10-RBASM Niagara Machine UNLESS OTHERWISE SPECIFIED: NAME DATE Regulator for DiamaPro Scarifier DP-SCAR10-REG DRAWN DIMENSIONS ARE IN INCHES TOLERANCES: Low Pressure Hose DP-SCAR10-REGLH TITLE: CHECKED FRACTIONAL ANGULAR: MACH BEND High Pressure Hose DP-SCAR10-REGHH...

  • Page 20: Throttle Assembly

    FRONT WIRING SHROUD ASSEMBLY UNLESS OTHERWISE SPECIFIED: Niagara Machine NAME DATE DRAWN DIMENSIONS ARE IN INCHES TOLERANCES: TITLE: CHECKED FRACTIONAL DESCRIPTION PART # ANGULAR: MACH BEND ENG APPR. TWO PLACE DECIMAL THREE PLACE DECIMAL MFG APPR. Complete Front Wiring Shroud Assembly for DiamaPro 10” Scarifier DP-SCAR10-FWSASM Q.A.

  • Page 21: Battery Box Assembly

    BATTERY BOX ASSEMBLY Niagara Machine UNLESS OTHERWISE SPECIFIED: NAME DATE DRAWN DIMENSIONS ARE IN INCHES TOLERANCES: TITLE: CHECKED FRACTIONAL ANGULAR: MACH BEND ENG APPR. TWO PLACE DECIMAL THREE PLACE DECIMAL DESCRIPTION MFG APPR. PART # Q.A. INTERPRET GEOMETRIC PROPRIETARY AND CONFIDENTIAL TOLERANCING PER: Battery Box Main Assembly for DiamaPro 10"...

  • Page 22: Control Panel

    CONTROL PANEL (not pictured) DESCRIPTION PART # Ignition Key Switch ROG-60V2318 SAM Safe Air Monitor (Propane Units Only) DP-EMS-H Emergency Stop for DiamaPro 10" Scarifier DP-SCAR10-SAFS SAM Bezel for DiamaPro 10" Scarifier DP-SCAR10-SBZ BRAKE SHOE ASSEMBLY (not pictured) DESCRIPTION PART # Brake Shoe Assembly for DiamaPro 10”...
  • Page 23 WIRING DIAGRAM - GAS MODEL...
  • Page 24 WIRING DIAGRAM - PROPANE MODEL...
