Summary of Contents for TURY FAST MAX IP 5
- Page 2 3.14 Auto Lock - GPS Tracker - Alarm - Blocker 3. 15 High idle mode 3.16 Automatic closing of the FAST MAX APP 3.17 Language selection 3.18 Hide logotypes 4. SECURITY 4.1 Technology 5. VALIDATION 5.1 Troubleshoot www. tury. com. b r...
- Page 3 CAUTIONS INSTALAÇ ÃO E DIC AS AROUND 30 MINUTES We recommend that the installation of TURY products is always carried out by an experienced, trained and qualified professional who has all the necessary tools to carry out the procedure. 1.1 FUNCTIONS 1.1.1 PERFORMANCE: The FAST MAX IP product offers drivers the possibility of adjusting the...
- Page 4 FAST MAX has a specific type of special pulse for OEM applications only, in which case the tracker must have this protocol on the lock signal output. TURY, the manufacturer of FAST MAX, has partnerships with most of the world's major vehicle tracking companies and supplies this electronic communication protocol only to tracker manufacturers.
-
Page 5: Technical Specifications
Vehicles with electronic throttle with manual or automatic gearbox and any type of fuel. To check the vehicles (makes, models, versions and years) to which this product applies, go to www.tury.com.br and search in the product finder. 1.5 PACKAGE CONTENTS •... - Page 6 2.3 ELECTRONIC ACCELERATOR CONNECTOR LOCATIONS ON THE MOTORCYCLE There are 3 possibilities for locating the accelerator connector on the motorcycle. (See image below). BELOW THE SPEEDOMETER PANEL BEHIND THE HEADLIGHT NEAR THE TANK *Image merely illustrative. www. tury. com. b r...
- Page 7 FAST SAFE BOX (not included in the product - sold separately). In some vehicles it is necessary to loosen the throttle body frame screws to access the electrical connection of the original electronic throttle connector. www. tury. com. b r...
- Page 8 Some motorcycle models have a female connector next to the accelerator and other models have a male connector next to the accelerator. If you do not use the correct connectors and modules, the product will not work. www. tury. com. b r...
-
Page 9: Programming And Settings
. Available at Available at App Store www. tury. com. b r... -
Page 10: Initial Settings
BLUETOOTH module as shown below: Android Only on the ANDROID system is it necessary to activate and enable the device's LOCATION system according to the procedures below: Activate Location While using the App Activate permission www. tury. com. b r... - Page 11 MENU / PEDAL PROGRAMMING in the FAST MAX APP and follow the procedures above. The pedal can be programmed with the motor switched off or on and there will be no motor acceleration during programming. www. tury. com. b r...
- Page 12 Once the FAST MAX IP pedal has been installed, paired and programmed, it is ready to use. It starts in original mode and to select the acceleration map, simply click on the desired button: CITY, TOUR, SPORT or FAST. CITY TOUR SPORT FAST www. tury. com. b r...
-
Page 13: Setting The Eco Mode
fleet drivers and users who want to drive to save fuel when there is no need for a more dynamic acceleration response. ECO mode The higher the ECO mode setting, the greater the reduction in acceleration response and the vehicle's fuel consumption. www. tury. com. b r... - Page 14 1º Open the FAST MAX APP and on the main screen press the letter P (PARKING) for 2 seconds, the function will be activated immediately. Step 1 Press for Function activated 2 seconds www. tury. com. b r www. tury. com. b r...
- Page 15 This time can be set via the FAST MAX APP (see 3.12.1). To avoid the situation where your cell phone is discharged while the PARKING function is activated, we suggest keeping a smartphone charger available in the vehicle. www. tury. com. b r...
- Page 16 This time can be set via the FAST MAX APP (see 3.12). To avoid the situation where your cell phone is discharged while the PARKING function is activated, we suggest keeping a smartphone charger available in the vehicle. www. tury. com. b r...
- Page 17 To activate the rescue function, simply turn on the ignition key and wait for the set time without touching the accelerator pedal. After the time programmed in the App has elapsed, the product will unlock the pedal, leaving the LOCK or PARKING mode and returning to the ORIGINAL acceleration mode. www. tury. com. b r...
- Page 18 ANDROID 13 or higher, press the FAST MAX APP icon and click on "APP INFORMATION", then deactivate the "REMOVE PERMISSIONS IF APP IS UNUSED" option, then click on "BATTERY" and select the "UNRESTRICTED" option. www. tury. com. b r...
- Page 19 If you choose to buy the Magic Key, read its installation manual for more details. This function is located in the application under MENU/AUTO LOCK/MAGIC KEY and is part of TURY's international patent application. The following is an example of activating the Auto Lock - Magic Key function, registering the controls and setting the time for activating the progressive lock by distance: 1º...
- Page 20 To configure and enable the AUTO LOCK deactivation function via the FAST MAX APP with the pairing password, simply follow the steps below (we recommend changing the original pairing password for safety - see item 3.5): www. tury. com. b r...
- Page 21 OEM applications only, in which case the tracker must have this protocol on the lock signal output. TURY, the manufacturer of FAST MAX IP, has partnerships with most of the world's major vehicle tracking companies and supplies this electronic communication protocol only to tracker manufacturers.
- Page 22 Note: If you enter an incorrect password, there are only 3 attempts to enter the correct password and unlock the pedal. Step 9 Step 10 Step 8 Click on Function Enter your Click on the DISABLED activated password ENTER switch www. tury. com. b r...
- Page 23 3º Click on the APP AUTO CLOSING switch to activate the function and the same to deactivate it. Step 2 Step 3 Step 1 Click on APP Click on MENU Click on Click on APP AUTO CLOSING SETTINGS AUTO CLOSING www. tury. com. b r...
-
Page 24: Language Selection
“CONTINUE” 3.18 HIDE LOGOTYPES The possibility of hiding the TURY brand logos in the FAST MAX APP has been developed, making it possible to present the product to specific customers as an original vehicle brand accessory. 1º Open the FAST MAX APP and on the main screen press the MENU key on the top left-hand side;... - Page 25 • It comes with a 2-year warranty against manufacturing defects, according to the certificate attached. • To prevent accidents and traffic fines, never use the app while driving. This equipment is not entitled to protection against harmful interference and may not cause interference to duly authorized systems. www. tury. com. b r...
- Page 26 6º FIXED ACCELERATION FUNCTION - With the vehicle switched on, accelerate to the desired point, activate the function in the FAST MAX APP and release your foot from the accelerator, checking that the acceleration remains constant. www. tury. com. b r...
-
Page 27: Troubleshooting
Faulty wiring harness connection, connected correctly and that accelerator pedal wiring harness with the wrong there are no pins with bent terminals programming application for the vehicle model. in the connectors or out of place. www. tury. com. b r... - Page 28 • Always pass and fix the TURY harness together with the vehicle's original electrical harness, covering the module and TURY harness with foam to avoid noise; • Make sure that the end position of the TURY electronic module is protected from water. (insul-film, rain or during cleaning);...
