Opel CD 40 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Contents
Touch & Connect ........................... 3
CD 40 USB .................................. 91
CD 30 / CD 30 MP3 ................... 133
Mobile phone portal ................... 163

Advertisement

Table of Contents
loading

Related Manuals for Opel CD 40

Summary of Contents for Opel CD 40

  • Page 1 Contents Touch & Connect ......3 CD 40 USB ........91 CD 30 / CD 30 MP3 ....133 Mobile phone portal ....163...
  • Page 2 Vauxhall Zafira Infotainment System...

  • Page 3: Table Of Contents

    Touch & Connect Introduction ........4 Radio ........... 18 CD Player ........23 AUX input ........28 USB port ........29 Bluetooth music ......32 Navigation ........34 Phone .......... 73 Index ..........86...

  • Page 4: Introduction

    Introduction Introduction General information Optionally, the Infotainment system can be operated using controls on the The Infotainment system provides steering wheel. you with state-of-the-art in-car The well-thought-out design of the infotainment. General information ....... 4 control elements, the touch screen The radio has six station memories and the clear displays enable you to Theft-deterrent feature ....
  • Page 5 Introduction Radio reception Unlocking the Infotainment traffic.The related traffic system Radio reception may be disrupted by regulations must always be static, noise, distortion or loss of followed. If the power supply to the reception due to Infotainment system is interrupted, Only make entries (e.g.
  • Page 6 Introduction Notice selecting the Delete screen Detailed description of menu button. operation via touch screen or 3. After all numbers are entered multifunction knob 3 9. select the OK screen button to confirm your input. 1. Select the OK screen button. A message with important A keypad for PIN code input is information regarding the safe...
  • Page 7 Introduction Control elements overview Touch & Connect...
  • Page 8 Introduction l ......... 19 R .......... 24 13 I .......... 77 Radio: scroll down in CD ejection ......24 Phone menu ......77 station memory ..... 19 NAV ........35 14 m knob ........9 CD/MP3: short press: skip Navigation menu ....35 Press: switch on/off track backwards;...
  • Page 9 Introduction Operation Steering wheel audio controls p button ......77 Phone connected, no call Control elements active: 1st press: open The Infotainment system is operated phone menu; 2nd press: via function buttons, multifunctional redial (if redial number knobs, a touch screen and menus available) .......
  • Page 10 Introduction When the Infotainment system is Adjusting the volume of voice The adjusted setting is stored by the switched on, the last selected volume commands (navigation) Infotainment system and will be is set. automatically used for all future The volume of voice commands can phone calls until the setting is be adjusted while a command is If the volume is muted (set to zero),...
  • Page 11 Introduction ■ USB port functions 3 29 You can, for example, activate an on- / (back) button screen button by tapping on it with a Press the / button to return from a ■ Bluetooth music functions 3 32 finger or change the position of an on- submenu to the next higher menu screen slider element by moving it Navigation...
  • Page 12 Introduction The corresponding system function is Messages activated, or a message is displayed, or a submenu with further options is displayed. With multifunction knob: 1. Turn the multifunction knob clockwise or anti-clockwise to select a screen button or menu item. The currently selected screen button or menu item is highlighted.
  • Page 13 Introduction Scrolling through a long list of menu With multifunction knob: With multifunction knob: items Turn the multifunction knob clockwise 1. Turn the multifunction knob or anti-clockwise to scroll through the clockwise or anti-clockwise to list of menu items. select a menu item. 2.
  • Page 14 Introduction Example: Avoid road settings Example: Display settings Notice In subsequent chapters the operating steps for switching to another setting option via touch screen or multifunction knob will simply be described as "...set...to...'option name'...". Example: System settings With touch screen: With touch screen: Tap on the - or + screen button beside Tap on a menu item to switch to...
  • Page 15 Introduction With multifunction knob: To open the AUDIO SETUP menu: Fader 1. Turn the multifunction knob Use this setting to adjust the volume ■ Press the SETUP button and then clockwise or anti-clockwise to distribution between the front and select the Audio screen button, select a menu item.
  • Page 16 Introduction Adjusting the volume of voice System settings commands (navigation) ■ if an audio main menu is currently active, e.g. the FM1 or CD menu, press the multifunction knob. Notice The Audio screen button in the SETUP menu is not selectable, when the volume is set to zero.
  • Page 17 Introduction Scroll direction Activating or deactivating touch clicks To adjust the scroll direction for menu If the menu item Touch Click in the item selection via the multifunction SYSTEM SETUP menu is set to On, knob: set Scroll Direction to [ or ]. each tap on a screen button or menu item is indicated by a clicking sound.

  • Page 18: Radio

    Radio Radio Usage If the currently played station is an RDS station 3 20, the station name Notice and programme related information Within the radio menus you can only are displayed. use the touch screen to select/ Usage .......... 18 activate the screen buttons at the Selecting the waveband Station search ......
  • Page 19 Radio Enabling or disabling traffic Manual station tuning announcements (TA) Using the multifunction knob (TA function not available for AM While a radio main menu is active: waveband) turn the multifunction knob clockwise Select the TA screen button to enable or anti-clockwise to change the or disable the reception of traffic receiving frequency.
  • Page 20 Radio This ensures that, e.g., the station Notice list always contains the FM stations If no beep can be heard when storing that can be received in the local area a station, system sounds are during a long motorway journey. deactivated.
  • Page 21 Radio The Infotainment system always During the verbal announcement the tunes into the best receivable volume can be changed by turning frequency of the currently played the m knob. RDS station. The traffic announcement can be If RDS Regional mode is activated, cancelled by selecting the Cancel only frequencies of the currently screen button.
  • Page 22 Radio Enabling or disabling traffic announcements Select the TA screen button to enable or disable the reception of traffic announcements. When the reception of traffic announcements is enabled, TA is displayed in the top line of all main menus. If traffic announcements can not be received, TA is crossed out.

  • Page 23: Cd Player

    CD Player CD Player General information MP3 and WMA files written in any format other than listed above may The Infotainment system's CD player not play correctly, and their file can replay audio CDs and MP3/WMA names and folder names may not CDs.
  • Page 24 CD Player ■ Dirt and liquids on CDs can smear Playlist entries must be in the form the lens of the audio player inside of relative paths. the device and cause faults. ■ This chapter deals only with playing ■ Protect CDs from heat and direct MP3 files since the operation for sunlight.
  • Page 25 CD Player If the normal CD replay mode is active (no mix or repeat mode activated, see below): replay starts with the first track on the CD again, after all tracks on the CD have been played. Notice Folders and playlists stored on an MP3 CD are treated equally by the CD player.
  • Page 26 CD Player Fast forward or rewind Select the Mix screen button to Repeat mode activate or deactivate the mix mode. Press the l or m button and hold it down to fast forward or rewind the If the mix mode is activated, Mix is current track.
  • Page 27 CD Player During MP3 CD replay If the CD is not removed after ejection, it will be drawn back in again If an MP3 CD is inserted, the current automatically after a few seconds. track or all tracks in the currently selected folder can be repeatedly played until the repeat mode is deactivated again.

  • Page 28: Aux Input

    AUX input AUX input General information The audio signal of the connected audio source is now transmitted via The connector is located in the area the speakers of the Infotainment of the centre console. system. Notice General information ..... 28 The volume can be adjusted via the The socket must always be kept m knob and via the o thumbwheel...

  • Page 29: Usb Port

    USB port USB port General information ■ Devices connected via USB are supported according to USB The connector is located in the area Specification V 2.0. Maximum of the centre console. supported speed: 12 Mbit/s. Notice General information ..... 29 ■...
  • Page 30 USB port Playing saved audio files At least 8 folders in depth hierarchy iPod are supported. MP3 player, USB drive, SD card WMA files with Digital Rights Management (DRM) from online music shops cannot be played. WMA files can only be played back safely, if they were created with Windows Media Player version 9 or later.
  • Page 31 USB port Music browser Depending on the model/version of the connected iPod and the data stored, there are various options for the selection and playing of tracks. Select the Browse screen button to display a menu with the available options for music browsing. Select the desired option for music browsing.

  • Page 32: Bluetooth Music

    Bluetooth music Bluetooth music General information Operation Bluetooth enabled audio sources Prerequisites (e.g. music mobile phones, MP3 The following prerequisites must be players featuring Bluetooth, etc.), General information ..... 32 met in order to use the Bluetooth which support Bluetooth music music mode of the Infotainment Operation ........
  • Page 33 Bluetooth music Activating the Bluetooth music Skipping to next or previous track Briefly press the t or v button (on mode the instrument panel). Pause/Stop replay Select the z screen button. To restart replay: press the l screen button again. Press the MEDIA button once or several times to activate the Bluetooth music mode.

  • Page 34: Navigation

    Navigation Navigation General information followed. If a navigation instruction contradicts traffic regulations, the The navigation system will reliably traffic regulations always apply. guide you to your destination without the need to read maps, even if you General information ..... 34 Functioning of the navigation have no local knowledge whatsoever.
  • Page 35 Navigation The route guidance is provided by Dynamic route guidance only works if voice commands and an direction traffic information is received via the arrow, as well as with the aid of a TMC traffic information system. multi-colour map display. The dynamic route guidance function can be deactivated, see chapter TMC traffic information system...
  • Page 36 Navigation The NAVIGATION menu provides The TRAFFIC MESSAGES menu The NAVIGATION SETUP menu access to all system functions for shows all traffic events on the current provides various settings for destination input 3 46 and route route (if route guidance is active), adjustment of the navigation system.
  • Page 37 Navigation Route guidance not active ■ Current position indicated by a red Route guidance active triangle. ■ Street name of current position. ■ Points of interest (POI), e.g. petrol stations, parking areas or restaurants, indicated by corresponding symbols. The display of POIs can be switched on/off, see "Setting up the navigation system"...
  • Page 38 Navigation Notice The display of POIs can be ■ Remaining distance to the final The activation/deactivation of voice switched on/off, see "Setting up the destination. guidance is indicated by a beep, if map display" below. Changing the distance unit, see system sounds are activated 3 9.
  • Page 39 Navigation Moving the visible map section Notice When the move mode is activated, The visible map section on the map you can set the GPS coordinates for display can be moved freely in all new destinations by tapping on the directions.
  • Page 40 Navigation ■ Show Position Information: book: select the Save screen displays the address/GPS button. coordinates of the current position. ■ Map Setup: displays the MAP To store the displayed address/ SETUP menu, see below. GPS coordinates in the address Setting up the map display book: select the Save screen To open the MAP SETUP menu: button.
  • Page 41 Navigation In the 2D map view, you can toggle ■ Show POIs In Map: if set to On, The following settings/options are between the "north orientation", points of interest, e.g. fuel stations, available: and the "driving direction parking areas, or restaurants, are ■...
  • Page 42 Navigation If this option is set to On: when the vehicle approaches a user defined POI, the related warning message is displayed. ■ POI Warning Distance: only applicable, if user defined points of interest (POI) and corresponding warning messages were downloaded to the Infotainment system, see "User defined points of interest"...
  • Page 43 Navigation system, see "User defined points of accomplish a short execution time interest" below. for a simulated trip. Select the menu item to remove all To return to normal route guidance: user defined POI data from the set the menu option to Off. Infotainment system.
  • Page 44 Navigation Notice 3 46. You can select the regarding Creating user defined POIs Functionality of the Dynamic menu item as destination for route For each POI type you need to create navigation settings when route guidance. a separate text file, e.g. by using a guidance is active, see "Settings for simple text editor software.
  • Page 45 Navigation Example: 9.9800000, 6. Enter further POI data, using a The only difference is: instead of 52.0150000, "Michaels House separate line for each POI, into creating a name (e.g. "Michaels [ Fleet Street ]" the text file, as described above. house") you need to create a warning message (e.g.
  • Page 46 Navigation To start the download: press the The NAVIGATION menu provides SETUP button, select the Navigation three options that you can use for screen button, select the Download destination input: my POIs now menu item, and then ■ Destination: opens the ENTER confirm the displayed message.
  • Page 47 Navigation as new destination, see "Entering and selecting the home address" below. The menu options Options, Route, and Cancel Route are described in the "Guidance" chapter 3 63. Using menus with keypads for address input When using the various options for address input, you often need to enter address data using menus with keypads.
  • Page 48 Navigation In case the displayed city name is the Entering an address directly one you are searching for, you can Press the NAV button, and then select the OK screen button to directly select the Destination menu item to add that city name to your destination open the ENTER DESTINATION address.
  • Page 49 Navigation Performing the address data input Select the City menu item to enter the name or postal code of your 1. Entering the country name: destination city. If the destination country needs to A menu with keypad for city name be entered or changed: select the or postal code input is displayed.
  • Page 50 Navigation A menu with keypad for street with keypad for house number If you select the No num. screen name input is displayed. input, see image below. button, the destination is set to the centre of the destination street, Notice and the CONFIRM In case the system does not require DESTINATION menu is...
  • Page 51 Navigation A message is displayed that provides the options (1) Move and (2) Store described above. Select the desired option (screen button). Moving the destination to a new location: If you select the Move screen button in the message, the SCROLL MAP menu is displayed.
  • Page 52 Navigation Tap on the map to move the The route will be calculated by the destination to a new location. navigation system, and then route guidance started. The destination flag is now displayed at the new location. Description on route guidance, see chapter "Guidance"...
  • Page 53 Navigation The previously entered address is Using the address book, you can The following options are available: indicated by a chequered flag. conveniently store the addresses of ■ New Address: displays the menu To change the previously entered your favourite destinations, and later for direct address input.
  • Page 54 Navigation The CONFIRM DESTINATION menu is displayed again. To store the new address in the address book: Select the Save screen button. A menu with keypad for name input is displayed. If required, you can move the Select a previous destination that visible map section in an arbitrary you want to store in the address direction by moving your finger on...
  • Page 55 Navigation To store the address data: see Enter a new name for the address descriptions above. book entry, and select the OK screen button to confirm the new ■ Current Position: stores the current name. destination in the address book. ■...
  • Page 56 Navigation The data stored on the map SD card The POINTS OF INTEREST menu is contain a great number of predefined displayed. POIs, which are indicated by corresponding symbols on the map display. You can select such POIs as destinations for route guidance. To select a point of interest: Press the NAV button, and then select the Destination menu item to...
  • Page 57 Navigation ■ Petrol stations nearby: shows a list In such cases, select the desired of petrol stations nearby the current subcategory. location. Finally, a list of category specific Operating steps to start route POIs will be displayed. guidance to a particular petrol Operating steps to start route station, see instructions on guidance to a particular POI, see...
  • Page 58 Navigation POIs which names contain the specific POI, see instructions on To select a user defined point of entered letter combination. Search near here above. interest: ■ Search in another city: provides Press the NAV button, and then Notice access to all POIs within a selected select the Destination menu item to If you do not enter any letter, and city.
  • Page 59 Navigation To return to the user POI list: select the List screen button. To start route guidance to the selected user POI: select the Start screen button. Description on route guidance, see chapter "Guidance" 3 63. Selecting a destination from the This method of destination input allows you to search for a new Select the Destination from map...
  • Page 60 Navigation After selecting the Save screen Selecting an intersection as button in the message, a menu with destination keypad for name input is displayed. This method of destination input functions almost the same as described for "Entering an address directly", see above. Instead of specifying a location in a street by a house number, you need to specify the location by an...
  • Page 61 Navigation If there are 5 or less crossing streets, Select the desired crossing street, a list of all crossing streets is and continue with operating step 5 of displayed. Select the desired "Entering an address directly", see crossing street, and continue with above.
  • Page 62 Navigation exceeds 50, the oldest one will be ■ Del. all: deletes the entire list of removed from the list, and the new previous destinations. one will be added. ■ Delete: deletes the displayed After selecting a previous destination destination from the list of previous in the list, a menu is displayed with destinations.
  • Page 63 Navigation The old home address (if available) Detailed descriptions on the map will be deleted. display and the visual route guidance information, see chapter "Usage" ■ Start: sets the displayed home 3 35. address or GPS coordinates as new destination, and starts route Voice commands guidance to that destination.
  • Page 64 Navigation Controlling route guidance via ■ Route: opens the ROUTE LIST Press the NAV button, and then menu that shows all streets on the select the Options menu item to open the NAVIGATION menu current route, see "Displaying the the ROUTE OPTIONS menu. Press the NAV button to open the route list"...
  • Page 65 Navigation Automatic: all TMC messages are and ferries should be minimized, ■ Direction arrow or motorway automatically taken into account for when calculating the route to the symbol. route calculation/recalculation. destination. Notice Prompt: in the event of a traffic jam An additional small red triangle in a Displaying the route list or other traffic incidents, for which...
  • Page 66 Navigation To show all available information on a The following menu options are traffic events in the vicinity of the particular route list item: select that available: current vehicle position. list item. ■ Block: using this menu item you can TMC (traffic) symbols (see chapter exclude streets from route "Symbols overview"...
  • Page 67 Navigation Using that menu you can exclude the first upcoming streets from the current route by defining the length of the exclusion section, starting from the current vehicle position. To exclude upcoming streets from the route: set the desired value of Avoid Dist., and then select the Recalculate Route menu item.
  • Page 68 Navigation Notice Press the NAV button, and then Enabling user defined POI You can only define one single select the Destination menu item or warnings exclusion street or one exclusion the Previous Destinations menu item. You can define "POI warnings" for section at a time in the route list.
  • Page 69 Navigation Maps In the case of a traffic problem (e.g. traffic jam, closed road) on the route All map data required for use of the driven, a message is displayed, and a navigation system is stored on an SD voice message output indicating the card provided with the Infotainment nature of the problem.
  • Page 70 Navigation Important information on SD card ■ Do not store the SD card in Removing the SD card handling locations exposed to direct sunlight, or in high temperatures or Caution humidity. ■ Always place the SD card in its Never attempt to use an SD card storage case, when not in use.
  • Page 71 Navigation Symbols overview Inserting the SD card No. Explanation Petrol station Route guidance and POI symbols Restaurant POI (points of interest) symbols are only shown on the map display, if the display of POIs is enabled. To enable the display of POIs: press the SETUP button, select the Navigation menu item, select the Map Setup menu item, and then set Show...
  • Page 72 Navigation Dynamic navigation to Automatic or Explanation Prompt, see chapter "Guidance" Traffic jam 3 63. Closed road Slippery road Road works Icy road Cross winds Narrowing Accident Danger Uneven road TMC (traffic) symbols are only shown on the map display, if dynamic route guidance via TMC messages is enabled.

  • Page 73: Phone

    Phone Phone General information Important information for operation and traffic safety The Phone portal provides you with the possibility of having mobile phone 9 Warning conversations via a vehicle General information ..... 73 microphone and the vehicle Mobile phones have effects on Bluetooth connection ....
  • Page 74 Phone Hereby, we declare that the Bluetooth phones is prohibited, if System Transceiver is in compliance interference is caused by the with the essential requirements and mobile phone or if dangerous other relevant provisions of Directive situations can occur. 1999/5/EC. Bluetooth Bluetooth connection The Bluetooth profiles HFP 1.1,...
  • Page 75 Phone Pairing a Bluetooth device Infotainment system's Bluetooth Connecting to another paired unit, CAR HF UNIT will be device Important information displayed. ■ Up to four devices can be paired to 4. On the Bluetooth device: select the system. CAR HF UNIT and then follow the ■...
  • Page 76 Phone Emergency call 2. Select the desired device. Removing a paired device 3. On the Bluetooth device: if not activated already, activate the 9 Warning Bluetooth function (see user guide of Bluetooth device). Connection setup cannot be guaranteed in all situations.For On the Infotainment system's this reason you should not rely display: after a few seconds a...
  • Page 77 Phone Operation Notice functions are active. You can Not every mobile phone supports all enquire about this with the local As soon as a connection via functions of the Phone portal. network operators. Bluetooth has been set up between Therefore deviations from the range your mobile phone and the The emergency call number can of functions described with these...
  • Page 78 Phone o thumbwheel: turn to adjust volume. Prerequisites The following prerequisites must be met in order to use the handsfree mode of the Infotainment system: ■ The Bluetooth function of the Infotainment system must be activated 3 74. ■ The Bluetooth function of the mobile phone must be activated In case a mobile phone is in the range The mobile phone is now connected...
  • Page 79 Phone data and call lists data is transferred from the mobile phone to the Infotainment system. Detailed information on this, see "Phone book setup" below. Initiating a phone call Using the phone book In the phone book contacts are stored with name and phone number.
  • Page 80 Phone Enter the first letters of the contact name you are searching for (select the Delete screen button once or several times to delete already entered letters). As soon as the system finds a contact name whose first letters match the entered letters, the entire name of the corresponding phone book entry is displayed (see image above).
  • Page 81 Phone To initiate a phone call: select the To initiate a phone call: select the Accessing the voicemail box desired list entry. The corresponding { screen button. The displayed Enter the phone number of the phone number is dialled. phone number is dialled. connected mobile phone manually, see "Manually entering a phone Redialling a phone number...
  • Page 82 Phone To answer the call: select the green Deactivating the microphone { screen button. temporarily Select the Mic. off screen button. The To reject the call: select the red } caller will not hear you any longer. screen button. To reactivate the microphone: select Second incoming phone call the Mic.
  • Page 83 Phone Notice Downloading the phone book Adjusting the sorting order Depending on the number of phone Set Sort Phonebook By to First book entries and the connected Name or Last Name to adjust the mobile phone, the data download sorting order for the phone book can take several minutes.
  • Page 84 Phone Notice In case you select a phone book that was not downloaded from the connected mobile phone, the Phonebk screen button in the PHONE menu will not be selectable.
  • Page 85 Phone...

  • Page 86: Index

    Index Activating the CD player....24 General information....Activating the radio....... 18 ....4, 23, 28, 29, 32, 34, 73 Adding waypoints......63 Guidance ........63 Address book........ 46 Address entry....... 46 Home address......46 AUX input socket........28 usage........28 Infotainment system control elements......
  • Page 87 Regionalization......20 Replacing a map SD card..... 35 Navigation Operating a Bluetooth music Route calculation......63 adding waypoints...... 63 device........32 Route guidance...... 63, 68 address book......46 Operation ......9, 32, 77 Route list........63 control elements......35 creating user POIs....35 Pairing a Bluetooth device....
  • Page 88 Usage......18, 24, 28, 35 USB port important information....29 playing saved audio files... 30 User POIs creating and downloading..35 selecting........46 Using the AUX input..... 28 Using the CD player..... 24 Using the Infotainment system..9 Using the navigation system..35 Using the radio......
  • Page 89 Copyright by General Motors UK Ltd. The information contained in this publication is effective as of the date indicated below. General Motors UK Ltd. reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information contained in this publication, as well as changes to the publication itself.
  • Page 90 Vauxhall Zafira Infotainment System...

  • Page 91: Cd 40 Usb

    CD 40 USB Introduction ........92 Radio ......... 106 CD Player ........118 AUX input ........123 USB port ........124 Index .......... 128...

  • Page 92: General Information

    Introduction Introduction General information In addition the Infotainment system can be equipped with a Mobile phone The Infotainment system provides portal. you with state-of-the-art in-car The well-thought-out design of the infotainment. General information ..... 92 control elements and the clear The radio has nine automatic station displays enable you to control the Theft-deterrent feature ....

  • Page 93: Theft-Deterrent Feature

    Introduction Radio reception Radio reception may be disrupted by static, noise, distortion or loss of reception due to ■ changes in distance from the transmitter, ■ multi-path reception due to reflection, ■ shadowing. Theft-deterrent feature The Infotainment system is equipped with an electronic security system for the purpose of theft deterrent.

  • Page 94: Overview

    Introduction Overview Control elements...
  • Page 95 Introduction e knob ......... 96 SOUND ....... 103 13 TP ........111 Sound function Traffic programme ....111 Briefly press: switch on/off programme selection ..103 Infotainment system ....96 14 j Eject CD ......119 BC ......... 94 Turn: adjust volume ....96 On-board computer ....

  • Page 96: Operation

    Introduction Operation Steering wheel audio controls Radio: discontinue TA and PTY31 messages ....106 Control elements If a DAB receiver is The Infotainment system is operated connected: changing via function buttons, multifunctional between analogue and knobs and menus that are shown on digital reception ....
  • Page 97 Introduction ■ If the automatic switch-on is Disabled: on the right side of the Speed dependent volume control disabled, the Infotainment system display the message appears "Turn (SDVC) can only be switched on with the on Radio via ON/OFF button only". When SDVC is activated 3 104, the e switch and with the j button for volume is adapted automatically to...
  • Page 98 Introduction For the best possible audio quality, Selection pages Feature pages the external audio source should be set to maximum volume. On units with line-out, the output signal is available at a fixed audio level and cannot be changed. To avoid overriding the AUX input, the effective output voltage of the external audio source must be lower than 1.5 V.
  • Page 99 Introduction Settings pages Selecting from a menu Select the menu item. ■ In some menus, settings are made by turning the multifunction knob. ■ Active functions are identified by a ticked box or a selected option field in front of the menu item. ■...
  • Page 100 Introduction Press the multifunction knob to For this purpose, the currently confirm your selection. displayed menu is overlaid with the Turn the multifunction knob to the pop-up. In the following chapters of the right until menu item Main appears in operating instructions, the requests You have to confirm some of the pop- the footer.
  • Page 101 Introduction The station last tuned in to is To select the Audio menu, proceed as Leaving a menu with the multifunction displayed. follows: knob You will hear the last station tuned in. In the radio, audio source or Sound menus: Selecting the CD menu Turn the multifunction knob to the left Press MEDIA button once or...
  • Page 102 Introduction This option is not available in lists, Main menu Mobile phone portal information input menus and the main menu. Display of the information provided if a Mobile phone portal is fitted. See Using the function buttons to exit from operating instructions for Mobile menu phone portal.

  • Page 103: Tone Settings

    Introduction ■ The programme name is indicated Information on the climate control 1. Select the menu items Treble or if the RDS function is active system Bass. 3 111. See car owner's manual. 2. Turn the multifunction knob until ■ If traffic announcements are the desired value is set.

  • Page 104: Volume Settings

    Introduction Sound The following menu items are SDVC available: If you prefer a preset sound style To compensate for ambient and there are five options to select from. rolling noise, the Infotainment ■ TA Volume: Volume of traffic system's volume is adjusted to the announcements Select menu item Sound.
  • Page 105 Introduction External In Use this function to adjust the volume of external sources such as a mobile phone. Select menu item External In. Turn the multifunction knob until the desired value is set. Press the multifunction knob. Aux volume Use this function to adjust the volume of external audio sources such as a CD player.

  • Page 106: Usage

    Radio Radio Usage Press the multifunction knob. The Audio menu is displayed. Radio mode Select waveband FM, AM or DAB (if Switch from another mode to radio available). Usage ........106 mode as shown below: The station last selected on the Station search ......
  • Page 107 Radio The Station menu contains the Update list of stations Automatic search following areas: The list of receivable stations is updated automatically. The In the upper area, stored stations can performance of the station list update be called up. varies depending on the waveband In the lower area, all other receivable set.
  • Page 108 Radio ■ After releasing the rocker switch, Station search with the multifunction the next receivable station is knob automatically tuned in. The station search with the multifunction knob is started from the ■ If the radio cannot find a station, it radio menu.

  • Page 109: Autostore Lists

    Radio The frequency last tuned into is Manual Storing displayed. To store stations manually, the radio needs to be in normal mode (not AS Turn the multifunction knob until the mode). exact frequency is reached. RDS on or RDS off are stored You will hear the newly tuned-in together with the station.
  • Page 110 Radio In the radio menu enable/disable on RDS is switched on automatically standby for traffic announcements if when automatic storing is enabled. desired 3 111. First, all receivable RDS stations are stored. Select menu item Autostore. If on standby for traffic announcement is switched on prior to or during automatic storing, the radio will select a memory slot with a traffic...

  • Page 111: Radio Data System (Rds)

    Radio Calling up a station via station button ■ The Infotainment system always tunes into the best receivable You are listening to the station last broadcasting frequency of the set tuned in. station by means of AF (Alternative Select the desired station with a Frequency).
  • Page 112 Radio Switching RDS on/off Enable/disable the Automatic tick box. If you switch RDS on, the RDS functions are enabled and only RDS Programme type (PTY) stations are sought during the Many RDS stations transmit a PTY automatic station search. code describing the type of If you switch RDS off, the RDS programme broadcast (e.
  • Page 113 Radio ■ Regionalisation is only possible in the FM waveband. The radio allows switching to another regional programme. ■ The RDS function must be switched Automatic ■ This function is set in the radio The radio remains tuned to the menu.
  • Page 114 Radio Traffic stations can be recognised by Keep the rocker switch m or n the TP symbol in the display. pressed until Seek is displayed. The radio only searches for traffic Switching traffic programme on/off programme stations. ■ If on standby for traffic announcement is enabled, [TP] or Hearing traffic announcements only [ ] is displayed in the upper display...

  • Page 115: Digital Audio Broadcasting

    Radio announcement. To do this, on General information improved, whereas AM or FM standby for traffic announcements reception is considerably impaired ■ With DAB, several radio must be enabled. in such cases. programmes (services) can be broadcast on a single frequency During the phone call the radio or ■...
  • Page 116 Radio Selecting an ensemble Select menu item Search available ensembles. You can select ensembles directly which you have already received The DAB Ensemble menu is once (the ensemble needs to be displayed. receivable). The entire waveband is displayed. This function is set in the radio menu. The automatic ensemble search Select the arrow next to the ensemble starts.
  • Page 117 Radio This function can only be performed if To display the first 20 to 25 characters the station is included in the new of the radio text: press the INFO ensemble. button. Select menu item DAB. Enable/disable the DAB AF tick box to change the setting.
  • Page 118 CD Player CD Player General information ■ You can also use the Infotainment system to play CDs containing MP3 You can play standard commercial music data and Mixed Mode CDs. CDs with a diameter of 12 cm with this ■ Self-recorded CD-Rs and CD-RWs unit.
  • Page 119 CD Player When naming albums and tracks, Do not prevent or assist the CD being Depending on the type of CD, umlauts or special characters drawn in. different CD information is displayed should not be included. in the CD menu. Text information only In the upper area of the display CD appears if Show title is switched on in Applicable playlist extensions:...
  • Page 120 CD Player In the CD menu select menu item The CD changer plays the CD at The CD menu is displayed. Track. increased speed and reduced The first track from the newly selected volume. A list of all tracks is displayed. album is shown on the display.
  • Page 121 CD Player Random CD (Random) Switching on Repeat Track Scan CD A track will be played. Audio CD: With the Scan CD function, the CD changer plays each track for 10 Hold down the rocker switch c until When random play is selected for an seconds.
  • Page 122 CD Player Activated = CD name If a CD is not removed, it will return to the player automatically and the Track name ejection process will be stopped. Artist name Album name Deactivated = Track number Album name Playing time Not all CDs contain CD text.
  • Page 123 AUX input AUX input General information The audio signal of the connected audio source is now transmitted via The connector is located in the area the speakers of the Infotainment of the centre console. system. Notice General information ....123 The volume can be adjusted via the The socket must always be kept m knob and via the o thumbwheel...
  • Page 124 USB port USB port General information ■ Devices connected via USB are supported according to USB The connector is located in the area Specification V 2.0. Maximum of the centre console. supported speed: 12 Mbit/s. Notice General information ....124 ■...
  • Page 125 USB port Playing saved audio files Supported folder structure depth: at iPod least 8 levels. MP3 player, USB drive, SD card WMA files with Digital Rights Management (DRM) from online music shops cannot be played. WMA files can only be played back safely, if they were created with Windows Media Player version 9 or later.
  • Page 126 USB port Music browser Notice The rocker switch buttons c and d have no function if an iPod is connected. Depending on the model/version of the connected iPod and the data stored, there are various options for the selection and playing of tracks. In the iPod menu select Album to display a menu with the available options for music browsing.
  • Page 127 USB port...
  • Page 128 Index Activating CD player....119 Ensemble........115 AM..........106 External In........104 AS..........109 Automatic search......106 Fader.......... 103 Automatic switch off...... 96 FM..........106 Autostore lists......109 AUX input socket........123 General information....usage........123 ......92, 118, 123, 124 Balance........
  • Page 129 Position........103 Programme type......111 TA volume........104 PTY..........111 Theft-deterrent feature ....93 Tone settings......103 TP..........111 Radio data system (RDS) ..111 Traffic announcements....111 Radio text........115 Traffic programme...... 111 Random........119 Treble......... 103 Random album......119 Regional programmes....
  • Page 131 Copyright by General Motors UK Ltd. The information contained in this publication is effective as of the date indicated below. General Motors UK Ltd. reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information contained in this publication, as well as changes to the publication itself.
  • Page 132 Vauxhall Zafira Infotainment System...

  • Page 133: Cd 30 / Cd 30 Mp3

    CD 30 / CD 30 MP3 Introduction ........ 134 Radio ......... 145 CD Player ........152 AUX input ........156 Index .......... 158...

  • Page 134: General Information

    Introduction Introduction General information In addition the Infotainment system can be equipped with a Mobile phone The Infotainment system provides portal. you with state-of-the-art in-car Optionally, the Infotainment system infotainment. General information ....134 can be operated using controls on the The radio has nine automatic station steering wheel.

  • Page 135: Theft-Deterrent Feature

    Introduction Radio reception Radio reception may be disrupted by static, noise, distortion or loss of reception due to ■ changes in distance from the transmitter, ■ multi-path reception due to reflection, ■ shadowing. Theft-deterrent feature The Infotainment system is equipped with an electronic security system for the purpose of theft deterrent.

  • Page 136: Overview

    Introduction Overview Control elements...
  • Page 137 Introduction RDS ........147 m ........141 10 OK ........139 Display programme name Confirm selection or page Radio: Page back in or transmission frequency forward in settings menu ..139 station memory, manual of the station ....... 147 and automatic station 11 n ........
  • Page 138 Introduction Steering wheel audio controls Press: TID: no function ..139 c button ....... 145 Press: GID: call up/reset Radio: search down, scroll trip computer, select a trip back through station computer entry ....139 memory ....... 145 q button ......145 CD: Short press: Skip one track backwards ....

  • Page 139: Operation

    Introduction The steering wheel remote control Switching on and off with the ignition Enable/Disable Ignition Logic has other functions in conjunction key (automatic switch-on) TID only: with the Mobile phone portal, see If the automatic switch-on is enabled, 1. Press SETTINGS button to chapter for Mobile phone portal.
  • Page 140 Introduction 3. Press OK button and then ■ Traffic announcements and The external source is automatically repeatedly n button to select external audio sources are inserted transferred through via a control at a preset minimum volume signal from the device connected, Ign.

  • Page 141: Tone Settings

    Introduction To avoid overriding the AUX input, the Audio Information effective output voltage of the Display of the following audio external audio source must be lower information: than 1.5 V. ■ Current waveband or AUX/CD. ■ Current station name or station Main display frequency or CD track number or The main menu is the display that...

  • Page 142: Volume Settings

    Introduction ■ Treble Press one of the function buttons After a few seconds the most TUNER, MEDIA or BC to display the recent display reappears. ■ Sound relevant function. Setting the volume distribution Press one of the function buttons Setting Bass and Treble between front - rear TUNER, MEDIA or BC to display the Make sure that any sound...
  • Page 143 Introduction The following menu items are 4. Adjust the value with m or n. The volume is only set to a minimum available: for announcements if the current After a few seconds the most volume setting is lower than the ■...
  • Page 144 Introduction On Volume 1. Press the SETTINGS button. 2. Press the OK button repeatedly 1. Press the SETTINGS button. until the relevant function is 2. Press the OK button repeatedly displayed. until the relevant function is 3. Adjust the value with m or n. displayed.

  • Page 145: Usage

    Radio Radio Usage Station search Radio mode Station selection, automatic search Switch from CD or AUX mode to radio Usage ........145 mode as shown below: FM waveband is selected and RDS Station search ......145 3 147 switched on. Press TUNER button.

  • Page 146: Autostore Lists

    Radio If the radio cannot find a station, it If RDS 3 147 is deactivated in the FM The station tuned-in is audible again switches automatically to a more and is displayed. waveband or the AM waveband is sensitive search level (not DAB). If it active, tapping m or n moves the The station is stored in the desired still cannot find a station, the last...

  • Page 147: Radio Data System (Rds)

    Radio The AS level can also be activated After the stations have been stored, Calling up a station and deactivated using the FM/AM the desired station can be selected by The desired waveband and the button 3 145. pressing the appropriate station desired mode need to be active button.
  • Page 148 Radio ■ The Infotainment system always disabled. However, the automatic tunes into the best receivable station search will also respond to broadcasting frequency of the set non-RDS stations. station by means of AF (Alternative This function is only applied if RDS is Frequency).
  • Page 149 Radio After station search starts the radio Automatic regionalisation Traffic stations can be recognised by display appears. the TP symbol in the display. If automatic regionalisation is switched on (REG Auto On): the radio If the radio does not find an Switching traffic programme on/off remains tuned to the regional appropriate station, it plays the...

  • Page 150: Digital Audio Broadcasting

    Radio ■ If on standby for traffic Traffic announcements are played at DAB stations are indicated by the announcement is switched on, then the preset volume for traffic programme name instead of the CD playback or DAB reception are announcement 3 142. broadcasting frequency.
  • Page 151 Radio ■ If the DAB signal is reflected by DAB AF corresponding FM station (if natural obstacles or buildings, the available) of the active DAB By setting DAB AF to On you can reception quality of DAB is programme. define that when you drive into improved, whereas AM or FM another ensemble area, the same The DAB waveband must be...
  • Page 152 CD Player CD Player General information ■ Self-recorded CD-Rs and CD-RWs are more vulnerable to mishandling With the CD player you can play than prerecorded CDs. Correct standard commercial CDs with a handling, especially in the case of diameter of 12 cm. self-recorded CD-Rs and CD-RWs, General information ....
  • Page 153 CD Player Applicable playlist extensions: Read CD and CD in appears on the Track selection "m3u" or "pls". display, then the number of CD tracks To select a track while a CD is is displayed. playing, tap on m or n repeatedly When generating (coding) the MP3 files from audio data, a bitrate of up until the desired track is displayed.
  • Page 154 CD Player The first track on the album is MP3 CD: Audio CD with CD text: displayed and played. ■ Random album: Random playback ■ Track name All albums which do not contain MP3 of the tracks of an album ■...
  • Page 155 CD Player Eject CD appears on the display. If a CD is ejected, the last radio station used will automatically be played. A CD can be ejected even if the appliance is turned off. The appliance switches off after the CD has been removed.
  • Page 156 AUX input AUX input General information Enable the external audio source and set it to maximum volume. The connector is located in the area If required: adjust the AUX input level of the centre console. in relation to the connected external Notice General information ....
  • Page 157 AUX input...
  • Page 158 Index Activating CD player....153 Fader.......... 141 AM..........145 FM..........145 AS..........146 Automatic search......145 General information..134, 152, 156 Automatic switch off....139 Autostore level......146 Autostore lists......146 Ignition logic........ 139 AUX input......139, 156 socket........156 AUX volume........
  • Page 159 SDVC.......... 142 Volume........139 Setting the volume...... 139 Volume settings......142 Sound settings......141 Speed dependent volume control (SDVC)......142 Starting CD replay...... 153 Station list........145 Station memory......145 Station search......145 Store........... 145 Switching the Infotainment system on or off....... 139 TA volume........
  • Page 161 Copyright by General Motors UK Ltd. The information contained in this publication is effective as of the date indicated below. General Motors UK Ltd. reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information contained in this publication, as well as changes to the publication itself.
  • Page 162 Vauxhall Zafira Infotainment System...

  • Page 163: Mobile Phone Portal

    Mobile phone portal Introduction ........ 164 Voice recognition ....... 174 Index .......... 180...
  • Page 164 Introduction Introduction General information General advice on these operating instructions The Mobile phone portal offers the You can find detailed functional opportunity to hold telephone descriptions for your Infotainment conversations using the mobile General information ....164 system in the operating instructions phone via a vehicle microphone and included with your Infotainment Bluetooth connection ....
  • Page 165 Introduction Operating the mobile telephone Bluetooth™ Operating the speech recognition system Mobile telephones affect your The Mobile telephone portal supports environment. This is the reason why Bluetooth™ Handsfree Profile V. 1.5 Do not use the speech recognition safety rules and regulations were and is specified to Bluetooth™...
  • Page 166 Introduction Bluetooth connection 1 Thumbwheel Turn: select menu items and The Bluetooth™ function on the commands mobile telephone must be activated, see operating instructions for the Press: confirm a selection (OK) mobile phone. 2 q button Bluetooth™ is a radio standard for Press: Selecting/switching off wireless connection of e.g.
  • Page 167 Introduction When the mobile telephone is slotted are listed in the Found devices in the adapter, the telephone menu or menu. Bluetooth™ menu appear on the display. If the mobile telephone is not slotted into the adapter, the Bluetooth™ menu appears on the display. Select the Bluetooth menu item.
  • Page 168 Introduction The message "Add device to 3. Deactivate Connect. known devices?", or a similar The message Disconnected! message, appears on the display appears followed once again by of the mobile telephone. the Bluetooth™ menu. 8. Confirm this on the keypad of the 4.
  • Page 169 Introduction Emergency call instructions for the mobile functions are active. You can telephone). enquire about this with the local The message "Device found: 9 Warning network operators. UHP" appears on the display of The emergency call number can the mobile telephone. Connection setup cannot be differ depending on the region and guaranteed in all situations.
  • Page 170 Introduction transferred from the mobile telephone Making telephone calls 9 Warning to the Infotainment system. This may Three different options where dialling take some time, depending on the a telephone number is concerned are Do not end the call until you are brand of telephone.
  • Page 171 Introduction Enter No... appears on the display. Select the digits for the telephone calls from the foot of the display in order and start the dialling process using Dial. Phone book After creation of the connection, the phone book is compared with the temporary phone book if the same Select the desired entry and start the Select the number you want and start...
  • Page 172 Introduction Select menu item Filtering. Press the p key . The selected check box indicates Refusing calls active filtering. The phone book Select the Reject menu item. entries are grouped by initial letter Ending calls (abc, def, …). Do the following in order to end the Select the entry you want and start telephone call: the dialling process.
  • Page 173 Introduction handsfree manufacturer must be permitted if the maximum observed when installing and transmission power of the mobile operating a mobile telephone. Failure telephone is 2 watts for GSM 900 or to do so could invalidate the vehicle 1 watt for the other types. type approval (EU directive 95/54/ For reasons of safety, do not use the EC).
  • Page 174 Voice recognition Voice recognition Voice recognition Before you dial a telephone number, the following preconditions must exist: The speech recognition system ■ The mobile telephone must be enables you to operate some of the Voice recognition ....... 174 ready for operation and a mobile telephone's functions by voice Bluetooth™...
  • Page 175 Voice recognition Ending the dialogue The Infotainment system ■ "Delete": The PIN code is deleted. simultaneously reacts to commands There are various ways to deactivate ■ "Additional digits": Additional with voice messages and displays. the speech recognition system and numbers can be entered. end the dialogue: Example of a dialogue whereby a PIN SIM card...
  • Page 176 Voice recognition ■ "Delete" ■ "Call" or "Accept": The inputs are In order to make a foreign call, you accepted. can say the word "Plus" (+) in front of ■ "Phonebook" the number. The plus allows you to ■ "Change": The last block of ■...
  • Page 177 Voice recognition User: "One One Nine Nine" "Redial" It can happen that the two names input are too different for the speech Using the "Redial" command, the Voice output repeats: "One One Nine recognition system, which then number most recently dialled can be Nine"...
  • Page 178 Voice recognition User: <Miriam> After the recognised name has been "Cancel" output, you can input the following Using the "Cancel" command, the Voice output: "The number, please!". commands: speech recognition system can be User: "Plus Four Nine" switched off. ■ "Call": The connection to the saved Voice output: "Plus Four Nine"...
  • Page 179 Voice recognition...
  • Page 180 Index Accepting calls......170 Lists..........170 Activating speech recognition..174 Making telephone calls....170 Bluetooth connection....166 Micro off........170 Mobile phones and CB radio equipment ......173 Call lists........170 Changing the language....174 Name.......... 174 Number........174 Dialling........170 DTMF..........
  • Page 181 Voice recognition ....... 174...
  • Page 183 Copyright by General Motors UK Ltd. The information contained in this publication is effective as of the date indicated below. General Motors UK Ltd. reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information contained in this publication, as well as changes to the publication itself.

This manual is also suitable for:

Cd 30Cd 30 mp3

Table of Contents
