SHC6400

Ultra-Rugged Tablet

SHC-6400

ULTWEEE Recycling Passport

Table of Contents

Need help?

Do you have a question about the SHC6400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sokkia SHC6400

Page 1 SHC6400 Ultra-Rugged Tablet SHC-6400 ULTWEEE Recycling Passport...
Page 2 SCH6400 Ultra-Rugged Tablet WEEE Recycling Passport Part Number 1069123-01 (JS 31302) Revision A 2023 © Topcon Corporation...
Page 3: Table Of Contents
SHC6400 Ultra-Rugged Tablet ........
Page 4: Shc6400 Ultra-Rugged Tablet
SHC6400 Ultra-Rugged Tablet WEEE Recycling Passport TITLE: REVISION DATE: SHC6400 WEEE Passport PART NUMBER: REVISION: 1132 West 1700 North Logan, Utah 84321 31302 435-753-1881 COLOR CODE: Juniper Systems Internal RoHS COMPLIANCY REQUIRED The use of heavy metals and heavy metal compounds of lead (Pb),...
Page 5 WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET REUSE AND TREATMENT INFORMATION Material Waste Disposal (WD) Weight (lb.) Weight [g] Weight [%] Important Information Subtotal Recovery Operations (RO) Rubber/Elastomer 0.014 6.350288 0.97% Sealant Compound Wood Subtotal 0.014 6.350288 0.97% Recycling (RC) Aluminum Alloy cast...
Page 6: Product Identification And Selective Treatment Information
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Product Identification and Selective Treatment Information SHC6400 Geo and GEO Cell USA and International Units Serial Label Sokkia Battery Door Label Sokkia Case Back Label Sokkia Product Label P/N: 1069123-01 (JS 31302)
Page 7: Primary Disassembly
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Primary Disassembly 1. Remove I/O Dust Cover. 5. Remove stylus from garage and cut tether to remove. 2. Remove Case Back Label. 6. Remove product label. 3. Remove battery door label. 7. Remove bumper screws (eight places) with PH#0 and remove bumpers.
Page 8: Case Back Disassembly
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Case Back Disassembly 7. Remove five screws from battery latch faceplate. 1. Remove hydrophobic patch. 2. Unlatch and remove battery door. 8. Remove battery latch and spring. 3. Remove rare earth magnet (Magnetic material).
Page 9 WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET 12. Remove plastic and rubber rings. 14. Remove three brass inserts. 13. Remove rubber stopper from end. 15. Remove camera lens and flashlight pipe. P/N: 1069123-01 (JS 31302)
Page 10: Internal Disassembly
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Internal Disassembly 6. Remove screw from Diversity module with PH#1. 7. Remove main and diversity antenna PCBAs Cell Modem and unplug cables. 1. Remove four screws indicated from Main antenna with PH#1. 2. Remove antenna.
Page 11: Rear Camera Disassembly
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Rear Camera Disassembly 3. Remove rear camera support with PH#1. 1. Remove camera boot. 4. Remove antenna support. 2. Peel rear camera from support and remove camera. P/N: 1069123-01 (JS 31302)
Page 12: Er Bluetooth Module Disassembly (If Equipped)
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET ER Bluetooth Module 3. Remove flex from PCBA. Disassembly (if equipped) 1. Remove these three screws with PH#1. 4. Remove the seven screws from around the PCBA with T5. 5. Separate the PCBA from the bracket.
Page 13: Main Pcba Disassembly
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Main PCBA Disassembly 3. Remove five screws from main PCBA with PH#1. NOTE: if an ER Bluetooth module has been 1. Remove Kapton tape from can. removed, three of these screws will have been removed in the process.
Page 14: Remove Flextails From Frame
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Remove Flextails from Frame 1. Remove front camera. 2. Remove thermal interface material. 3. Disconnect all flextails from PCBA. 4. Remove main PCBA. 7. Remove two T5 screws from I/O module. 8. Remove I/O module faceplate and remove I/O module from unit.
Page 15: Final Disassembly
WEEE Recycling Passport SHC6400 ULTRA-RUGGED TABLET Final Disassembly 6. Remove heat pipe from mag frame. 7. Remove six grounding pads. 1. Pull keypad cover away from unit 8. Remove ground tape strips from mag frame. 2. Pull keypad flex away from unit.
Page 16 Sokkia Corporation • 16900 W 118th Terrace • Olathe, KS 66061 • +1-800-4-SOKKIA Topcon Europe Positioning B.V. Essebaan 11 2908 Lj Capelle a/d Ijssel The Netherlands • +31 (0)10-751 9300 © 2023 Topcon Corporation • 7400 National Drive • Livermore, CA • 94550 • All rights reserved.
